TP-LINK Omada Tri-Band Omnidirectional BE9300 Indoor/Outdoor WiFi 7 Access Point

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1212042 Product code: EAP772-Outdoor
Can be ordered 10 units Availability: 14 days after order approval
Warranty: 3 years
236.83 €
Ready for dispatch
25.07.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Speed index: 9000
  • Type of device: Outdoor Access Point
  • Wi-Fi standard: Wi-Fi 7 (802.11 be)
Basic information
Speed index : 9000
Type of device Outdoor Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Wi-Fi standard : Wi-Fi 7 (802.11 be)
Functionality
3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode Tri-Band

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 2.5 Gbps

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 1
More detailed specification
Accessories included - EAP772-Outdoor Zestaw uszczelniający Zestaw montażowy Instrukcja instalacji
Antenna - Built-in
Antenna - Antenna type - Internal
Antenna gain - 6 dBi
ARTIKEL1 - BE11000 OUTDOOR WI-FI 7 AP
ARTIKEL2 - TRI-BAND 1X2.5G PORT POE
Brand - TP-Link
BrandPartCode - EAP772-OUTDOOR
Breite - 0
Category - Wireless Access Points
Certificates - CE, FCC, RoHS
Certificates - Certification - CE, FCC, RoHS, IC
Color - White
Description - Wewnętrzny/zewnętrzny, trzypasmowy, dookólny punkt dostępowy Omada Wi-Fi 7 BE9300 Zewnętrzne Wi-Fi 7: Prędkość do 9,3 Gb/s 6 GHz odblokowywane przez AFC: AFC umożliwia dostęp do pasma 6 GHz w zastosowaniach na zewnątrz budynku Dookólny zasięg w 3 pasmach: Do 300m2 zasięgu Profesjonalna konstrukcja urządzenia: Klasa szczelności IP68, 1 port RJ45 PoE+ 2.5G PoE+ i dwupolaryzacyjne anteny 2,4 GHz Prosta i szybka instalacja: Montaż na ścianie/słupie i konfiguracja jednym kliknięciem w Omada SDN Zaawansowane funkcje: Scentralizowane zarządzanie, Mesh i Płynny roaming Trzypasmowy, dookólny zasięg 6 GHz odblokowywane przez AFC
Odblokuj czyste, zewnętrzne pasmo 6 GHz wspierane przez AFC. EAP772-Outdoor eliminuje zatłoczenia i dostarcza trzypasmowy, dookólny zasięg w paśmie 2,4 GHz, 5 GHz oraz 6 GHz. Zasięg na poziomie nawet 300m2 zapewnia płynne działanie sieci na zewnątrz budynku.
Profesjonalna konstrukcja urządzenia
EAP772-Outdoor został wyposażony w port RJ45 2.5G z obsługą PoE+, dzięki czemu zapewnia wysoką przepustowość danych dla takich zastosowań jak płynne strumieniowanie na żywo i wideo 4K. Dodatkowo, jego dwupolaryzacyjne anteny pasma 2,4GHz oferują lepsze możliwości przeciwdziałania zakłóceniom.
Wiodąca w branży obudowa o klasie szczelności IP68
EAP772-Outdoor jest całkowicie pyłoszczelny i może być zanurzony pod wodą na głębokości do 1,5 metra nawet w czasie 1 godziny, co przekracza możliwości standardu IP67. Jest w stanie wytrzymać najtrudniejsze warunki środowiskowe panujące na zewnątrz budynku.
Płynna łączność w sieci Mesh z Roamingiem
Klienci mogą korzystać z nieprzerywanego strumieniowania podczas poruszania się po okolicy, dzięki możliwości automatycznego przełączania się między punktami dostępowyni oferującymi optymalny sygnał.
Konfiguracja w Omada SDN jednym kliknięciem
Omada SDN umożliwia użytkownikom szybką konfigurację EAP772-Outdoor poprzez automatyczną identyfikację urządzenia i adopcję jednym kliknięciem.
Design - LED indicators - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Designation - CE+WEEE
dimensionalWeight - 1815
dimension depth - 105 mm
dimension height - 325 mm
Dimensions - 230 × 207,5 × 69,7 mm
dimension weight - 2020 g
dimension width - 245 mm
ean - 1210002602280
EANCode - 1210002602280
Environment requirements - Dopuszczalna temperatura pracy: -3070   Dopuszczalna temperatura przechowywania: -4070   Dopuszczalna wilgotność powietrza: 1090%, niekondensująca Dopuszczalna wilgotność przechowywania: 590%, niekondensująca
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - Yes
Features - Airtime Fairness (ATF) - Yes
Features - BeamForming - Yes
Features - Bluetooth - Yes
Features - Bluetooth version - 5.2
Features - Ethernet LAN data rates - 2500 Mbit/s
Features - Maximum data transfer rate - 9300 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2880 Mbit/s
Features - Maximum data transfer rate (6 GHz) - 5760 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11be
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Number of users - 380 user(s)
Features - Quality of Service (QoS) support - Yes
Features - VLAN support - Yes
Gewicht - 2
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 1210002602280
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP772-OUTDOOR(EU)
I/O ports - 1 x 10/100/1000/2500 RJ-45 port PoE
Laenge - 0
LongDesc - Ultra-Thin Enterprise WiFi 7 Access Point- Next-Gen WiFi 7- Wi-Fi Speeds up to 9214 Mbps- Multi-Link Operation (MLO)- 1× 2.5G RJ45 Port- PoE Power- Ultra-Thin Design- Centralized Cloud Management- Omada Mesh TechnologyUltra-Thin Design for Flexible DeploymentThe overall design of EAP772 utilizes a thinner circular arc with a groove around the top cover, fitting closer to various installation surfaces such as ceilings. The compact internal hardware layout and heat-dissipating design ensure high performance with a sharp aesthetic.Boosted Network Security- Secure Guest Network with up to 24 SSIDs- Boost Your Business with SMS Login- WPA3 for Worry-Free Open Public Networks- Rogue AP Detection
LongProductName - 574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz), 802.11 a/b/g/n/ac/ax/be, 1× 2.5G Ethernet, 220 × 220 × 32.5 mm
LongSummaryDescription - TP-Link Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 9300 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal,.... Ethernet LAN data rates: 2500 Mbit/s. Product colour: White
Management, monitoring, configuration - Aplikacja Omada Dostęp do chmury: Tak. Wymaga użycia Kontrolera Omada. Powiadomienia e-mail  Kontrola dostępu po adresach MAC      SNMP v1, v2c Dziennik systemowy  SSH  Zarządzanie przez przeglądarkę Zarządzanie L3  Zarządzanie multi-site  Zarządzanie VLAN  Bezobsługowa konfiguracja ZTP: Tak. Wymaga użycia Kontrolera Omada opartego na Chmurze.\ Scentralizowane zarządzanie: Kontroler Omada oparty na Chmurze Kontroler sprzętowy Omada Kontroler programowy Omada
Management features - Web-based management - Yes
name - TP-Link EAP772-Outdoor
Network architecture - GigabitEthernet
Number of antennas - 1
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating frequency - 6 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Packaging content - AC adapter included - No
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power supply - 802.3at PoE
producer - TP-LINK
producerCode - EAP772-Outdoor
ProductName - BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
productName - TP-Link Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
productSize - Normal
Security - Uwierzytelnianie przy pomocy strony powitalnej§ Kontrola dostępu Filtrowanie bezprzewodowych adresów MAC Izolacja klientów sieci bezprzewodowej Mapowanie SSID do VLAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X Szyfrowanie WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 24
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - SNMP
Security - Security algorithms - SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Security - Security algorithms - SNMPv2
Security - Security algorithms - SNMPv3
Security - Security algorithms - WPA-Enterprise
Security - Security algorithms - WPA-Personal
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-Personal
Security - Security algorithms - WPA3-Enterprise
Security - Security algorithms - WPA3-Personal
Security - Service Set Identifier (SSID) features - Multiple SSIDs
ShortSummaryDescription - TP-Link Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point, 2.4 GHz, 5 GHz, 6 GHz, 9300 Mbit/s, SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal,..., 2500 Mbit/s
sizeX - 330
sizeY - 250
sizeZ - 110
Software -
Special functions - Funkcje transmisji bezprzewodowej: 4K-QAM OFDMA Multi SSID: 24 (8 na każde pasmo) Wł./wył. nadajnika sieci bezprzewodowej Automatyczny wybór kanału Kontrola mocy transmisji (na podstawie dBm) QoS (WMM) MU-MIMO MLO 320MHz Omada Mesh§ Płynny roaming (802.11k/v/r)§ Sterowanie pasmem Równoważenie obciążenia pasma Airtime Fairness Beamforming Ograniczanie prędkości Harmonogram restartu Harmonogram sieci bezprzewodowej Statystyki sieci bezprzewodowej w oparciu o SSID/AP/Klienta Statyczny adres IP/Dynamiczny adres lP
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11be
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 4
Stck_Pal - 0
Storno - N
System Requirements - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux
Title - TP-Link Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
URL - https://www.omadanetworks.com/en/business-networking/omada-wifi-outdoor/eap772-outdoor/(eu)%20v1/
vendpn - EAP772-Outdoor
WarrantyInfo - 3 Years
warrantyLength - 60
warrantyType - G
weight - 2000
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 32.5 mm
Weight & dimensions - Width - 220 mm
