ID: 876943
Product code: FPMA-C340DBLACK
In stock 1 units
Warranty: 3 years
Newstar Full motion dual TV/monitor ceiling mount, 32-75"
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Delivery by courier to the addressWithin 1-2 working days5.99 €
Main product parameters All parameters
- Maximum load (1 screen), kg: 50.00
- Maximum screen diagonal, inches: 75
- Minimum screen diagonal, inches: 32
All parameters
Colour
: Melna
Maximum load (1 screen), kg
: 50.00
Maximum screen diagonal, inches
: 75
Minimum screen diagonal, inches
: 32
Model
: FPMA-C340DBLACK
Notebook holder
: Nav
Number of supported screens
: 2
Rotation
: Not
Swivel
: Ir
Tilt
: Is
Type of attachment
: Griestu
VESA support
: 100 x 100, 200 x 100, 200 x 200, 300 x 300, 400 x 200, 400 x 300, 400 x 400
More detailed specification
Angle of rotation Ergonomics - 6°
Brand - Neomounts
BrandPartCode - FPMA-C340DBLACK
Cable management Ergonomics - Yes
Category - TV Mounts & Stands
Category Code - TMS
Country of origin Technical details - China
Description - NEOMOUNTS BY NEWSTAR BACK TO BACK SCREEN CEILING MOUNT (HEIGHT: 106-156 CM)
Description - The Neomounts FPMA-C340DBLACK is a full motion ceiling mount for 2 flat screens up to 75". The unique tilt (10°), swivel (360°) and rotate technology (6°) allows the mount to change to the best angle for the optimal viewing position. The ceiling mount can be easily adjusted in height from 106 to 156 cm* and has a weight capacity of 50 kg (2x). The FPMA-C340DBLACK is suitable for screens that meet VESA hole pattern 100x100 to 400x400mm. A nifty cable management systems conceals and routes cables from ceiling to screen. The mount comes with an additional cover for installation on suspended ceilings. * The Neomounts NS-EP100BLACK is an extension pole for ceiling mount models NM-C440BLACK, NM-C440DBLACK, FPMA-C340BLACK and FPMA-C340DBLACK. This pole can be used as extra extension to the pole included with the models. In this way, the height of the ceiling mounts can be increased with an extra 107,5 cm.
Design - Housing material - Steel
Design - Product colour - Black
Ergonomics - Angle of rotation - 6°
Ergonomics - Cable management - Yes
Ergonomics - Height adjustment - Yes
Ergonomics - Height adjustment range - 1060 - 1560 mm
Ergonomics - Height adjustment type - Manual
Ergonomics - Pivot angle - -3 - 3°
Ergonomics - Swivel angle - 360°
Ergonomics - Swivel angle range - -180 - 180°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -10 - 0°
GTIN - 8717371449445
Harmonized System (HS) code Logistics data - 7326909890
Height - 145.000000
Height adjustment Ergonomics - Yes
Height adjustment range Ergonomics - 1060 - 1560 mm
Height adjustment type Ergonomics - Manual
Height Weight & dimensions - 1785 mm
Housing material Design - Steel
Length - 930.000000
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 17.9 kg
Logistics data - Master (outer) case height - 310 mm
Logistics data - Master (outer) case length - 270 mm
Logistics data - Master (outer) case net weight - 14.5 kg
Logistics data - Master (outer) case width - 950 mm
Logistics data - Products per master (outer) case - 2 pc(s)
Logistics data - Products per pallet (EU) - 30 pc(s)
LongDesc - The Neomounts FPMA-C340DBLACK is a full motion ceiling mount for 2 flat screens up to 75". The unique tilt (10°), swivel (360°) and rotate technology (6°) allows the mount to change to the best angle for the optimal viewing position. The ceiling mount can be easily adjusted in height from 106 to 156 cm* and has a weight capacity of 50 kg (2x). The FPMA-C340DBLACK is suitable for screens that meet VESA hole pattern 100x100 to 400x400mm. A nifty cable management systems conceals and routes cables from ceiling to screen. The mount comes with an additional cover for installation on suspended ceilings.* The Neomounts NS-EP100BLACK is an extension pole for ceiling mount models NM-C440BLACK, NM-C440DBLACK, FPMA-C340BLACK and FPMA-C340DBLACK. This pole can be used as extra extension to the pole included with the models. In this way, the height of the ceiling mounts can be increased with an extra 107,5 cm.
LongProductName - Neomounts FPMA-C340DBLACK Monitor/TV mount ceiling 2 screens - 32-75" - max 50 kg/screen - VESA 100x100-400x400 - h 106-156 cm - black
LongSummaryDescription - Neomounts FPMA-C340DBLACK Dual monitor/TV mount ceiling 32-75" - h 106-156 cm. Maximum weight capacity: 50 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 190.5 cm (75"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 400 x 400 mm. Height adjustment range: 1060 - 1560 mm, Tilt angle range: -10 - 0°, Swivel angle range: -180 - 180°, Angle of rotation: 6°. Product colour: Black
Manufacturer - Neomounts
ManufacturerPartNumber - FPMA-C340DBLACK
Master (outer) case gross weight Logistics data - 17.9 kg
Master (outer) case height Logistics data - 310 mm
Master (outer) case length Logistics data - 270 mm
Master (outer) case net weight Logistics data - 14.5 kg
Master (outer) case width Logistics data - 950 mm
Maximum screen size Mounting - 190.5 cm (75")
Maximum VESA mount Mounting - 400 x 400 mm
Maximum weight capacity (per display) Mounting - 50 kg
Maximum weight capacity Mounting - 50 kg
Minimum screen size Mounting - 81.3 cm (32")
Minimum VESA mount Mounting - 100 x 100 mm
Model - FPMA-C340DBLACK
Mounting - Maximum screen size - 190.5 cm (75")
Mounting - Maximum VESA mount - 400 x 400 mm
Mounting - Maximum weight capacity - 50 kg
Mounting - Maximum weight capacity (per display) - 50 kg
Mounting - Minimum screen size - 81.3 cm (32")
Mounting - Minimum VESA mount - 100 x 100 mm
Mounting - Mounting type - Ceiling
Mounting - Number of displays supported - 2
Mounting - Panel mounting interface - 100 x 100,200 x 100,200 x 200,300 x 300,400 x 200,400 x 400
Mounting type Mounting - Ceiling
Number of displays supported Mounting - 2
Orientation Technical details - Landscape
Package depth Packaging data - 250 mm
Package height Packaging data - 145 mm
Package weight Packaging data - 8.5 kg
Package width Packaging data - 930 mm
Packaging data - Package depth - 250 mm
Packaging data - Package height - 145 mm
Packaging data - Package weight - 8.5 kg
Packaging data - Package width - 930 mm
Panel mounting interface Mounting - 100 x 100,200 x 100,200 x 200,300 x 300,400 x 200,400 x 400
PeriodofWarranty - 5 Y
Pivot angle Ergonomics - -3 - 3°
Product colour Design - Black
ProductName - Neomounts FPMA-C340DBLACK Dual monitor/TV mount ceiling 32-75" - h 106-156 cm
Products per master (outer) case Logistics data - 2 pc(s)
Products per pallet (EU) Logistics data - 30 pc(s)
Short summary - Neomounts FPMA-C340DBLACK Monitor/TV mount ceiling 2 screens - 32-75" - max 50 kg/screen - VESA 100x100-400x400 - h 106-156 cm - black
ShortSummaryDescription - Neomounts FPMA-C340DBLACK Dual monitor/TV mount ceiling 32-75" - h 106-156 cm, 100 x 100 mm, 400 x 400 mm, -10 - 0°, -180 - 180°, 6°, Black
Stand/mount type - Ceiling
Summary - Neomounts FPMA-C340DBLACK Dual monitor/TV mount ceiling 32-75" - h 106-156 cm. Maximum weight capacity: 50 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 190.5 cm (75"), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 400 x 400 mm. Height adjustment range: 1060 - 1560 mm, Tilt angle range: -10 - 0°, Swivel angle range: -180 - 180°, Angle of rotation: 6°. Product colour: Black
Swivel angle Ergonomics - 360°
Swivel angle range Ergonomics - -180 - 180°
Swivelling Ergonomics - Yes
Technical details - Country of origin - China
Technical details - Orientation - Landscape
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -10 - 0°
Title - Neomounts FPMA-C340DBLACK Dual monitor/TV mount ceiling 32-75" - h 106-156 cm
Unit Box Height - 0.25
Unit Box Length - 0.93
Unit Box Width - 0.15
Unit Calculated Volume - 0.03488 cubm
Unit Calculated Weight - 8.55 kg
Units per Shipping Box - 1
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-C340DBLACK
Vendor Homepage - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-C340DBLACK
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 8.530000
Weight & dimensions - Height - 1785 mm
Weight & dimensions - Weight - 7.26 kg
Weight Weight & dimensions - 7.26 kg
Wheels - No
Width - 252.000000
