2.4 GHz Features - Yes
5 GHz Features - Yes
6 GHz Features - No
Accessories included - EAP625-Outdoor HD 2 Detachable Antennas Installation Guide Mounting Kit Sealing Kit
Antenna - Detachable external
Antenna - Antennas quantity - 2
Antenna - Antenna type - External
Antenna gain - 5 dBi
Antennas quantity Antenna - 2
Antenna type Antenna - External
ARTIKEL1 - AX1800 WI-FI 6 OUTDOOR AP
ARTIKEL2 - DUAL-BAND OMADA SDN
Brand - TP-Link
BrandPartCode - EAP625-OUTDOOR HD
Breite - 0
Cabling technology Features - 10/100/1000Base-T(X)
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Certificates - CE, FCC, RoHS
Color - White
Depth Weight & dimensions - 182.2 mm
Description - Long Distance Starts with External Antennas
Two detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network. Ideal for High-Density Outdoor Scenes
OFDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.
Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments. Flexible Deployment with Omada Mesh and PoE Support - Less Wiring with Omada Mesh
- Powered with PoE+ Switch
- Powered with Passive PoEUp to 1.8 Gbps WiFi 6 Speeds: 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHzSupports WiFi 6 technologies, such as 1024-QAM, OFDMA, etcHigh-density connectivity up to 1,000+ clientsLong-range coverage with the high-power amplifier and 2× detachable antennasIP67 weatherproof enclosure for various outdoor environmentsAdvanced Functions: Centralized management, Omada mesh, and seamless roamingPoE+ Powered: Supports both 802.3at PoE (adapter not included)
Description - Wireless Indoor/Outdoor Access Point, AX1800 Standard WiFi 6 with speeds up to 1.8Gbps: 574 Mbps in the 2.4GHz band + 1201 Mbps in the 5GHz band Support for WiFi 6 technology: 1024-QAM, OFDMA, etc. Ability to connect over 1,000 clients Long range thanks to a high-power amplifier and 2 detachable antennas The IP67 housing of the device will work well in outdoor conditions Advanced features: Centralized management, Omada Mesh and Seamless roaming Supports 802.3at PoE and Passive PoE (adapter not included)
Design - International Protection (IP) code - IP67
Design - LED indicators - Yes
Design - Placement - Pole, Wall
Design - Product colour - White
Design - Reset button - Yes
Designation - CE+WEEE
dimensionalWeight - 1225
dimension depth - 75 mm
dimension height - 340 mm
Dimensions - 280,4 × 182,2 × 56,9 mm
dimension weight - 1346 g
dimension width - 215 mm
ean - 4895252506327
EAN - 4895252506327
EANCode - 4895252506327
Environment requirements - Permissible operating temperature: -3070 (-22158) Permissible storage temperature: -4070 (-40158) Permissible air humidity: 10%90%, non-condensing Permissible storage humidity: 5%90%, non-condensing
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1800 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1201 Mbit/s
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Number of users - 1020 user(s)
Frequency band Features - 2.4 - 5 GHz
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0840030711831
GTIN - 840030711831
GTIN - 4895252506327
GTIN - 4895252506334
guarantee - 60
guarantee_type - normal
Height Weight & dimensions - 56.9 mm
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP625-OUTDOOR HD
I/O ports - 1 x 10/100/1000 Mbit/s
International Protection (IP) code Design - IP67
IP address filtering Security - Yes
Laenge - 0
LED indicators Design - Yes
LongDesc - Long Distance Starts with External AntennasTwo detachable external antennas for 5 GHz and 2.4 GHz provide optimal coverage and greater flexibility for your network.Ideal for High-Density Outdoor ScenesOFDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.Equipped with an IP67 weatherproof enclosure, our EAP625-Outdoor HD withstands the most extreme environments.Flexible Deployment with Omada Mesh and PoE Support- Less Wiring with Omada Mesh- Powered with PoE+ Switch- Powered with Passive PoE
LongProductName - 2.4GHz (574Mbps), 5GHz (1201Mbps), 802.11 a/b/g/n/ac/ax, Gigabit Ethernet, 280.4 x 182.2 x 56.9 mm
LongSummaryDescription - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Omada App Backup & Restore Website Firmware Upgrade NTP Cloud Access: Yes. Requires OC300 Controller, OC200 Controller, Omada Cloud Controller or Omada Software Controller Email Notifications LED Offset MAC Access Control SNMP v1, v2c, v3 SSH Website Management Central Management: Omada Hardware Controller (OC300) Omada Hardware Controller (OC200) Omada Software Controller Omada Cloud Controller
Manufacturer - TP-Link
Maximum data transfer rate (2.4 GHz) Features - 574 Mbit/s
Maximum data transfer rate (5 GHz) Features - 1201 Mbit/s
Maximum data transfer rate Features - 1800 Mbit/s
Model name - EAP625-OUTDOOR HD
MPN - EAP625-OUTDOOR HD
name - TP-Link EAP625-Outdoor HD Access Point AX1800
Name - TP-LINK Omada EAP625-Outdoor HD AX1800 Wifi6
Network architecture - GigabitEthernet
Networking standards Features - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of antennas - 2
Number of users Features - 1020 user(s)
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features -
Packaging content - Quantity per pack - 1 pc(s)
Placement Design - Pole, Wall
Power - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) Power - Yes
Power supply - 802.3at PoE 48V Passive PoE Note: PoE adapter not included.
producer - TP-LINK
producerCode - EAP625-Outdoor HD
Product colour Design - White
ProductName - AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
productName - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
productSize - Normal
Quantity per pack Packaging content - 1 pc(s)
Reset button Design - Yes
Security - VLAN Access Control Rogue AP Detection Captive Page Authentication Maximum MAC Filtering: 4,000 Wireless Client Isolation WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise Encryption 802.1X Support
Security - IP address filtering - Yes
Security - Security algorithms - WPA-Enterprise
Security - Security algorithms - WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Security - Security algorithms - WPA-Personal
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-Personal
Security - Security algorithms - WPA3-Enterprise
Security - Security algorithms - WPA3-Personal
Security algorithms Security - WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Series - Omada
ShortSummaryDescription - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point, 2.4 GHz, 5 GHz, 1800 Mbit/s, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
sizeX - 224
sizeY - 342
sizeZ - 80
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 8
Stck_Pal - 0
Storno - Y
Summary - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal. Power over Ethernet (PoE). Product colour: White
System Requirements -
Title - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
Unit Box Height - 0.08
Unit Box Length - 0.34
Unit Box Width - 0.22
Unit Calculated Volume - 0.006851 cubm
Unit Calculated Weight - 1.46 kg
Units per Pallet - 0
Units per Shipping Box - 8
URL - https://www.tp-link.com/en/business-networking/omada-wifi-outdoor/eap625-outdoor-hd/
Vendor Homepage - https://www.tp-link.com/en/business-networking/omada-wifi-outdoor/eap625-outdoor-hd/
vendpn - EAP625-Outdoor HD
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
Weight - 1.343
Weight - 886 g
weight - 1340
Weight & dimensions - Depth - 182.2 mm
Weight & dimensions - Height - 56.9 mm
Weight & dimensions - Width - 280.4 mm
Width Weight & dimensions - 280.4 mm
