Brand - Chieftec
BrandPartCode - BX-10B-OP
Category - Computer Cases
Category - Root/Electronics/PC parts/Computer casings
Category 1 - Gehäuse
Category 2 - Midi-/Mini-Tower
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
Chassis type - Mini Tower
Chłodzenie: Możliwość montażu - 5 wentylatorów 120 mm
Chłodzenie: Obsługiwane radiatory - 240mm
Chłodzenie: Zainstalowane komponenty - 1 wentylator 120mm
Color - Black
Cooling - Bottom fans diameters supported - 120 mm
Cooling - Bottom fans diameters supported - 120,140 mm
Cooling - Bottom fans diameters supported - 140 mm
Cooling - Liquid cooling capability - Yes
Cooling - Liquid cooling installed - No
Cooling - Number of bottom fans supported (max) - 3
Cooling - Number of rear fans supported (max) - 1
Cooling - Number of top fans supported (max) - 2
Cooling - Rear fans diameters supported - 120
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear fans installed - 1x 120 mm
Cooling - Top fans diameters supported - 120
Cooling - Top fans diameters supported - 120,140 mm
Cooling - Top fans diameters supported - 140 mm
Cooling - Top radiator sizes supported - 240
Cooling - Top radiator sizes supported - 240 mm
Dane fizyczne: Głębokość - 415 mm
Dane fizyczne: Rodzaj materiału - stal
Dane fizyczne: Szerokość - 204 mm
Dane fizyczne: Waga - 4.78 kg
Dane fizyczne: Wysokość - 325 mm
Dane techniczne: Grupa produktowa - Obudowy komputerowe Chieftec
Dane techniczne: Gwarancja - 2 lata w serwisie sprzedawcy
Dane techniczne: Kolor - czarny
Dane techniczne: Panel boczny - przeźroczysty
Dane techniczne: Producent - Chieftec
Dane techniczne: Standard - micro-ATX
Dane techniczne: Standard - mini-ITX
Dane techniczne: Typ obudowy - Mini Tower
Description - BX-10B-OP enclosure Compact, modern m-ATX case Optimized cooling options Supports 240mm Radiator 1x 120mm fan installed CHIEFTEC BX-10B-OP is a modern, compact housing that combines elegant design with high functionality and ease of assembly. Featuring standard ATX PSU compatibility, m-ATX boards and gaming cards with a maximum length of 380mm, as well as a total of 6 possible fans, modern configurations should have no problems installing in a BX-10B-OP with enough space and good cooling .
Design - Anti-dust filter - Yes
Design - Form factor - Tower
Design - Full-Height expansion slots - 4
Design - Illumination - No
Design - Material - Carbon steel
Design - Material - SPCC
Design - Material - SPCC, Carbon steel
Design - Maximum CPU cooler height - 16.5 cm
Design - Maximum graphics card length - 38 cm
Design - Number of 2.5" bays - 4
Design - Number of 3.5" bays - 1
Design - Number of expansion slots - 4
Design - On/off button - Yes
Design - Product colour - Black
Design - Side window - Yes
Design - Supported motherboard form factors - micro ATX
Design - Supported motherboard form factors - micro ATX, Mini-ITX
Design - Supported motherboard form factors - Mini-ITX
Design - Tempered glass panel(s) - Yes
Design - Type - PC
Designation - CE+WEEE
dimensionalWeight - 11020
dimension depth - 485 mm
dimension height - 410 mm
Dimensions - 415 x 204 x 325 + (15mm legs)
dimension weight - 5480 g
dimension width - 275 mm
Drive bays 2.5'' extern. - 0
Drive bays 2.5'' intern. - 4
Drive bays 3.5'' extern. - 0
Drive bays 3.5'' intern. - 1
Drive bays 5.25'' extern. - 0
Drive bays 5.25'' intern. - 0
ean - 753263078063
EAN - 0753263078063
Eans - 753263078063
Fan - 12 cm
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x USB 3.0
Front panel connectors - 1 x USB Typ C
GTIN - 753263078063
GTIN - 0753263078063
guarantee - 24
guarantee_type - normal
Kieszenie na dyski: Ilość kieszeni 2.5 wewn. - 2 szt.
Kieszenie na dyski: Ilość kieszeni 3.5 wewn. - 2 szt.
LongDesc - The CHIEFTEC BX-10B-OP is a modern, compact mini tower that combines elegant and subtle design with high functionality and easy-installation for a capable system. Featuring standard ATX PSU compatibility, m-ATX boards and graphics cards up to a maximum length of 380mm, as well as a total of 6 possible installed fans, modern configurations should have no trouble being installed into the BX-10B-OP from a space or cooling perspective.
LongProductName - BX-10B-OP, m-ATX, 120mm PWM fan pre-installed, 0.6mm SPCC, 415 x 204 x 325mm, 4.78 kg, black
LongSummaryDescription - Chieftec BX-10B-OP. Form factor: Tower, Type: PC, Product colour: Black. Rear fans installed: 1x 120 mm, Rear fans diameters supported: 120 mm, Top fans diameters supported: 120,140 mm. Supported HDD sizes: 2.5,3.5". Width: 204 mm, Depth: 415 mm, Height: 325 mm. Package weight: 5.48 kg
Manufacturer - Chieftec
Manufacturer_code - BX-10B-OP
MPN - BX-10B-OP
Name - Chieftec BX-10B-OP
Name - Chieftec BX-10B-OP, tower case (black)
name - Chieftec BX-10B-OP Mini Tower Black
Name - Midi Chieftec BX-10B-OP
No. of drive bays - 5
Other features - Material: 0.6mm SPCC PCI Slots: 4 CPU Cooler height (max.): 165mm VGA card length (max.): 380mm (300mm if PSU > 180mm) Fans (optional): Front: 3x 120mm or 2x 140mm (140mm only with ITX motherboard) Rear: 1x 120mm fan Top: 2x 120mm or 2x 140mm fans or 240mm radiator
Packaging data - Package weight - 5.48 kg
Panel przedni: Złącza na przednim panelu - 1 x USB 3.2 Gen 1
Panel przedni: Złącza na przednim panelu - 1 x USB 3.2 Gen 1 (Typ-C)
Panel przedni: Złącza na przednim panelu - audio
Ports & interfaces - Audio output - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Power supply - Power supply included - No
Producent: Nazwa producenta / importera - ChieftecArena Electronic GmbHKoppersstr. 1840549 DuesseldorfEmail: info@chieftec.eu
producer - Chieftec
Producer - Chieftec
producerCode - BX-10B-OP
ProducerCode - BX-10B-OP
ProductName - BX-10B-OP
productName - Chieftec BX-10B-OP computer case Mini Tower Black
productSize - Normal
Przestrzeń na komponenty: Maksymalna długość karty graficznej - 38 cm (30 cm, jeśli zasilacz > 180 mm)
Przestrzeń na komponenty: Maksymalna wysokość chłodzenia - 16.5 cm
Safety warning - Warnings - Beware of sharp edges during assembly.
Safety warning - Warnings - Ensure that the enclosure is properly ventilated to avoid overheating of components.
Safety warning - Warnings - Keep the product away from water sources to prevent electrical damage.
ShortDescription - Micro ITX | czarna | bez zasilacza | 1x USB3.2 Gen1 Type-A, 1x USB 3.2 Gen1 | 415mm x 204mm x 325mm |
ShortSummaryDescription - Chieftec BX-10B-OP, Tower, PC, Black, micro ATX, Mini-ITX, SPCC, Carbon steel, 16.5 cm
sizeX - 480
sizeY - 280
sizeZ - 410
Storage - Supported HDD sizes - 2.5
Storage - Supported HDD sizes - 2.5,3.5"
Storage - Supported HDD sizes - 3.5"
Technical details - Compliance certificates - CE
Technical details - Compliance certificates - CE, RoHS
Technical details - Compliance certificates - RoHS
Technical details - Sustainability compliance - Yes
Technical details - Warranty period - 2 year(s)
Title - Chieftec BX-10B-OP computer case Tower Black
URL - https://www.chieftec.eu/products-detail/538/BX-10B-OP
vendpn - BX-10B-OP
WarrantyInfo - 24 Months
warrantyLength - 24
warrantyType - G
Weight - 4.78 kg
Weight - 5,60
Weight - 5.6
weight - 5500
Weight & dimensions - Depth - 415 mm
Weight & dimensions - Height - 325 mm
Weight & dimensions - Material thickness - 0.6 mm
Weight & dimensions - Weight - 4.78 kg
Weight & dimensions - Width - 204 mm
Zasilacz: Standard zasilacza - ATX
Zasilacz: Wbudowany zasilacz - brak w komplecie
