Accessories included - ZenWiFi BD4 RJ45 cable Power adapter Warranty card Quick start guide
Antenna - Built-in
Brand - ASUS
BrandPartCode - 90IG0960-MO3C40
Category - Mesh Wi-Fi Systems
category - Peripherals|Networking & WLAN|Wireless LAN|Mesh
Category - Root/Electronics/Networks and communication/Routers
Certificates -
code - 90IG0960-MO3C40
Color - White
Description - ASUS ZenWiFi BD4 Najnowszej generacji rozwiązanie Wi-Fi 7 - Dzięki technologii 4096-QAM ZenWiFi BD4 umożliwia ultraszybką, wydajną i stabilną transmisję sieciową z przepustowością większą o 20% w porównaniu do Wi-Fi 6. Dwuzakresowa sieć Wi-Fi 7 typu mesh - Dwuzakresowy system typu mesh Wi-Fi 7 (802.11be) z unikalnym rozmieszczeniem anten udostępnia większą szybkość transmisji na poziomie do 3600 Mb/s, zapewniając silne połączenie Wi-Fi w każdym kącie Twojego domu. Multi-link Operation (MLO) - Dzięki technologii MLO urządzenia mogą jednocześnie nadawać i/lub odbierać na różnych pasmach i kanałach. Łącza równoległe zwiększają przepustowość urządzenia, zmniejszają opóźnienia i ulepszają niezawodność. Smart Home Master - Technologia Smart Home Master umożliwia Ci szybkie skonfigurowanie wydzielonej, zaawansowanej sieci w różnych scenariuszach zastosowań. Technologia Smart Home Master obsługuje teraz trzy główne funkcje, które obejmują sieć IoT, sieć dla dzieci oraz sieć VPN. Pakiet zabezpieczeń klasy komercyjnej - ZenWiFi BD4 jest dostarczany wraz z funkcjami ASUS AiProtection Pro, kontrolą rodzicielską, a także Safe Browsing, aby zabezpieczyć Twoje domowe środowisko Wi-Fi.
Design - Antennas quantity - 4
Design - Antenna type - Internal
Design - LED indicators - Power
Design - Maximum coverage - 603 m²
Design - Product colour - White
Design - Product type - Mesh router
Design - Reset button - Yes
Designation - CE+WEEE
dimension depth - 175 mm
dimension height - 330 mm
Dimensions - 140 x 70 x 140 mm
dimension weight - 2450 g
dimension width - 170 mm
ean - 4711387580943
Eans - 4711387580943
Environment requirements -
Features - Built-in processor - Yes
Features - DHCP server - Yes
Features - Firewall security - Firewall
Features - Flash memory - 128 MB
Features - Internal memory - 512 MB
Features - MU-MIMO technology - Yes
Features - Parental control - Yes
Features - Port forwarding - Yes
Features - Processor cores - 4
Features - Processor frequency - 1.5 GHz
Features - Quality of Service (QoS) support - Yes
GTIN - 4711387580943
guarantee - 36
guarantee_type - normal
I/O ports - 2 x 10/100/1000/2500 RJ-45 port (WAN)
LongDesc - ASUS ZenWiFi BT8 Worry-Free Smart Home MeshThe ASUS ZenWiFi series advances your ever-evolving smart home with worry-free WiFi. The ASUS ZenWiFi BT8 raises the bar for whole-home mesh with WiFi 7 and next-gen Smart AiMesh technology. It delivers blazing-fast tri-band speeds up to 14 Gbps and unleashes superior 6 GHz WiFi. Along with ultra-high-speed dual 2.5-gigabit Ethernet ports and a suite of advanced network and security technologies, this mesh WiFi system is ready for the future of your smart home network today.DESIGNThe Pinnacle of WiFiASUS ZenWiFi BT8 embodies our unwavering commitment to developing incredible in-house WiFi and network technologies. Seamlessly connect to your family and friends within a worry-free connected experience.
LongProductName - Dual-band WiFi 7 (802.11be) AiMesh Extendable Router, 3.6 Gbps, Coverage up to 6500 sq. ft. (3pk), Dual 2.5G Ports, Up to 3 SSIDs for IoT Devices, Parental Controls & VPNs, Advanced Network Security
LongSummaryDescription - ASUS ZenWiFi BD4. Product colour: White, Antenna type: Internal, Product type: Mesh router. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 7 (802.11be), WLAN data transfer rate (max): 2882 Mbit/s. Processor frequency: 1.5 GHz, Internal memory: 512 MB, Flash memory: 128 MB. AC input voltage: 110 - 240 V, AC input frequency: 50 - 60 Hz, AC adapter output voltage: 12 V. Width: 140 mm, Depth: 70 mm, Height: 140 mm
Management, monitoring, configuration - Diagnosis Tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update Adaptive QoS: Bandwidth Monitor, Bandwidth Limiter Traditional QoS Traffic Monitor Traffic Analyzer Website History WAN: Port Forwarding Port Triggering DMZ DDNS LAN: DHCP Server IGMP Snooping IPTV Manually Assign IP Address Wake on LAN (WOL) Wireless: MU-MIMO UTF-8 SSID WiFi MAC Address Filter Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming
Model - ZenWiFi BD4
Name - ASUS BD4 (3 pack)
name - ASUS ZenWiFi BD4 BE3600 Wi-Fi 7 Mesh System - weiß, 3er-Pack
name - Router ZenWiFi BD4 Dual-band WiFi 7 Mesh, 3600 Mbps (3-pack)
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features -
Packaging content - AC adapter included - Yes
Packaging content - Ethernet cable - Yes
Packaging content - Number of products included - 3 pc(s)
Packaging data - Package depth - 174 mm
Packaging data - Package height - 150 mm
Packaging data - Package weight - 2.34 kg
Packaging data - Package width - 339 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Ethernet WAN - Yes
Power - AC adapter output current - 1.5 A
Power - AC adapter output voltage - 12 V
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 110 - 240 V
Power supply - Wejście AC: 110 V ~ 240 V (50 ~ 60 Hz) Wyjście DC: 12 V z maksymalnym prądem 1,5 A
producer - Asus
Producer - Asus
ProducerCode - BD4 3-pak
ProductName - ZenWiFi BD4
Security - AiProtection VPN WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise WPS Let's Encrypt DNS-over-TLS Security Scan Firewall Parental Control VPN
ShortDescription - WI-FI 7
ShortSummaryDescription - ASUS ZenWiFi BD4, White, Internal, Mesh router, Power, 603 m², Dual-band (2.4 GHz / 5 GHz)
Software - ASUS Router APP
Special functions - Obsługa Google Assistant AiMesh: Primary AiMesh Router; AiMesh Node
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11be
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
System Requirements -
Title - ASUS ZenWiFi BD4 Dual-band (2.4 GHz / 5 GHz) Wi-Fi 7 (802.11be) White 2 Internal
Type - xDSL
URL - https://www.asus.com/networking-iot-servers/whole-home-mesh-wifi-system/zenwifi-wifi-systems/asus-zenwifi-bd4/
vendpn - ZenWiFi BD4 (3pk)
WarrantyInfo -
Weight & dimensions - Depth - 70 mm
Weight & dimensions - Height - 140 mm
Weight & dimensions - Weight - 511 g
Weight & dimensions - Width - 140 mm
Wireless LAN features - Apps supported - ASUS Router
Wireless LAN features - Dynamic DNS (DDNS) - Yes
Wireless LAN features - Guest access - Yes
Wireless LAN features - IGMP snooping - Yes
Wireless LAN features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
Wireless LAN features - Security algorithms - WPA, WPA2, WPA2-Enterprise, WPA3-Personal
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 7 (802.11be)
Wireless LAN features - VPN support - Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wireless LAN features - WLAN data transfer rate (first band) - 688 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 2882 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 2882 Mbit/s
