Analog signal format system Video - NTSC, PAL
Angle of rotation Camera - 360°
Audio - Audio input channels - 1.0 channels
Audio - Built-in microphone - Yes
Audio - Signal-to-Noise Ratio (SNR) - 65 dB
Audio input channels Audio - 1.0 channels
Back Light Compensation (BLC) Video - Yes
Bluetooth Network - No
BNC output ports Ports & interfaces - 1
Brand - Dahua Technology
BrandPartCode - HAC-HDW1231TLMQ-A-0280B
Built-in HDD Storage - No
Built-in microphone Audio - Yes
Camera - Angle of rotation - 360°
Camera - Camera pan control - Yes
Camera - Camera shutter type - Electronic
Camera - Camera tilt control - Yes
Camera - Lens viewing angle, diagonal - 127°
Camera - Lens viewing angle, horizontal - 107°
Camera - Lens viewing angle, vertical - 56°
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 78°
Camera - White balance - Auto
Camera pan control Camera - Yes
Camera shutter type Camera - Electronic
Camera tilt control Camera - Yes
Category - Security Cameras
Category Code - HSC
Closest focusing distance Lens system - 0.7 m
Connectivity technology Performance - Wired
Day/night mode Performance - Yes
DC-in jack Ports & interfaces - Yes
DC output voltage Power - 12
Description - Max 30 fps@1080pStarlight, 130 dB true WDR, 3D NR3.6 mm fixed lens (2.8 mm optional)CVI/CVBS/AHD/TVI switchableSuper AdaptBuilt-in mic(-A)Max. IR length 30m, Smart IRIP67, DC 12 VQuick-to-install saves installation time
Design - Form factor - Dome
Design - Housing material - Metal, Plastic
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling/Wall/Pole
Design - Product colour - White
Detect distance Lens system - 43.9 m
Diameter Weight & dimensions - 11 cm
Ethernet LAN Network - No
Fixed focal length Lens system - 2.8 mm
Form factor Design - Dome
Frame rate Video - 30 fps
Gain control type Video - Auto/Manual
GTIN - 6923172506658
Height Weight & dimensions - 88.1 mm
Highlight Compensation (HLC) Video - Yes
Housing material Design - Metal, Plastic
Identify distance Lens system - 4.4 m
Image sensor - Number of effective pixels (H x V) - 1920 x 1080 pixels
Image sensor - Optical sensor size - 25.4 / 2.8 mm (1 / 2.8")
Image sensor - Sensor type - CMOS
International Protection (IP) code Design - IP67
Lens system - Closest focusing distance - 0.7 m
Lens system - Detect distance - 43.9 m
Lens system - Fixed focal length - 2.8 mm
Lens system - Identify distance - 4.4 m
Lens system - Maximum aperture number - 1.6
Lens system - Observe distance - 17.5 m
Lens system - Recognize distance - 8.8 m
Lens viewing angle, diagonal Camera - 127°
Lens viewing angle, horizontal Camera - 107°
Lens viewing angle, vertical Camera - 56°
LongDesc -
LongProductName - Eyeball, 1920 x 1080, 2 MP, CMOS, 1/2.8", IP67, BNC port, BLC/WDR/HLC
LongSummaryDescription - Dahua Technology Lite HAC-HDW1231TLMQ-A-0280B. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Dome. Angle of rotation: 360°, Lens viewing angle, horizontal: 107°, Lens viewing angle, vertical: 56°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"), Number of effective pixels (H x V): 1920 x 1080 pixels. Detect distance: 43.9 m, Observe distance: 17.5 m, Recognize distance: 8.8 m
Manual Packaging content - Yes
Maximum aperture number Lens system - 1.6
Maximum resolution Video - 1920 x 1080 pixels
Mirror Security - Yes
Mounting type Design - Ceiling/Wall/Pole
Network - Bluetooth - No
Network - Ethernet LAN - No
Network - Wi-Fi - No
Noise reduction technology Video - 3D noise reduction
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of effective pixels (H x V) Image sensor - 1920 x 1080 pixels
Observe distance Lens system - 17.5 m
Operating temperature (T-T) Operational conditions - -40 - 60 °C
Operational conditions - Operating temperature (T-T) - -40 - 60 °C
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical sensor size Image sensor - 25.4 / 2.8 mm (1 / 2.8")
Package weight Packaging data - 450 g
Packaging content - Manual - Yes
Packaging content - Number of cameras - 1
Packaging data - Package weight - 450 g
Pan range Camera - 0 - 360°
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Placement supported - Outdoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Placement supported Performance - Outdoor
Ports & interfaces - BNC output ports - 1
Ports & interfaces - DC-in jack - Yes
Power - DC output voltage - 12
Power - Power consumption (max) - 3.1 W
Power - Power source type - DC
Power consumption (max) Power - 3.1 W
Power source type Power - DC
Privacy masking Video - Yes
Product colour Design - White
ProductName - HAC-HDW1231TLMQ-A-0280B
Recognize distance Lens system - 8.8 m
Security - Mirror - Yes
Sensor type Image sensor - CMOS
ShortSummaryDescription - Dahua Technology Lite HAC-HDW1231TLMQ-A-0280B, IP security camera, Outdoor, Wired, Ceiling/Wall/Pole, White, Dome
Signal-to-Noise Ratio (SNR) Audio - 65 dB
Smart IR Video - Yes
Storage - Built-in HDD - No
Storage temperature (T-T) Operational conditions - -40 - 60 °C
Summary - Dahua Technology Lite HAC-HDW1231TLMQ-A-0280B. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling/Wall/Pole, Product colour: White, Form factor: Dome. Angle of rotation: 360°, Lens viewing angle, horizontal: 107°, Lens viewing angle, vertical: 56°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"), Number of effective pixels (H x V): 1920 x 1080 pixels. Detect distance: 43.9 m, Observe distance: 17.5 m, Recognize distance: 8.8 m
Supported graphics resolutions Video - 960 x 480, 960 x 576, 1920 x 1080 (HD 1080)
Supported video modes Video - 480p, 576p, 1080p
Tilt angle range Camera - 0 - 78°
Title - Dahua Technology Lite HAC-HDW1231TLMQ-A-0280B security camera Dome IP security camera Outdoor 1920 x 1080 pixels Ceiling/Wall/Pole
Total megapixels Video - 2 MP
Type Performance - IP security camera
Unit Box Height - 0.12
Unit Box Length - 0.13
Unit Box Width - 0.11
Unit Calculated Volume - 0.001716 cubm
Unit Calculated Weight - 0.439 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/Starlight/HAC-HDW1231TLMQ(-A)
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/HDCVI-Cameras/Lite-Series/1080P/Starlight/HAC-HDW1231TLMQ(-A)
Video - Analog signal format system - NTSC, PAL
Video - Back Light Compensation (BLC) - Yes
Video - Frame rate - 30 fps
Video - Gain control type - Auto/Manual
Video - Highlight Compensation (HLC) - Yes
Video - Maximum resolution - 1920 x 1080 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Smart IR - Yes
Video - Supported graphics resolutions - 960 x 480, 960 x 576, 1920 x 1080 (HD 1080)
Video - Supported video modes - 480p, 576p, 1080p
Video - Total megapixels - 2 MP
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Diameter - 11 cm
Weight & dimensions - Height - 88.1 mm
Weight & dimensions - Weight - 280 g
Weight Weight & dimensions - 280 g
White balance Camera - Auto
Wi-Fi Network - No
Wide Dynamic Range (WDR) Performance - Yes
