Dahua PFS3110-8ET1GT1GF-96 PoE ports 8 1SFP

10G support Network - No
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 8
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - Dahua Technology
BrandPartCode - DH-PFS3110-8ET1GT1GF-96
Category - Network Switches
Category Code - SWI
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC)
CnCode - 85176200
Compliance certificates Certificates - CE, Federal Communications Commission (FCC)
Data transmission - Forwarding rate - 4.17 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 0.5 MB
Data transmission - Switching capacity - 5.6 Gbit/s
DC input voltage Power - 53 V
Depth Weight & dimensions - 105 mm
Description - Intelligent PoEP rovides power consumption control and real-time monitoring toguarantee priority of power supply for important ports and preventmalfunctioning caused by power consumption change. Supports ultrawide power supply, able to adapt to IPC power fluctuation. Red Port 90 W The red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoEstandards, with a maximum output power consumption of 90W perport. Suitable for powering high-power devices. PoE Watchdog Adopts the innovative PoE Watchdog. PoE Watchdog can be switchedon by dialing/turning on the WEB page switch. It enables the switch toautomatically detect port status and restart the failed ports to recoverconnection in case of IPC connection exception. This enables intelligentoperation and maintenance management in its true sense andeffectively reduces manual maintenance costs. Long Distance PoEB y dialing or enabling long-range transmission on the WEB interface,the transmission distance of a PoE port can be up to 250 m, meeting therequirement of wired transmission (bandwidth reduced to 10 Mbps).100 Mbps PoE ports and gigabit uplink portsThe red port meets the IEEE 802.3bt standardPower supply supports up to 90 WPoE watchdog monitors the status of terminals in real-timeSupports 250 m long-distance power supplySupports the power management policy8-pin PoE offers better compatibility and reduces cable lossDurable full-metal housing provides great heat dissipation
Design - Housing material - Metal
Design - Product colour - Black
Forwarding rate Data transmission - 4.17 Mpps
GTIN - 6923172540690
Height Weight & dimensions - 28 mm
Housing material Design - Metal
Input current Power - 1.81 A
Jumbo frames Data transmission - 9000
Jumbo frames support Data transmission - Yes
LongDesc - Intelligent PoEProvides power consumption control and real-time monitoring toguarantee priority of power supply for important ports and preventmalfunctioning caused by power consumption change. Supports ultrawide power supply, able to adapt to IPC power fluctuation.Red Port 90 WThe red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt and Hi-PoEstandards, with a maximum output power consumption of 90W perport. Suitable for powering high-power devices.PoE WatchdogAdopts the innovative PoE Watchdog. PoE Watchdog can be switchedon by dialing/turning on the WEB page switch. It enables the switch toautomatically detect port status and restart the failed ports to recoverconnection in case of IPC connection exception. This enables intelligentoperation and maintenance management in its true sense andeffectively reduces manual maintenance costs.Long Distance PoEBy dialing or enabling long-range transmission on the WEB interface,the transmission distance of a PoE port can be up to 250 m, meeting therequirement of wired transmission (bandwidth reduced to 10 Mbps).
LongProductName - 5.60 Gbps, 10/100/1000 Mbps, 53 VDC, 1.81 A, 8 PoE, Black
LongSummaryDescription - Dahua Technology PoE PFS3110-8ET1GT1GF-96. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 5.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53 V. Power over Ethernet (PoE)
MAC address table Data transmission - 8000 entries
Management features - Switch type - Unmanaged
Model name - PFS3110-8ET1GT1GF-96
Network - 10G support - No
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Networking standards Network - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -10 - 55 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package depth Packaging data - 239 mm
Package height Packaging data - 89 mm
Package weight Packaging data - 1.4 kg
Package width Packaging data - 279 mm
Packaging data - Package depth - 239 mm
Packaging data - Package height - 89 mm
Packaging data - Package weight - 1.4 kg
Packaging data - Package width - 279 mm
Packet buffer memory Data transmission - 0.5 MB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP module slots quantity - 1
Power - DC input voltage - 53 V
Power - Input current - 1.81 A
Power - Power consumption (max) - 96 W
Power - Power source - DC
Power - Power supply included - Yes
Power consumption (max) Power - 96 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 96 W
Power over Ethernet (PoE) ports quantity Power over Ethernet (PoE) - 8
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power source Power - DC
Power supply included Power - Yes
Product colour Design - Black
ProductName - PFS3110-8ET1GT1GF-96
SFP module slots quantity Ports & interfaces - 1
ShortSummaryDescription - Dahua Technology PoE PFS3110-8ET1GT1GF-96, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)
Storage relative humidity (H-H) Operational conditions - 5 - 95%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Summary - Dahua Technology PoE PFS3110-8ET1GT1GF-96. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 5.6 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53 V. Power over Ethernet (PoE)
Switching capacity Data transmission - 5.6 Gbit/s
Switch type Management features - Unmanaged
Title - Dahua Technology PoE PFS3110-8ET1GT1GF-96 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 96 W
Unit Box Height - 0.09
Unit Box Length - 0.285
Unit Box Width - 0.24
Unit Calculated Volume - 0.006156 cubm
Unit Calculated Weight - 1.38 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/search/products?keyword=DH-PFS3110-8ET1GT1GF-96
Vendor Homepage - https://www.dahuasecurity.com/search/products?keyword=DH-PFS3110-8ET1GT1GF-96
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 105 mm
Weight & dimensions - Height - 28 mm
Weight & dimensions - Weight - 650 g
Weight & dimensions - Width - 240 mm
Weight Weight & dimensions - 650 g
Width Weight & dimensions - 240 mm
