D-Link DMS-107/E 7-Port

ARTIKEL1 - 7-PORT UNMANAGED SWITCH
ARTIKEL2 - 5X1G 2X2.5G FANLESS
Brand - D-Link
BrandPartCode - DMS-107/E
Breite - 0
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Compliance certificates - BSMI, CE, Low Voltage Directive (LVD), RoHS
Code - DMS-107/E
Data transmission - Forwarding rate - 14.88 Mpps
Data transmission - MAC address table - 2000 entries
Data transmission - Number of queues - 8
Data transmission - Packet buffer memory - 2 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 20 Gbit/s
Design - Housing material - Metal
Design - LED indicators - Activity, Link, Power
Design - Product colour - Black
EAN - 790069470240
EAN - 0790069470240
EANCode - 0790069470240
EAN_code - 0790069470240
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 790069470240
GTIN - 0790069470240
HERSTELLER - D-LINK
Hoehe - 0
HSTNUMMER - DMS-107/E
Laenge - 0
LongDesc - Experience multi-Gigabit Ethernet speeds.The DMS-107 is a multi-Gigabit Ethernet plug-and-play switch that provides ultra-fast connectivity to your network core or network-attached storage (NAS) device. You can easily connect multiple computers within minutes, and start sharing an internet connection, files, music, and video across your small office or home network.2.5 Gigabit EthernetSave time transferring large files and improve sharing and productivityEffortless multi-Gigabit networkingEasily upgrade or extend your home or small business networkCompact Metal HousingSturdy, compact metal housing with fanless design for silent operationEnergy Efficient DesignAutomatic power saving features to reduce power usageReady for Wi-Fi 6.It comes with multi-Gigabit ports for maximum throughput and performance - ideal for enjoying unrestricted Wi-Fi 6 devices, high-end gaming computers and workstations. The multi-Gigabit ports eliminate potential bottlenecks with Wi-Fi 6 Access Points, allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.Effortless traffic optimisation.With 2.5 Gigabit transfer speeds on uplink ports, you can rapidly transfer files between connected servers and network attached storage (NAS) to computers. The switch’s 802.1p Quality of Service (QoS) functionality on Gigabit ports automatically organises and prioritises time-sensitive and critical data for efficient delivery, allowing for buffer-free video streaming as well as smooth video and voice calls.Plug-and-pay convenience.The DMS-107 is a plug-and-play device that requires no advanced technical configuration. Plug-and-play makes it easy to instantly create a network connected to the internet.Designed for life, built to last.The DMS-107 features a fanless design for silent operation, reduced energy consumption, and increased reliability by eliminating a common point of failure. Its sturdy compact metal housing ensures the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components. Energy Saving.The compact, metal housing and fanless design mean the switches can be placed virtually anywhere and operate silently. The DMS-107 is designed with energy efficiency in mind. The switches automatically reduce power to ports that are inactive or not connected, and support the IEEE 802.3az Energy-Efficient Ethernet standard.
LongProductName - 7-Port Multi-Gigabit Unmanaged Switch
LongSummaryDescription - D-Link 7-Port Multi-Gigabit Unmanaged Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x. DC input voltage: 12 V
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Manufacturer - D-Link
Manufacturer_code - DMS-107/E
MPN - DMS-107/E
Name - D-Link DMS-107 7-Port Multi-Gigabit Unmanaged Switch
Name - D-Link DMS-107/E, switch
Name - D-Link | 7-Port Multi-Gigabit Unmanaged Switch | DMS-107/E | Unmanaged | Desktop | Power supply type External
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-T, 1000BASE-T, 2500BASE-T
Network - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Network - MAC address auto-learning supported - Yes
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Operational conditions - Heat dissipation - 14.28 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -10 - 70 °C
Performance - Fanless - Yes
Performance - Mean time between failures (MTBF) - 944277.78 h
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 2
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 5
Power - DC input voltage - 12 V
Power - Input current - 0.5 A
Power - Power consumption (typical) - 3.37 W
Power - Power source - DC
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
ProductName - 7-Port Multi-Gigabit Unmanaged Switch
ShortSummaryDescription - D-Link 7-Port Multi-Gigabit Unmanaged Switch, Unmanaged, Gigabit Ethernet (10/100/1000)
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - D-Link 7-Port Multi-Gigabit Unmanaged Switch
URL - https://eu.dlink.com/uk/en/products/dms-107-7-port-multi-gigabit-unmanaged-switch
WarrantyInfo - 5 Years
Weight - 0,47
Weight - 0.468
Weight & dimensions - Depth - 28 mm
Weight & dimensions - Height - 82 mm
Weight & dimensions - Weight - 295.2 g
Weight & dimensions - Width - 145 mm
