Adjustment shutter speed Camera - Auto/Manual
Alarm input/output Performance - Yes
Alarm input channels Security - 1
Alarm output channels Security - 1
Angle of rotation Camera - 360°
Audio - Audio formats supported - G.711 A-law, G.726, PCM
Audio - Audio input channels - 1.0 channels
Audio - Audio output channels - 1.0 channels
Audio - Built-in microphone - Yes
Audio - Signal-to-Noise Ratio (SNR) - 56 dB
Audio formats supported Audio - G.711 A-law, G.726, PCM
Audio input channels Audio - 1.0 channels
Audio output channels Audio - 1.0 channels
Back Light Compensation (BLC) Video - Yes
Bit rate control Video - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate Video - 3 kbps-20480 kbps
Bluetooth Network - No
Brand - Dahua Technology
BrandPartCode - HFW3849T1-ASPV0280B-PRO-B
Built-in HDD Storage - No
Built-in microphone Audio - Yes
Camera - Adjustment shutter speed - Auto/Manual
Camera - Angle of rotation - 360°
Camera - Camera shutter speed - 1/3 - 1/100000 s
Camera - Camera shutter type - Electronic
Camera - Lens viewing angle, diagonal - 360°
Camera - Lens viewing angle, horizontal - 360°
Camera - Lens viewing angle, vertical - 90°
Camera - Minimum illumination - 0.007 lx
Camera - Number of Privacy masking areas - 4
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 90°
Camera - White balance - Auto, Manual, Natural, Outdoor, Street lamp
Camera shutter speed Camera - 1/3 - 1/100000 s
Camera shutter type Camera - Electronic
Card reader integrated Storage - Yes
Category - Security Cameras
Category Code - FNC
Certification Performance - CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive; 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B
Closest focusing distance Lens system - 4.4 m
CnCode - 85258900
Compatible memory cards Storage - MicroSD (TransFlash)
Connectivity technology Performance - Wired
Day/night mode Performance - Yes
DC output voltage Power - 12
Description - 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera8-MP 1/1.8" CMOS image sensor, low luminance, and high definition imageOutputs max. 8 MP (3840 ×2160)@25/30 fpsH.265 codec, high compression rate, ultra-low bit rateBuilt-in multi-core light, the max. IR distance is 50 m and the max. warm light distance is 50 m · ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environmentsRotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenesIntelligent monitoring: Intrusion, tripwire (the two function support the classification and accurate detection of vehicle and human), stay detection, loitering detection, face detection (full image)Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detectionAlarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 G Micro SD card; built-in dual MICs; 1-ch speaker; support two-way talk12 VDC/PoE power supplyIP67 protectionSound and light alarm (red and blue lights)SMD 4.0Supports AI SSA and one-tap arming and disarmingSMD area can be set in warm light areas that support triggering alarms
Design - Form factor - Bullet
Design - Housing material - Metal, Plastic
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling/wall
Design - Product colour - Black
Detect distance Lens system - 91 m
Dynamic range Performance - 120 dB
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Fixed focal length Lens system - 3.6 mm
Form factor Design - Bullet
Frame rate Video - 20 fps
Gain control type Video - Auto/Manual
Height Weight & dimensions - 84.7 mm
Highlight Compensation (HLC) Video - Yes
Housing material Design - Metal, Plastic
Identify distance Lens system - 9.1 m
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 1.8 mm (1 / 1.8")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Internal memory Storage - 512 MB
International Protection (IP) code Design - IP67
LED type Night vision - White
Length Weight & dimensions - 288.4 mm
Lens system - Closest focusing distance - 4.4 m
Lens system - Detect distance - 91 m
Lens system - Fixed focal length - 3.6 mm
Lens system - Identify distance - 9.1 m
Lens system - Number of lenses - 1
Lens system - Observe distance - 36.4 m
Lens system - Recognize distance - 18.2 m
Lens viewing angle, diagonal Camera - 360°
Lens viewing angle, horizontal Camera - 360°
Lens viewing angle, vertical Camera - 90°
Live view Network - Yes
LongDesc - 8MP WizColor TiOC PRO Fixed-focal Bullet WizSense Network Camera
LongProductName - 1/1.8" CMOS, 3840 (H) × 2160 (V), 256 MB, 1 GB, >56 dB
LongSummaryDescription - Dahua Technology WizSense IPC-HFW3849T1-AS-PV-PRO. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.007 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 360°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 91 m, Observe distance: 36.4 m, Recognize distance: 18.2 m
Maximum memory card size Storage - 256 GB
Maximum resolution Video - 3840 x 2160 pixels
Minimum illumination Camera - 0.007 lx
Mobile operating systems supported System requirements - Android, iOS
Model - HFW3849T1-ASPV0280B-PRO-B
Mounting type Design - Ceiling/wall
Network - Bluetooth - No
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Live view - Yes
Network - Networking standards - IEEE 802.3af
Network - Number of users - 20 user(s)
Network - Supported network protocols - IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Network - Wi-Fi - No
Networking standards Network - IEEE 802.3af
Night vision - LED type - White
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 2
Night vision distance Night vision - 30 m
Night vision Night vision - Yes
Noise reduction technology Video - 3D noise reduction
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of illumination LEDs Night vision - 2
Number of lenses Lens system - 1
Number of Privacy masking areas Camera - 4
Number of sensors Image sensor - 1
Number of users Network - 20 user(s)
Observe distance Lens system - 36.4 m
Operating relative humidity (H-H) Operational conditions - 0 - 95%
Operating temperature (T-T) Operational conditions - -40 - 60 °C
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 60 °C
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical sensor size Image sensor - 25.4 / 1.8 mm (1 / 1.8")
Packaging content - Number of cameras - 1
Pan range Camera - 0 - 360°
Performance - Alarm input/output - Yes
Performance - Certification - CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive; 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - Placement supported - Indoor & outdoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Placement supported Performance - Indoor & outdoor
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 76 W
Power - Power consumption (Power over Ethernet (PoE)) - 9.1 W
Power - Power consumption (typical) - 4.5 W
Power - Power source type - DC, PoE
Power consumption (max) Power - 76 W
Power consumption (Power over Ethernet (PoE)) Power - 9.1 W
Power consumption (typical) Power - 4.5 W
Power source type Power - DC, PoE
Privacy masking Video - Yes
Product colour Design - Black
ProductName - IPC-HFW3849T1-AS-PV-PRO
Progressive scan Image sensor - Yes
Recognize distance Lens system - 18.2 m
Region of Interest (ROI) encoding Video - Yes
ROM capacity Storage - 128 MB
Security - Alarm input channels - 1
Security - Alarm output channels - 1
Security - Video motion detection - Yes
Sensor type Image sensor - CMOS
ShortSummaryDescription - Dahua Technology WizSense IPC-HFW3849T1-AS-PV-PRO, IP security camera, Indoor & outdoor, Wired, 120 dB, CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive; 2014/30/EU; FCC: 47 CFR FCC..., Ceiling/wall
Signal-to-Noise Ratio (SNR) Audio - 56 dB
Smart IR Video - Yes
Storage - Built-in HDD - No
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Internal memory - 512 MB
Storage - Maximum memory card size - 256 GB
Storage - ROM capacity - 128 MB
Storage temperature (T-T) Operational conditions - -40 - 60 °C
Summary - Dahua Technology WizSense IPC-HFW3849T1-AS-PV-PRO. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: Black, Form factor: Bullet. Minimum illumination: 0.007 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 360°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 91 m, Observe distance: 36.4 m, Recognize distance: 18.2 m
Supported graphics resolutions Video - 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2304 x 1296, 2592 x 1944, 2668 x 1512, 2688 x 1512, 3072 x 1728, 3072 x 2048, 3840 x 2160
Supported network protocols Network - IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
System requirements - Mobile operating systems supported - Android, iOS
Tilt angle range Camera - 0 - 90°
Title - Dahua Technology WizSense IPC-HFW3849T1-AS-PV-PRO Bullet IP security camera Indoor & outdoor 3840 x 2160 pixels Ceiling/wall
Total megapixels Video - 8 MP
Type Performance - IP security camera
Unit Box Height - 0.136
Unit Box Length - 0.339
Unit Box Width - 0.148
Unit Calculated Volume - 0.0068234 cubm
Unit Calculated Weight - 1.47 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC-PRO-WizColor/IPC-HFW3849T1-AS-PV-PRO
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizSense-Series/3-Series/TiOC-PRO-WizColor/IPC-HFW3849T1-AS-PV-PRO
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate - 3 kbps-20480 kbps
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Frame rate - 20 fps
Video - Gain control type - Auto/Manual
Video - Highlight Compensation (HLC) - Yes
Video - Maximum resolution - 3840 x 2160 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Region of Interest (ROI) encoding - Yes
Video - Smart IR - Yes
Video - Supported graphics resolutions - 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2304 x 1296, 2592 x 1944, 2668 x 1512, 2688 x 1512, 3072 x 1728, 3072 x 2048, 3840 x 2160
Video - Total megapixels - 8 MP
Video - Video compression formats - H.264, H.264+, H.264B, H.265, H.265+
Video - Video formats supported - H.264, H.264+, H.264B, H.265, H.265+
Video - Video streaming - Yes
Video compression formats Video - H.264, H.264+, H.264B, H.265, H.265+
Video formats supported Video - H.264, H.264+, H.264B, H.265, H.265+
Video motion detection Security - Yes
Video streaming Video - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Height - 84.7 mm
Weight & dimensions - Length - 288.4 mm
Weight & dimensions - Width - 94.4 mm
White balance Camera - Auto, Manual, Natural, Outdoor, Street lamp
Wi-Fi Network - No
Wide Dynamic Range (WDR) Performance - Yes
Width Weight & dimensions - 94.4 mm
