3.5" External Drive Bays - 1
3.5" Internal Drive Bays - 3
5.25" External Drive Bays - 2
ATX Mainboard Form Factor - Yes
Audio-Out Input/Output connectors - 1
Brand - Chieftec
BrandPartCode - HQ-01B-OP
Case Type - MidiTower
Category - Computer Cases
Category 1 - Gehäuse
Category 2 - Midi-/Mini-Tower
Category Code - CAS
Category_1 - Computers and Laptops
Category_2 - Computers - Accessories
Colour - Black
Cooling - Front fans diameters supported - 120 mm
Cooling - Number of front fans supported (max) - 1
Cooling - Number of rear fans supported (max) - 2
Cooling - Number of side fans supported (max) - 2
Cooling - Rear fans diameters supported - 80 mm
Cooling - Side fans diameters supported - 120 mm
Description - The solid and eye-catching mATX / ATX solution for users with a feel for value and quality! The “state-of-the-art” and modern hairbrush designed front panel blends timeless into both corporate and home environments, adding value to the user and his environment. By offering a vast array of installation and expansion slots as well as connectivity, the Midi-Tower serves perfectly as a main-stream solution and stands out.
Design - Form factor - Midi Tower
Design - Material - SECC
Design - Maximum CPU cooler height - 12 cm
Design - Maximum graphics card length - 25 cm
Design - Number of 3.5" bays - 4
Design - Number of 5.25" bays - 2
Design - Number of external 5.25" bays - 2
Design - Number of internal 3.5" bays - 3
Design - Product colour - Black
Design - Side window - No
Design - Supported motherboard form factors - ATX, micro ATX
Design - Type - PC
Dimensions - 428mm x 160mm x 410mm
EAN - 4710713234574
EAN_code - 4710713234574
Full Description Line - MidiTower|Dimensions 428mm x 160mm x 410mm
GTIN - 4710713234574
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - The solid and eye-catching mATX / ATX solution for users with a feel for value and quality!The “state-of-the-art” and modern hairbrush designed front panel blends timeless into both corporate and home environments, adding value to the user and his environment. By offering a vast array of installation and expansion slots as well as connectivity, the Midi-Tower serves perfectly as a main-stream solution and stands out.
LongProductName - mATX / ATX, Drive Bays ext.: 2x 5.25" / 1x 3.5", Drive Bays int.: 3x 3.5", 2x USB3.0, Mic-in, Audio-out
LongSummaryDescription - Chieftec HQ-01B-OP. Form factor: Midi Tower, Type: PC, Product colour: Black. Supported power supply form factors: ATX. Front fans diameters supported: 120 mm, Side fans diameters supported: 120 mm, Rear fans diameters supported: 80 mm. Supported HDD sizes: 3.5". Width: 160 mm, Depth: 428 mm, Height: 410 mm
Manufacturer - Chieftec
Manufacturer_code - HQ-01B-OP
MicroATX Mainboard Form Factor - Yes
Microphone Input/Output connectors - 1
MPN - HQ-01B-OP
Name - Chieftec HQ-01B-OP - Tower Enclosure - black
Name - Midi Chieftec Elox Serie HQ-01B-OP
Ports & interfaces - Audio input - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Power supply - Power supply included - No
Power supply - Supported power supply form factors - ATX
ProductName - HQ-01B-OP
Product Net Weight - 4.5 kg
Shipping Box Depth Shipping/Package Box Dimensions - 50 cm
Shipping Box Height Shipping/Package Box Dimensions - 46.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 4.5 kg
Shipping Box Width Shipping/Package Box Dimensions - 21 cm
ShortSummaryDescription - Chieftec HQ-01B-OP, Midi Tower, PC, Black, ATX, micro ATX, SECC, 12 cm
Storage - Supported HDD sizes - 3.5"
Technical_details - external: 2x 5.25", 1x 3.5" Internal: 3x 3.5" Front I/O: 2x USB-A 3.0, 1x microphone, 1x headphone PCI-slots: 7 Fan(s) (front): 1x 120mm (optional) Fan(s) (rear): 2x 80mm (optional) Fans (left): 2x 120mm (optional) Fans right: not available Fan(s) (top): not available Fan(s) (bottom): not available Fans (other): not available Motherboard: to ATX Power supply: ATX Power supply position: top CPU Coolers: to max. 120mm height Graphics Cards: to max. 250mm Colour: black Dimensions (WxHxD): 160x410x428mm (Stands: +15mm) Capacity: 28.08l Weight: 4.50kg
Title - Chieftec HQ-01B-OP computer case Midi Tower Black
Unit Box Height - 0.465
Unit Box Length - 0.5
Unit Box Width - 0.21
Unit Calculated Volume - 0.04883 cubm
Unit Calculated Weight - 4.5 kg
Units per Shipping Box - 1
URL - https://www.chieftec.eu/en/chassis/atx/elox-series/hq-01b.html
USB 3.0 Input/Output connectors - 2
Vendor Homepage - www.chieftec.eu/en/chassis/atx/elox-series/hq-01b.html
Warranty - 24 months
WarrantyInfo - 24 Month
Weight - 4,50
Weight - 4.38
Weight & dimensions - Depth - 428 mm
Weight & dimensions - Height - 410 mm
Weight & dimensions - Material thickness - 0.6 mm
Weight & dimensions - Weight - 4.5 kg
Weight & dimensions - Width - 160 mm
