10/100/1000M LAN Ports - 1
Accessories included -
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antennas quantity - 2
Antenna - Antenna type - Internal
Antenna gain - 5 dBi
ARTIKEL1 - AX1800 WI-FI 6 OUTDOOR AP
ARTIKEL2 - DUAL-BAND OMADA SDN
Brand - TP-Link
BrandPartCode - EAP623-OUTDOOR HD
Breite - 0
Category - Wireless Access Points
Category Code - WAP
Certificates - CE, FCC, RoHS
Certificates - Certification - CE, FCC, RoHS
Color - White
Colour - White
Data transmission speed - 1800 Mbps
Description - AX1800 Indoor/Outdoor Wi-Fi 6 Access Point Up to 1.8 Gbps WiFi 6 Speeds: 574 Mbps on 2.4 GHz + 1201 Mbps on 5 GHz.1 Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc.2 High-density connectivity up to 1,000+ clients.3 Long-range coverage with the high-power amplifier and smart antennas. Advanced Functions: Centralized management, Omada mesh, and seamless roaming.4 PoE+ Powered: Supports both 802.3at PoE (adapter not included).
Description - Do 1,8 Gb/s WiFi 6 prędkości: 574 Mb/s na 2,4 GHz + 1201 Mb/s na 5 GHz. Obsługuje technologie Wi-Fi 6, takie jak 1024-QAM i OFDMA itp. Obudowa odporna na warunki atmosferyczne IP67 do różnych środowisk zewnętrznych. Zaawansowane funkcje: Scentralizowane zarządzanie, siatka Omada i płynny roaming. Zasilanie PoE+: Obsługuje PoE 802.3at (adapter nie wchodzi w skład zestawu).
Design - LED indicators - Yes
Design - Placement - Pole
Design - Product colour - White
Design - Reset button - Yes
Designation - CE+WEEE
dimension depth - 90 mm
dimension height - 480 mm
Dimensions - 280.4 x 106.5 x 56.8 mm
Dimensions - 280.4 × 106.5 × 56.8 mm
dimension weight - 1200 g
dimension width - 240 mm
ean - 4895252506303
EANCode - 4895252506303
Environment requirements - Temperatura pracy: -30°C-70°C Temperatura przechowywania: -40°C-70°C Wilgotność robocza: 10%-90%, bez kondensacji; Wilgotność przechowywania: 5-90%, bez kondensacji
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1800 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1201 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Number of users - 1020 user(s)
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power (CE) - < 20 dBm (2.4 GHz, EIRP), < 30 dBm (5 GHz, EIRP);
Features - Transmitting power (FCC) - < 25 dBm (2.4 GHz), < 25 dBm (5 GHz)
Features - VLAN support - Yes
Gewicht - 1.18
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4895252506303
GTIN - 4895252506310
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP623-OUTDOOR HD
I/O ports - 1 x 10/100/1000 Mbit/s
Laenge - 0
LongDesc - Long-Range, High-Speed WiFi 6Professional antennas with high-power amplifiers utilize WiFi 6 technology to deliver robust and extensive wireless coverage.Powered by the latest WiFi 6 technology, the AP delivers speeds of up to 1.8 Gbps.Explore More with Smart AntennasEquipped with horizontally polarized and vertically polarized antennas, EAP623-Outdoor HD’s intelligent algorithms automatically select the optimal antennas, bringing lower interference, longer coverage, and higher performance.Ideal for High-Density Outdoor ScenesOFDMA and MU-MIMO provide simultaneous connections for dozens of clients in large open areas.Equipped with an IP67 weatherproof enclosure, our EAP623-Outdoor HD withstands the most extreme environments.Flexible Deployment with Omada Mesh and PoE SupportSeamless Integration into Omada SDN
LongProductName - 2.4 GHz (574 Mbps), 5 GHz (1201 Mbps), 1x Gigabit LAN, 48V Passive PoE, 280.4 x 106.5 x 56.8 mm
LongSummaryDescription - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, SSH. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Aplikacja Omada Przywracania kopii zapasowej Aktualizacja oprogramowania sprzętowego przez Internet NTP Scentralizowane zarządzanie: Kontroler sprzętowy Omada (OC300); Kontroler sprzętowy Omada (OC200); Kontroler programowy Omada; Kontroler oparty na chmurze Omada Dostęp do chmury: Tak. Wymagaj użycia OC300, OC200, kontrolera programowego Omada lub kontrolera Omada opartego na chmurze. Powiadomienie e-mailem Dostęp do zarządzania można filtrować na podstawie adresów MAC SNMP: v1, v2c, v3 SSH: Tak Interfejs sieciowy
Management features - Syslog - Yes
Management features - Web-based management - Yes
Model name - EAP623-OUTDOOR HD
name - Access Point EAP623-Outdoor HD AX1800
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power supply - 802.3at PoE Pasywne PoE 48 V
producer - TP-LINK
ProductName - AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
Product Net Weight - 1 kg
Security - VLAN Kontrola dostępu Wykrywanie fałszywych punktów dostępowych Uwierzytelnianie portalu przechwytującego Izolacja bezprzewodowa między klientami WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise Obsługa 802.1X
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - SNMP, SNMPv2, SNMPv3, SSH
ShortSummaryDescription - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point, 2.4 GHz, 5 GHz, 1800 Mbit/s, SNMP, SNMPv2, SNMPv3, SSH, 10,100,1000 Mbit/s
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 0
Storno - Y
System Requirements -
Title - TP-Link Omada AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
Unit Box Height - 0.065
Unit Box Length - 0.325
Unit Box Width - 0.24
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 1 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/my/business-networking/omada-wifi-outdoor/eap623-outdoor-hd/
Vendor Homepage - www.tp-link.com/my/business-networking/omada-wifi-outdoor/eap623-outdoor-hd/
vendpn - EAP623-Outdoor HD
Warranty - 60 months
WarrantyInfo -
Weight & dimensions - Depth - 106.5 mm
Weight & dimensions - Height - 56.8 mm
Weight & dimensions - Width - 280.4 mm
Wireless Frequency Range - 5 GHz, and 2.4 GHz
