Thermaltake AX500 Full Tower, Tempered Glass, Black

Name: Thermaltake AX500 Full Tower, Tempered Glass, Black
Brand: Thermaltake
SKU: 1233898
Price: 219.54 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1233898 Product code: CA-11D-00F1WN-00

Can be ordered 5 units Availability: 14 days after order approval

Warranty: 3 years

Compare

Ready for dispatch

23.10.2026

starting from 5.99 € with VAT

Delivery options

Delivery by courier to the address

Within 1-2 working days

5.99 €

Main product parameters All parameters

Form factor: Extended ATX
Case type: High-End
Color: Black
PSU: None

All parameters

Form factor : Extended ATX

Case type : High-End

Color Black

The colour of the front panel of the housing. This parameter is approximate and may differ from the actual colour of the housing.

Side panel type : Tempered Glass

PSU : None

Max. CPU cooler height, mm : 185

Max. radiator size, mm : 420

Max. Video card length, mm : 460

2.5" internal HDD/SSD bays : 1

3.5" internal HDD bays : 5

5.25" external drive bays : 0

3.5" FDD drive bays : 0

USB 2.0 Ports : 0

USB 3.0 ports : 2

USB Type-C ports : 1

Number of fans : 4

More detailed specification

Category 1 - Gehäuse
Category 2 - Midi-/Mini-Tower
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
Chassis type - Big Tower
Color - Black
Compatible power supply standard - ATX
Computer case backlight - No
Description - AX500 Full Tower Chassis The AX500 Full Tower Chassis supports E-ATX/SSI-EEB motherboards, dual 420mm radiators, and up to fourteen 120mm fans for optimal airflow. It features a graphics card holder to prevent sagging and two drive cages beneath the PSU cover, ideal for high-performance workstations or gaming setups.
Designation - CE+WEEE
dimension depth - 365 mm
dimension height - 655 mm
Dimensions - 550 x 248 x 548 mm
dimension weight - 15000 g
dimension width - 640 mm
Drive bays 2.5'' intern. - 6
Drive bays 3.5'' intern. - 5
ean - 4711475648425
EAN - 4711475648425
EAN_code - 4711475648425
Fans installed - 1 x 120 mm (back)
Fans installed - 3 x 140 mm (front)
Form-factor - ATX
Form-factor - E-ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Form-factor - SSI-CEB
Form-factor - SSI-EEB
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x UB1 x USB 3.2 Gen 2 Type-CavS 3.2 Gen 2 Type-C
Front panel connectors - 2 x USB 3.0
guarantee - 36
guarantee_type - statutory
Manufacturer - Thermaltake
Manufacturer_code - CA-11D-00F1WN-00
Maximum CPU cooling height - 185 mm
Maximum length of the graphics card - 460 mm
Maximum length of the power supply - 200 mm
Maximum number of fans - 14
MPN - CA-11D-00F1WN-00
Name - Big Thermaltake AX500 Black
name - Thermaltake AX500 Black
Name - Thermaltake AX500, Big Tower Case Black, Tempered Glass
No. of drive bays - 11
Number of fans installed - 4
Ooptional water cooling - 1 x 120 mm (back)
Ooptional water cooling - 1 x 120 mm (front)
Ooptional water cooling - 1 x 120 mm (top)
Ooptional water cooling - 1 x 140 mm (back)
Ooptional water cooling - 1 x 140 mm (front)
Ooptional water cooling - 1 x 140 mm (top)
Ooptional water cooling - 1 x 240 mm (front)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 280 mm (front)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 360 mm (front)
Ooptional water cooling - 1 x 360 mm (top)
Ooptional water cooling - 1 x 420 mm (front)
Ooptional water cooling - 1 x 420 mm (top)
Optional fans - 1 x 120 mm or 1 x 140 mm (rear)
Optional fans - 3 x 120 mm (osłona zasilacza)
Optional fans - 3 x 120 mm lub 3 x 140 mm (top)
Optional fans - 3 x 120 mm or 2 x 140 mm (side)
Optional fans - 3 x 120 mm or 3 x 140 mm (front)
Power supply - Failure
producer - Thermaltake
Side panel - Tempered Glass
vendpn - CA-11D-00F1WN-00
Weight - 14.9
Weight - 15,20
