Asus Platforma Asus Rack (1U) RS500A-E12-RS4U AMD Epyc 9004 (4x Nvme, 2xM.2, 2xGPU, 2x1Gbe, IPMI, 1+1 800W)

Brand - ASUS
BrandPartCode - 90SF02J1-M000R0
Category - Server Barebones
Category 1 - PC-Systeme
Category 2 - Server Barebone
Design - Chassis type - Rack (1U)
Design - LED indicators - Yes
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product colour - Black, Silver
Design - Product colour - Silver
dimensionalWeight - 27460
EAN - 4711387030448
Expansion slots - Number of M.2 (M) slots - 2
Expansion slots - PCI Express x8 slots - 1
Expansion slots - PCI Express x16 slots - 3
Features - Trusted Platform Module (TPM) - Yes
Features - Trusted Platform Module (TPM) version - 2.0
GTIN - 4711387030448
LongDesc - PCIe 5.0 ReadyFaster storage, graphics and networking capabilitiesPCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.AMD EPYC™ 9004 Series ProcessorsThe 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.World Records LeadershipASUS holds the most amount of records in dual-socket (2P) and single-socket (1P) on SPEC CPU 2017 benchmark and dominate the computing performance. These top performance results provide a useful insight into compute-intensive workloads on different computer systems, enabling our customers to reduce complexity, tackle challenging workloads and accelerate system validations.ASUS servers feature Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for timesensitive applications such as financial services or data center operations.Core OptimizerMaximizes the processor frequency in multi-core operations, avoiding frequency shifting for reduced latency.Engine BoostAutomatic power acceleration with an innovative voltage design to increase server overall performance.Workload PresetsPreconfigured BIOS server profiles based on workloads and benchmarks for improved performance and efficiency.ASUS select servers achieved most power efficiency positions on the SPEC Power benchmark for energy efficiency and demonstrate to customers how they can achieve faster deployments and higher energy efficiency for their IT infrastructure.ASUS Power BalancerAdjust overall loading automatically based on real-time monitoring to decrease overall power consumption for Improved efficiency and cost/performance optimization.Thermal Radar 2.0Features intelligent fan-curve adjustments to fit the real-time server usage patterns and lower fan power consumption.Scalable Storage SolutionThis server features scalable storage solutions to support maximum performance for data center flexibility, and enable industry-standard SAS/SATA/NVMe interfacing through Broadcom Tri-Mode RAID adapters for increased connectivity and security.Accelerating performance for AI workloadsUp to two single-slot GPUsThis server features multiple PCIe 5.0 slots to meet the demands of AI and high-performance computing (HPC) workloads, including supporting up to two single-slot active or passive GPUs, and Xilinx Alveo accelerators. The scalable configurations in one 1U system provide optimized acceleration for workloads across cloud and on-premises data centers, and for hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.* The total number of NVMe drives installed will affect the total number of GPUs that can be installed.* FPGA Xilinx verification is available on request.* Refer to GPU compatible list by models.NVIDIA Omniverse3D design collaboration and simulationASUS solutions for Omniverse give your organization a comprehensive package for Omniverse Enterprise. The diverse portfolio allows us to tailor a package to be fully compatible with your design environment and needs. As our long-term partnership with NVIDIA and ISV certifications, we’re fully invested in the Omniverse ecosystem and ready to help our partners develop new segments on this exciting platform.Server-management SolutionRemote server managementASUS ASMB11-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.Enhanced SecurityHardware Root-of-Trust SolutionDetect, recover, boot and protectASUS servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.* Platform Firmware Resilience (PFR) module must be specified at time of purchase and is factory-fitted. It is not for sale separately.Trusted Platform Module 2.0ASUS servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.
LongProductName - AMD EPYC 9004 single-processor 1U server that supports up to 24 DIMM, 4 NVMe, three PCIe 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs, and ASUS ASMB11-iKVM
LongSummaryDescription - ASUS RS500A-E12-RS4U. Processor socket: Socket SP5, Processor manufacturer: AMD, Processor family: AMD. Supported memory types: DDR5-SDRAM, Maximum internal memory: 6.14 TB, Supported RDIMM clock speeds: 4000,3600,4400,4800 MHz. Storage drive sizes supported: 3.5,M.2, Supported storage drive types: HDD & SSD, Supported storage drive interfaces: Serial ATA, Serial Attached SCSI (SAS). Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, LAN controller: Intel® I350-AM2. Chassis type: Rack (1U), Product colour: Black, Silver
Manufacturer - ASUS
Memory - Maximum internal memory - 6.14 TB
Memory - Number of DIMM slots - 24
Memory - Supported memory types - DDR5-SDRAM
Memory - Supported RDIMM clock speeds - 3600
Memory - Supported RDIMM clock speeds - 4000
Memory - Supported RDIMM clock speeds - 4000,3600,4400,4800 MHz
Memory - Supported RDIMM clock speeds - 4400 MHz
Memory - Supported RDIMM clock speeds - 4800 MHz
MPN - 90SF02J1-M000R0
Name - Barebone ASUS RS500A-E12-RS4U/1G/800W/4NVMe/OCP
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - LAN controller - Intel® I350-AM2
Operational conditions - Operating temperature (T-T) - 10 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 20 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging data - Package weight - 18.1 kg
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - IPMI LAN (RJ-45) port - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - 80 PLUS certification - 80 PLUS Titanium
Power - Number of main power supplies - 2
Power - Power supply - 800 W
Processor - Built-in processor - No
Processor - Compatible processor series - AMD EPYC 9004
Processor - Number of processors supported - 1
Processor - Processor family - AMD
Processor - Processor manufacturer - AMD
Processor - Processor socket - Socket SP5
producerCode - 90SF02J1-M000R0
productName - ASUS RS500A-E12-RS4U Socket SP5 Rack (1U) Black, Silver
ProductName - RS500A-E12-RS4U
productSize - Normal
ShortSummaryDescription - ASUS RS500A-E12-RS4U, Socket SP5, AMD, AMD, AMD EPYC 9004, DDR5-SDRAM, 6.14 TB
sizeX - 598
sizeY - 1148
sizeZ - 200
Storage - Hot-swap HDD bays - Yes
Storage - Number of 3.5" bays - 4
Storage - Number of storage drives supported - 6
Storage - SSD form factor - M.2
Storage - Storage drive sizes supported - 3.5
Storage - Storage drive sizes supported - 3.5,M.2
Storage - Storage drive sizes supported - M.2
Storage - Supported storage drive interfaces - Serial ATA, Serial Attached SCSI (SAS)
Storage - Supported storage drive types - HDD & SSD
Title - ASUS RS500A-E12-RS4U Socket SP5 Rack (1U) Black, Silver
URL - https://servers.asus.com/products/Servers/Rack-Servers/RS500A-E12-RS4U
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 21080
Weight & dimensions - Depth - 449 mm
Weight & dimensions - Height - 43.9 mm
Weight & dimensions - Weight - 13.2 kg
Weight & dimensions - Width - 842.5 mm
