Startech 2-PORT GIGABIT POE INJECTOR 802.3AF/AT 10M/100M/1000M

ARTIKEL1 - 2-PORT GIGABIT POE INJECTOR
ARTIKEL2 - 802.3AF/AT 10M/100M/1000M
Brand - StarTech.com
BrandPartCode - AF221CE-POE-INJECTOR
Breite - 0
Category - PoE Adapters
Certificates - Compliance certificates - RoHS
EANCode - 0065030911313
Features - Auto-negotiation - Yes
Features - Housing material - Plastic
Features - Jumbo frames - 9000
Features - Jumbo frames support - Yes
Features - LED indicators - Yes
Features - Maximum operating distance - 100 m
Features - Product colour - Black
Features - Surge protection - Yes
Features - Wall mountable - Yes
Gewicht - 0.36
GRUPPE1 - Network
GRUPPE2 - Media Converters
GTIN - 0065030911313
GTIN - 065030911313
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - AF221CE-POE-INJECTOR
Laenge - 0
Logistics data - Master (outer) case height - 320 mm
Logistics data - Master (outer) case length - 420 mm
Logistics data - Master (outer) case width - 440 mm
Logistics data - Products per master (outer) case - 40 pc(s)
LongDesc - Supply power and data to two PoE devices over standard Ethernet cablingThis 2-port multi-speed PoE+ injector serves as Power Sourcing Equipment (PSE) and enables Ethernet speeds of 10/100/1000Mbps. This mid-span inline injector can transmit network data and power up to 328ft (100m) for two Powered Devices (PD).Versatile PoE InjectorDual-port PoE injector supports the IEEE 802.3af and IEEE 802.3at PSE standards and delivers up to 30W output (52V/0.580A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design allows for either desktop or surface-mount use.Streamlined Cable ManagementAll Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (3.2x1x1.8in(82x25x46mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.The StarTech.com Advantage
LongProductName - StarTech.com 2-Port PoE+ Injector, 10/100/1000Mbps, PoE/PoE+ (802.3af/at), 4x 10/100/1000BASE-T RJ45, 30W, Wall Mountable
LongSummaryDescription - StarTech.com 2-Port Gigabit Midspan PoE+ Injector, 10/100/1000Mbps, PoE+ (802.3af/at), 30W, 1Gbps Ethernet, Wall Mountable, Unmanaged Inline Power Over Ethernet. Ethernet interface type: Gigabit Ethernet, Fast Ethernet, Ethernet LAN data rates: 10,1000,100 Mbit/s, Cabling technology: 10/100/1000. Product colour: Black, Housing material: Plastic, Maximum operating distance: 100 m. Output power: 30 W, AC adapter input voltage: 100 - 240 V, Input current: 1.5 A. Compliance certificates: RoHS. Width: 46 mm, Depth: 102 mm, Height: 25 mm
Network - Auto MDI/MDI-X - Yes
Network - Cabling technology - 10/100/1000
Network - Chipset - IC Plus - IP802AR
Network - Ethernet interface type - Gigabit Ethernet, Fast Ethernet
Network - Ethernet LAN data rates - 10,1000,100 Mbit/s
Network - Networking standards - IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3at
Network - Power over Ethernet (PoE) - Yes
Network - Web-based management - No
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 144 mm
Packaging data - Package height - 38 mm
Packaging data - Package weight - 105 g
Packaging data - Package width - 207 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - RJ-45 input ports - 2
Ports & interfaces - RJ-45 output ports - 2
Power - AC adapter input voltage - 100 - 240 V
Power - AC adapter output voltage - 52 V
Power - Input current - 1.5 A
Power - Output current - 1.25 A
Power - Output power - 30 W
Power - Power consumption (max) - 65 W
Power - Power plug type - Type M
Power - Suitable for use in country/location - Europe, United Kingdom
Power - Surge protection voltage - 2 kV
Power - Total Power over Ethernet (PoE) budget - 30 W
ProductName - 2-Port Gigabit Midspan PoE+ Injector, 10/100/1000Mbps, PoE+ (802.3af/at), 30W, 1Gbps Ethernet, Wall Mountable, Unmanaged Inline Power Over Ethernet
ShortSummaryDescription - StarTech.com 2-Port Gigabit Midspan PoE+ Injector, 10/100/1000Mbps, PoE+ (802.3af/at), 30W, 1Gbps Ethernet, Wall Mountable, Unmanaged Inline Power Over Ethernet, Gigabit Ethernet, Fast Ethernet, 10,1000,100 Mbit/s, 10/100/1000, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3at, IC Plus - IP802AR, Black
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - StarTech.com 2-Port Gigabit Midspan PoE+ Injector, 10/100/1000Mbps, PoE+ (802.3af/at), 30W, 1Gbps Ethernet, Wall Mountable, Unmanaged Inline Power Over Ethernet
URL - https://www.startech.com/en-us/AF221CE-POE-INJECTOR
WarrantyInfo - 2 Years
Weight & dimensions - Depth - 102 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Weight - 60 g
Weight & dimensions - Width - 46 mm
