Accessories included - 1 x 1 do 3 Kabel PWM wentylatora 1 x Kabel wentylatora zasilacza Molex 4-Pin do 4-Pin (2-pinowy) 1 x Kabel redukcji szumĂłw
Air flow rates - 78.73 cfm
Brand - MSI
BrandPartCode - MAG-CRLQD-360R2
Category - Computer Cooling Systems
category - Liquid Cooling|Sets & Bundles|AIO Liquid Coolers|360 mm AiOs
code - 306-7ZW1C41-813
Cooling technology - Liquid
CPU socket - LGA1150
CPU socket - LGA1151
CPU socket - LGA1155
CPU socket - LGA1156
CPU socket - LGA1200
CPU socket - LGA1366
CPU socket - LGA1700
CPU socket - LGA2011
CPU socket - LGA2011-3
CPU socket - LGA2066
CPU socket - Socket AM2
CPU socket - Socket AM2+
CPU socket - Socket AM3
CPU socket - Socket AM3+
CPU socket - Socket AM4
CPU socket - Socket FM1
CPU socket - Socket FM2
CPU socket - Socket FM2+
CPU socket - Socket SP3
CPU socket - Socket sTRX4
CPU socket - Socket TR4
Description - ChĹodzenie procesora MAG CORELIQUID 360R V2Â Â
Design - Fan connector - 4-pin
Design - Illumination LED - Yes
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Design - Radiator material - Aluminum
Designation - CE+WEEE
dimension depth - 145 mm
dimension height - 440 mm
Dimensions - Wymiary wentylatora: 120 x 120 x 25 mm Wymiary grzejnika: 394 x 120 x 27 mm Wymiary grzejnika: 394 x 120 x 27 mm
dimension weight - 2382 g
dimension width - 185 mm
ean - 4719072864088
Fan - 12 cm
Fan speed (max) - 500 rpm
Fan speed (min) - 2000 rpm
GTIN - 4719072864088
guarantee - 36
guarantee_type - normal
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - CONQUER THE BATTLEFIELDThe MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.The newly introduced MAG CORELIQUID has everything you're looking for in a liquid cooler, ranging from quality materials that provide reliable durability to heat dissipation technologies that are extremely effective. Users can even enjoy perks like ARGB lighting and a 270-degree rotating blockhead that is simple to use. On top of that, the blockhead boasts a unique irregular aesthetic that is both stylish and artistic. Every single component of the MAG CORELIQUID is designed with the end goal in mind: to provide effective cooling without any compromise.ROTATABLE BLOCKHEADMount the cold plate at any orientation, turn the blockhead up to 270 degrees, and keep it upright.RADIATOR PUMP DESIGNThe pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump's life expectancy by moving it away from the heat source.LGA 1700 COMPATIBLEThe MAG CORELIQUID R Series liquid cooler provides out of box support for LGA 1700.PUMP MOTOR RESONANCE ELIMINATIONA durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.HIGH THERMAL DISSIPATIONA split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.EVAPORATION PROOF TUBINGConstructed with three layers of netted plastic tubing and a reinforced mesh exterior.DIY 2.0 – INTEGRATING WITH THE SYSTEM ENVIRONMENTConnect and synchronize with MSI coolers and cases with strategically positioned pin-header locations including a dedicated pump-fan header.MORE SILENCE THAN EXPECTEDMAG CORELIQUID 360R V2's noise level is significantly lower than that of competitor's by 10%.COOLING YOU CAN'T HEARFor those who prefer a quieter environment, a bundled noise reducer cable changes the fans’ speed to produce less sound while still providing good airflow.EXTENSIVE COMPATIBILITYRobust yet built for flexibility, MAG CORELIQUID has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.
LongProductName - 2000/4200 RPM, 14.3-34.3 dBA, 21.63-78.73 CFM, 1.8/4.08W, ARGB, 12V DC
LongSummaryDescription - MSI MAG CORELIQUID 360R V2 Liquid CPU Cooler '360mm Radiator, 3x 120mm ARGB PWM Fan, ARGB lighting, Center Supported, Compatible with Intel and AMD Platforms, Latest LGA 1700 ready'. Type: Liquid cooling kit, Fan diameter: 12 cm, Minimum air pressure: 0.23 mmH2O, Maximum air pressure: 2.39 mmH2O. Product colour: Black
name - MAG Core Liquid 360R V2 360mm ARGB CPU Cooler
name - MSI MAG CoreLiquid 360R V2 ARGB AiO Wasserkühlung - 360mm
Noise - 34.3 dB
Number of fans - 3
Other features - ĹoĹźysko wentylatora: dwa ĹoĹźyska kulkowe Oczekiwana ĹźywotnoĹÄ wentylatora: 70 000 godzin NapiÄcie znamionowe wentylatora: 12 V DC PrÄd znamionowy wentylatora: 0,15 A PobĂłr mocy wentylatora: 1,8 W Tryb PWM DĹugoĹÄ kabla (kabel 5V ARGB/PWM): 550/350 mm ZĹÄcze kabla ARGB: pin + gniazdo DĹugoĹÄ rury chĹodzÄcej wodÄ: 400 mm OĹwietlenie blokowe: ARGB Oczekiwana ĹźywotnoĹÄ pompy: 100 000 godzin Poziom haĹasu pompy: 18 dBA PrÄd obciÄĹźenia pompy: 0,34 A PobĂłr mocy pompy: 4,08 W PrÄdkoĹÄ pompy: 4200 obr/min NapiÄcie znamionowe pompy: 12 V DC DĹugoĹÄ kabla ARGB 5V: 400 mm ZĹÄcze kabla ARGB: pin + gniazdo
Performance - Compatible processor series - AMD Ryzen 7 5th Gen, 3rd Generation AMD Ryzen™ 9, AMD Ryzen 9 5th Gen, 3rd Gen AMD Ryzen™ Threadripper™, Intel® Core™ i7, Intel® Core™ i9
Performance - Fan bearing technology - Ball bearing
Performance - Fan diameter - 12 cm
Performance - Fan diameter 2 - 12 cm
Performance - Fan noise level (max) - 34.3 dB
Performance - Fan noise level (min) - 14.3 dB
Performance - Fan speed (max) - 2000 RPM
Performance - Fan speed (min) - 500 RPM
Performance - Maximum airflow - 78.73 cfm
Performance - Maximum air pressure - 2.39 mmH2O
Performance - Minimum airflow (imperial) - 21.63 cfm
Performance - Minimum air pressure - 0.23 mmH2O
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Pump bearing technology - Ceramic bearing
Performance - Pump connector - 3-pin
Performance - Pump motor speed - 4200 RPM
Performance - Pump noise level - 18 dB
Performance - Suitable location - Motherboard, Processor
Performance - Supported processor sockets - LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+, Socket SP3, Socket TR4, Socket sTRX4
Performance - Type - Liquid cooling kit
Power - Fan current - 0.15 A
Power - Fan power consumption - 1.8 W
Power - Fan voltage - 12 V
Power - Pump current - 340 mA
Power - Pump power consumption - 4.08 W
Power - Pump voltage - 12 V
producer - MSI
ProductName - MSI MAG CORELIQUID 360R V2 Liquid CPU Cooler '360mm Radiator, 3x 120mm ARGB PWM Fan, ARGB lighting, MSI Center Supported, Compatible with Intel and AMD Platforms, Latest LGA 1700 ready'
Radiator - Aluminium
ShortSummaryDescription - MSI MAG CORELIQUID 360R V2 Liquid CPU Cooler '360mm Radiator, 3x 120mm ARGB PWM Fan, ARGB lighting, Center Supported, Compatible with Intel and AMD Platforms, Latest LGA 1700 ready', Liquid cooling kit, 12 cm, Black
Title - MSI MAG CORELIQUID 360R V2 Liquid CPU Cooler '360mm Radiator, 3x 120mm ARGB PWM Fan, ARGB lighting, Center Supported, Compatible with Intel and AMD Platforms, Latest LGA 1700 ready'
Type of cooling - Active
URL - https://www.msi.com/Liquid-Cooling/MAG-CORELIQUID-360R-V2/Overview
vendpn - MAG CORELIQUID 360R V2
WarrantyInfo -
Weight & dimensions - Fan dimensions (W x D x H) - 120 x 120 x 25 mm
Weight & dimensions - Radiator depth - 12 cm
Weight & dimensions - Radiator height - 2.7 cm
Weight & dimensions - Radiator width - 39.4 cm
Weight & dimensions - Tube length - 40 cm
Weight & dimensions - Waterblock depth - 6.68 cm
Weight & dimensions - Waterblock height - 4.86 cm
Weight & dimensions - Waterblock width - 8.06 cm
