Yealink Yealink

Audio - Audio system full duplex - Yes
Audio - Built-in speaker(s) - Yes
Audio - Echo cancellation - Yes
Audio - Speaker power - 5 W
Brand - Yealink
BrandPartCode - 1203684
Camera - Auto Focus (AF) object detection - People
Camera - Camera privacy shutter - Yes
Camera - Camera type - Single camera
Camera - Diagonal field of view - 120°
Camera - Horizontal field of view - 105°
Camera - Remote control interface - Ethernet
Category - Video Conferencing Systems
Certificates - Certification - CE, FCC, RoHS, REACH, ISO 9001, CCC, NOM
Code - 1203684
Computer system - Mobile operating systems supported - Android 11.0
Computer system - Operating system installed - Android 10
Design > Colour of product - Black
Display - Display diagonal - 20.3 cm (8")
Display - Display resolution - 1280 x 800 pixels
Display - Touchscreen - Yes
Display > Display diagonal - 8 "
Display > Touchscreen - Yes
EAN - 6938818316218
Features - Cable lock slot - Yes
Features - Motion sensor - Yes
GTIN - 0841885118608
GTIN - 841885118608
GTIN - 6938818316218
Logistics data - Country of origin - China
LongDesc - Yealink MeetingBar A10 is an all-ine-one video bar deisgned for small space (1-7 people) and home office. The built-in 4k camera with 120° field of view catches details precisely, with great color. AI-powered features including Auto Framing, Speaker Tracking and Smart Gallary deliver a focused view without distraction. The built-in 8-MEMS beamforming microphones pick up voice from all directions, and a full-duplex audio algorithm with AI-enhanced noise cancellation delivers clear sound for both sides clearly even if you are talking at the same time.
LongProductName - MeetingBar A10-020, all-in-one video bar, Teams/Zoom/BYOD, video conferencing kit (video bar, touch console CTP18)
LongSummaryDescription - Yealink MeetingBar A10-020. Product type: Video collaboration bar. HD type: 4K Ultra HD, Maximum frame rate: 30 fps. Ethernet LAN, Wi-Fi. Bluetooth. Display diagonal: 20.3 cm (8"), Display resolution: 1280 x 800 pixels. Operating system installed: Android 10. Product colour: Black, Grey
Microphone - Microphone mute - Yes
Microphone - Microphone sensitivity - 88 dB
Microphone - Number of microphone arrays - 8
Name - Yealink Meeting Bar A10-020 | Black
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,1000,100 Mbit/s
Network - Security algorithms - 256-bit AES, EAP-TLS, MSCHAPv2, PEAP, TLS
Network - Wi-Fi - Yes
Networking > Bluetooth - Yes
Networking > Bluetooth version - 4.2
Networking > Wi-Fi - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -30 - 70 °C
Other features > Compatible operating systems - Android 11
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 447.00 mm
Package features > Gross height (mm) - 150.00 mm
Package features > Gross width (mm) - 165.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 78 pc(s)
Package features > Paper/Pasteboard - 320.00 g
Package features > Plastic (No PET) - 80.00 g
Package features > Tare weight (kg) - 0.40 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Cables included - HDMI, LAN (RJ-45)
Packaging content - HDMI cable length - 1.8 m
Packaging content - Networking cable length - 3 m
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 150 mm
Packaging data - Package height - 447 mm
Packaging data - Package weight - 4.27 kg
Packaging data - Package width - 165 mm
Performance - Auto-tracking - Yes
Performance - Auto framing - Yes
Performance - Bluetooth - Yes
Performance - Bluetooth version - 4.2
Performance - Meeting features - Add participates, Calendar, Content sharing, Hold/Resume, One-click join
Performance - Number of cameras - 1
Performance - Product colour - Black, Grey
Performance - Product type - Video collaboration bar
Performance - PTZ control - Yes
Performance - Tracking modes - Presenter mode
Performance - Wall mountable - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - Line-in - Yes
Ports & interfaces - Line-out - Yes
Ports & interfaces - Microphone in - Yes
Ports & interfaces - Reset slot - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Ports & interfaces - USB connector type - USB Type-A, USB Type-C
Power - AC input voltage - 100 - 240 V
Power - DC output current - 0.7 A
Power - DC output voltage - 48 V
Power - Power consumption (idle) - 10 W
Power - Power consumption (max) - 14 W
Power - Power consumption (typical) - 10.5 W
Power - Power source type - AC
ProductName - MeetingBar A10-020
ShortSummaryDescription - Yealink MeetingBar A10-020, Video collaboration bar, 4K Ultra HD, 30 fps, Android 10, Black, Grey
Technical details > Connections - 1x HDMI output (CEC supported), 1x USB-A, 1x USB-C for content sharing, 1x 10 M/100 M/1000 M Ethernet port, 1x Yealink VCH port (RJ-45), 1x Power port, 1x Security lock slot, 1x Reset slot
Technical details > Gross weight - 2.20 kg
Technical details > Net weight - 1.80 kg
Technical details > Producer - Yealink
Technical details > Producer product name - Meeting Bar A10-020
Title - Yealink MeetingBar A10-020
URL - https://www.yealink.com/en
Video - HD type - 4K Ultra HD
Video - Maximum frame rate - 30 fps
Video - Maximum video resolution - 3840 x 2160 pixels
Video - Video codecs - H.264 High profile, H.264 SVC, H.264
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 68 mm
Weight & dimensions - Height - 82 mm
Weight & dimensions - Weight - 3.59 kg
Weight & dimensions - Width - 380 mm
