Cooler Master TD500 V2 Mesh, Tempered Glass, White

Air Duct - No
Category 1 - Gehäuse
Category 2 - Midi-/Mini-Tower
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
category_en - Computers & Components > Computer components > PC Cases
category_lv - Datortehnika > Datoru komponentes > Datoru korpusi
category_ru - Datortehnika > Datoru komponentes > Datoru korpusi
Chassis type - Midi Tower
Code - TD500V2-WGNN-S00
Color - White
Cooling > Front fans diameters supported - 3x 120mm, 2x 140mm mm
Cooling > Rear fans diameters supported - 1x 120mm mm
Description - FineMesh Performance Front Panel
Polygonal FineMesh features a 3D contour and is also capable of simultaneously providing high airflow and dust filtration.
AVAILABLE IN BOTH BLACK & WHITE COLORATIONS
MasterBox TD500 Mesh V2 is available in both black and white so you can choose the color that best matches your setup! Three CF120 ARGB Fans Included Pre-installed CF120 ARGB fans provide ample airflow, ensuring low temperatures, high performance, and eye-catching aesthetics during even the most intense gaming sessions.
USB 3.2 GEN 2 TYPE C SUPPORT
USB 3.2 Gen 2 Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.
ARGB/FAN HUB Included
The included controller allows users to manage systems lighting independently from the hardware configuration and provides the user with 4 additional fan headers in case of need.
REMOVABLE TOP PANEL
The top panel is entirely removable for improved access during assembly and ease of mounting of cooling solutions.
TOOL-FREE CRYSTALLINE TG SIDE PANEL
Featuring a crystalline tempered glass side panel, completely toolless for quick access to the internals.
Versatile Cooling Options
Support for up to seven 120mm fans and 360mm front and top radiator support ensure that performance is not compromised.
PSU SHROUD WITH REMOVABLE COVER
MasterBox TD500 Mesh V2s removable PSU cover allows users to freely decide whether to showcase or keep their PSUs hidden.
HARDWARE COMPATIBILITY
MasterBox TD500Mesh V2 is natively compatible with ITX, M-ATX and ATX motherboards.
E-ATX motherboards, such as SSI-CEB models, are compatible with dimensions up to 12" x 10.7".
description_en - Type: PCForm Factor: Midi TowerSupported Motherboard Form Factors: EATX, Mini-ITX, SSI CEB, Micro ATX, ATX3.5" Drive Bays: 22.5" Drive Bays: 35.25" Drive Bays: 0Side Window: YesMaterial: Mesh, Steel, Plastic, Tempered GlassProduct Color: WhiteLighting: YesDust Filter: YesLight Color: MultiMaximum CPU Cooler Height: 165 mmMaximum Graphics Card Length: 410 mmExpansion Slots: 7Maximum PSU Length: 200 mmLighting Position: Case FansEnhanced Cable Management: Yes
Power SupplyPower Supply Included: NoPSU Mount Position: BottomSupported PSU Form Factors: ATX
ConnectivityUSB 2.0 Ports: 0USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports: 2USB 3.2 Gen 2 (3.1 Gen 2) Type-C Ports: 1Audio In: YesAudio Out: YesUSB 3.2 Gen 2 (3.1 Gen 2) Type-A Ports: 0
CoolingInstalled Front Fans: 3x 120 mmMaximum Front Fans: 3Supported Front Fan Sizes: 140, 120Supported Rear Fan Sizes: 120Supported Top Fan Sizes: 140, 120Maximum Rear Fans: 1Maximum Top Fans: 3Rear Radiator Sizes Supported: 120Front Radiator Sizes Supported: 240, 280, 120, 360, 140Top Radiator Sizes Supported: 280, 140, 360, 240, 120
StorageSupported Drive Sizes: 3.5, 2.5
Weight & DimensionsWeight: 7.7 kgHeight: 500 mmWidth: 210 mmDepth: 499 mm
Package InformationPackage Weight: 9200 gPackage Depth: 558 mmPackage Height: 584 mmPackage Width: 290 mm
Additional InformationVolume: 50 L
description_lv - Tips: PC (dators)Formas faktors: Midi TowerAtbalstāmie mātesplates formas faktori: EATX, Mini-ITX, SSI CEB, Micro ATX, ATX3.5" nodalījumu skaits: 22,5" izmēra laidumu skaits: 35.25" nodalījumu skaits: 0Sāna logs: JāMateriāls: Tīklaudums, Tērauds, Plastmasa, Rūdītā stiklaProdukta krāsa: BaltsIluminācija: JāFiltrs pret putekļiem: JāGaismas krāsa: MultiMaksimālais CPU vēsinātāja augstums: 165 mmMaksimālais grafiskās kartes garums: 410 mmPaplašināšanas slotu skaits: 7Maksimālais strāvas piegādes vienības garums: 200 mmGaismas novietojums: Case fansUzlabota kabeļu pārvaldība: Jā
Enerģijas padeveStrāvas barošana iekļauta: NēStrāvas piegādes vieta: ApakšaIespējamie barošanas piegādes tipu faktori: ATX
SavienojamībaUSB 2.0 pieslēgvietu skaits: 0USB 3.2 Gen 1 (3.1 Gen 1) A tipa pieslēgvietu skaits: 2USB 3.2 Gen 2 (3.1 Gen 2) C tipa pieslēgvietu skaits: 1Audio ieeja: JāAudio izeja: JāUSB 3.2 Gen 2 (3.1 Gen 2) A tipa pieslēgvietu skaits: 0
DzesēšanaUzstādītie priekšējie ventilatori: 3x 120 mmMaksimālais priekšējo ventilatoru skaits: 3Atbalstītie priekšējo ventilatoru diametri: 140, 120Atbalstītie aizmugures ventilatoru izmēri: 120Atbalstītie augšējo ventilatoru izmēri: 140, 120Maksimālais aizmugures ventilatoru skaits: 1Maksimālais augšējo ventilatoru skaits: 3Rear radiator sizes supported: 120Front radiator sizes supported: 240, 280, 120, 360, 140Top radiator sizes supported: 280, 140, 360, 240, 120
Datu uzglabāšanas līdzekļiAtbalstāmie cietā diska izmēri: 3.5, 2.5
Svars & dimensijasSvars: 7.7 kgAugstums: 500 mmPlatums: 210 mmDziļums: 499 mm
Informācija par iepakojumuIepakojuma svars: 9200 gIepakojuma dziļums: 558 mmIepakojuma augstums: 584 mmIepakojuma platums: 290 mm
Papildus informācijaSkaļums: 50 L
description_ru - Тип: ПКФорм-фактор: Midi TowerПоддерживаемые форм-факторы материнской платы: EATX, Mini-ITX, SSI CEB, Micro ATX, ATXОтсеки 3.5": 2Отсеки 2.5": 3Отсеки 5.25": 0Боковое окно: ДаМатериал: Сетка, Сталь, Пластик, Закалённое стеклоЦвет изделия: БелыйПодсветка: ДаФильтр от пыли: ДаЦвет подсветки: МногоцветныйМаксимальная высота кулера CPU: 165 ммМаксимальная длина видеокарты: 410 ммСлоты расширения: 7Максимальная длина блока питания: 200 ммРасположение подсветки: Вентиляторы корпусаПродвинутое управление кабелями: Да
ЭлектропитаниеБлок питания включён: НетПоложение блока питания: ВнизуПоддерживаемые форм-факторы БП: ATX
ПодключенияПорты USB 2.0: 0Порты USB 3.2 Gen 1 (3.1 Gen 1) Type-A: 2Порты USB 3.2 Gen 2 (3.1 Gen 2) Type-C: 1Аудиовход: ДаАудиовыход: ДаПорты USB 3.2 Gen 2 (3.1 Gen 2) Type-A: 0
ОхлаждениеУстановленные передние вентиляторы: 3x 120 ммМаксимум передних вентиляторов: 3Поддерживаемые размеры передних вентиляторов: 140, 120Поддерживаемые размеры задних вентиляторов: 120Поддерживаемые размеры верхних вентиляторов: 140, 120Максимум задних вентиляторов: 1Максимум верхних вентиляторов: 3Поддерживаемые радиаторы сзади: 120Поддерживаемые радиаторы спереди: 240, 280, 120, 360, 140Поддерживаемые радиаторы сверху: 280, 140, 360, 240, 120
Хранение данныхПоддерживаемые размеры дисков: 3.5, 2.5
Вес и размерыВес: 7.7 кгВысота: 500 ммШирина: 210 ммГлубина: 499 мм
Информация о упаковкеВес упаковки: 9200 гГлубина упаковки: 558 ммВысота упаковки: 584 ммШирина упаковки: 290 мм
ДополнительноОбъём: 50 л
Design > Colour of product - White
Design > Form factor - Mid Tower
Design > Material - Tempered Glass, Mesh, Plastic
Design > Side window - Yes
Designation - CE+WEEE
dimension depth - 290 mm
dimension height - 580 mm
Dimensions - 499 x 210 x 500mm
dimension weight - 9000 g
dimension width - 555 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 3
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 2
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
EAN - 4719512135358
ean - 4719512135358
EAN_code - 4719512135358
Fan - 12 cm
Features > Compatibility - Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature)
Form-factor - ATX
Form-factor - E-ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x USB 3.1 Typ C
Front panel connectors - 2 x USB 3.0
gross_weight - 9.2 kg
guarantee - 24
guarantee_type - normal
Link - https://www.coolermaster.com/catalog/cases/mid-tower/masterbox-td500-mesh-v2/
Manufacturer - Cooler Master
Manufacturer_code - TD500V2-WGNN-S00
Model -
MPN - TD500V2-WGNN-S00
Name - CoolerMaster MasterBox TD500 ARGB V2 White
Name - Cooler Master MasterBox TD500 Mesh V2, tower case (white, tempered glass)
Name - Cooler Master | MasterBox TD500 Mesh V2 | Side window | White | Mid Tower | ATX
name - PC Case MasterBox TD500 V2 Mesh with window ARG
No. of drive bays - 5
Other features -
Other features > Drive bays - 2 x 3.5", 3 x 2.5"
Other features > Expansion slots - 7
Other features > Power supply type - ATX
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 499.00 mm
Package features > Gross depth master carton - 240.00 mm
Package features > Gross height (mm) - 500.00 mm
Package features > Gross height master carton - 470.00 mm
Package features > Gross width (mm) - 210.00 mm
Package features > Gross width master carton - 570.00 mm
Package features > Net weight master carton - 5.40 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 5 pc(s)
Package features > Paper/Pasteboard - 2500 g
Package features > Plastic (No PET) - 500 g
Package features > Tare weight (kg) - 3.00 kg
Package features > Tare weight master carton - 1.10 kg
Package features > Volume (m3) - 0.05 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Ports & interfaces > Audio input - 1x Audio Jack
Ports & interfaces > Audio output - 1x Audio Jack
Power supply > Power supply included - No
Power supply > Power supply location - Bottom
producer - Cooler Master
Producer - Cooler Master
Producer product name - MasterBox TD500 Mesh V2
Side panel - Yes
Technical details > Gross weight - 14.00 kg
Technical details > Net weight - 11.00 kg
Technical details > Other features - 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C, Polygonal FineMesh Front Panel, Three CF120 ARGB Fans Included, Tool-Free Crystalline TG Side Panel, PSU Shroud With Removable Cover, ARGB Controller Included, Removable Top Panel, Removable HDD cage
Technical details > Producer - Cooler Master
Technical details > Warranty - 24 month(s)
title_en - Cooler Master MasterBox TD500 Mesh V2 Computer case Midi Tower White
title_lv - Cooler Master MasterBox TD500 Mesh V2 Datora korpuss Midi Tower Balts
title_ru - Cooler Master MasterBox TD500 Mesh V2 Компьютерный корпус Midi Tower Белый
vendpn - TD500V2-WGNN-S00
Warranty - 24
Weight - 7.7 kg
weight - 7.7 kg
Weight - 9,00
Weight & dimensions > Depth - 43 cm
Weight & dimensions > Height - 47.7 cm
Weight & dimensions > Width - 21 cm
