Analog signal format system Performance - NTSC, PAL
Audio formats supported Performance -
Audio input Ports & interfaces - 1
Audio output Ports & interfaces - 1
Audio system Performance -
Bit rate Performance -
BNC input ports Ports & interfaces - 16
Brand -
BrandPartCode -
Built-in processor Processor - Yes
Category -
- STD
Certification Performance -
DC voltage Power - 12 V
Depth Weight & dimensions -
Description - Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions. Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, Cooper Series featuring SMD Plus to benefit customers from AI upgrade. The series are designated to reduce false-alarm rates and human surveillance costs, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities. SMD Plus
SMD Plus, referred to as Smart Motion Detection Plus, which is an upgrading version of SMD that greatly improves the alarm accuracy by loading deep-learning algorithm. It analyzes person and vehicle shapes based on motion detection and send alarms only when person and vehicle intrudes.
*SMD Plus takes effect when SMD or IVS&SMD is selected in AI Mode. AI Coding
Compared with H.265, AI codec can reduce up to 50% bit rate and storage requirements while have no loss of decoding compatibility, providing clear human and vehicle details. Smart H.265+
Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras. HDCVI/AHD/TVI/CVBS Auto-detect
The XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient. High Definition Camera Input
The XVR supports up to 1080p HDCVI camera and 6MP IP camera input. Coaxial Audio/Upgrade/Alarm
The integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation. Long Distance Transmission
The HDCVI system supports long distance transmission over coaxial cable and UTP, max. 700 m for 4K/4MP, 800 m for 1080p and 1200 m for 720p.H.265+/H.265 dual-stream video compressionSupports Full-channel AI-CodingSupports HDCVI/AHD/TVI/CVBS/IP video inputsMax 18 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps Incoming BandwidthLong transmission distance over coax cableUp to 8 channels video stream ( analog channel ) SMD Plus
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Network - 1
Ethernet LAN Network - Yes
GTIN -
-
- 6 TB
- 1
HDD interface Hard drive -
HDMI ports quantity Ports & interfaces - 1
Height Weight & dimensions - 47.6 mm
LongDesc -
LongProductName -
LongSummaryDescription -
Maximum HDD capacity Hard drive - 6 TB
Maximum video resolution Performance - 1920 x 1080 pixels
Model -
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Number of users - 128 user(s)
Network - Supported network protocols -
Number of HDDs supported Hard drive - 1
Number of users Network - 128 user(s)
Operating relative humidity (H-H) Operational conditions -
Operating system installed Performance - Embedded LINUX
Operating temperature (T-T) Operational conditions - -10 - 45 °C
Operational conditions - Operating relative humidity (H-H) -
Operational conditions - Operating temperature (T-T) - -10 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Performance - Analog signal format system - NTSC, PAL
Performance - Audio formats supported -
Performance - Audio system -
-
Performance - Certification -
Performance - Maximum video resolution - 1920 x 1080 pixels
Performance - Operating system installed - Embedded LINUX
-
Performance - Product colour - Black
- Yes
Performance - Rack capacity - 1U
-
Performance - Video compression formats -
- Yes
- Yes
Playback resolutions supported Performance -
Ports & interfaces - Audio input - 1
Ports & interfaces - Audio output - 1
Ports & interfaces - BNC input ports - 16
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - VGA (D-Sub) output ports - 1
- 16 channels
- 12 V
Power - Power consumption (typical) - 10 W
Power consumption (typical) Power - 10 W
Processor - Built-in processor - Yes
Product colour Performance - Black
ProductName -
PTZ control Performance - Yes
Rack capacity Performance - 1U
ShortSummaryDescription -
Storage relative humidity (H-H) Operational conditions - 0 - 90%
Storage temperature (T-T) Operational conditions - -20 - 70 °C
Summary -
Supported network protocols Network -
Title -
- 0.31
-
- 0.085
Unit Calculated Volume -
Unit Calculated Weight - 1.43 kg
Units per Shipping Box - 1
URL -
USB 2.0 ports quantity Ports & interfaces - 2
Vendor Homepage -
VGA (D-Sub) output ports Ports & interfaces - 1
Video capturing speed Performance -
Video compression formats Performance -
Video input channels Ports & interfaces - 16 channels
Video motion detection Performance - Yes
Video streaming Performance - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth -
Weight & dimensions - Height - 47.6 mm
Weight & dimensions - Weight - 890 g
Weight & dimensions - Width - 260 mm
Weight Weight & dimensions - 890 g
Width Weight & dimensions - 260 mm
