Qnap WEBMANAG SWITCH 1PORT 10GBERJ45 16 PORTS GBE SFP28 RM DESIGN

ARTIKEL1 - WEBMANAG SWITCH 1PORT 10GBERJ45
ARTIKEL2 - 16 PORTS GBE SFP28 RM DESIGN
Brand - QNAP
BrandPartCode - QSW-M5216-1T
Category - Network Switches
Certificates - Certification - CE, FCC, VCCI, BSMI
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Static route - Yes
Data transmission - Switching capacity - 820 Gbit/s
Data transmission - Throughput - 410 Gbit/s
Design - Electromagnetic compatibility - CLASS A
Design - LED indicators - Activity, Link, Power, Speed, Status
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Reset button - Yes
Design - Stackable - No
EANCode - 4713213519134
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0885022021338
GTIN - 885022021338
GTIN - 4713213519134
HERSTELLER - QNAP
HSTNUMMER - QSW-M5216-1T
Logistics data - Country of origin - Taiwan
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Products per master (outer) case - 5 pc(s)
LongDesc - The QSW-M5216-1T is a 16-Port 25GbE SFP28 fiber Managed Switch with one 10GbE NBASE-T port. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M5216-1T provides an entry-level network management solution that is usable even by non-IT professionals. Offering ultra-high 25GbE speeds and a backbone switching capacity of 820Gbps, the QSW-M5216-1T can serve as the core switch uplinking to 25G Servers and NAS in server rooms or connecting to 25G/10G switches to accelerate high-speed storage, video editing, virtualization, and AI applications. The QSW-M5216-1T provides flexible network interfaces for high compatibility at an affordable price, enabling small businesses to quickly upgrade to an ultra-high-speed backbone network by integrating to existing network infrastructure.Upgrade to ultra-high-speed 25GbE with ease!While 10GbE is a solid base for high-speed network transmission, the ultra-high-speed 25GbE provides comparative cost advantages and compatibility in SMB server rooms to satisfy data computing applications.High switching capacity of 820Gbps for backbone networksThe QSW-M5216-1T has sixteen 25GbE SFP28 fiber ports and offers backbone switching capacity of 820Gbps, guaranteeing the full potential of each port. The QSW-M5216-1T can serve as the core switch uplinking to 25G/100G Servers and NAS in server rooms or connecting to 25G/10G edge fiber switches.Flexible deployment with multiple 25GbE and 10GbE portsAlong with sixteen 25GbE SFP28 fiber ports, the QSW-M5216-1T is has one 10GBASE-T port for enabling hybrid high-speed networks. Its 25GbE SFP28 interfaces are backward compatible with 10GbE SFP+/1GbE SFP; and 10GbE RJ45 is compatible with NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M).Pair with a NAS and 100GbE network expansion card for high-performance, low-latency computingBy using QSFP28 to (4) SFP28 cables, you can easily connect the four 25GbE ports on the QSW-M5216-1T to a NAS with a QXG-100G2SF-E810 dual-port 100GbE network expansion card. You can also use two QSFP28 to (4) SFP28 cables to connect the 100GbE port on the QXG-100G2SF-E810 to four 25GbE ports on the switch. Set a group of QSFP28 to (4) SFP28 connection as the main route and the other as a backup route.QSS: Intuitive Network Management SoftwareThe QNAP Switch System (QSS) features an easy-to-use Web GUI with value-added functions to simplify network set up and management.QSS: Human-centered settings guideQSS provides an overview dashboard, port management and setting guide to help control Layer 2 networks.Optimize Network Performance with bandwidth and packet controlThe QSW-M5216-1T provides bandwidth and packet control functions (such as LACP, VLAN, QoS, and IGMP Snooping) to boost network performance through IP grouping and bandwidth management.Powerful security and system functionsThe QSW-M5216-1T has powerful security and system functions (including ACL, LLDP, RSTP and Flow Control) to help enhance network reliability with access controls, troubleshooting, loop prevention and avoiding packet loss.Near-silent and energy savingWith its smart cooling system, the QSW-M5216-1T ensures high-speed network performance without distracting background noise. IEEE 802.3az (EEE) support also reduces power consumption without sacrificing performance or functionality. By dynamically detecting and adjusting for link speeds and activities, the QSW-M5216-1T provides energy savings of up to 50% to minimize operational costs.
LongProductName - 16x 25GbE SFP28, 1x 10GbE RJ45, Web Managed, 100-240VAC, 50/60 Hz, 43.5 x 285 x 237.7 mm, 2.15 kg
LongSummaryDescription - QNAP QSW-M5216-1T. Switch type: Managed, Switch layer: L2. Console port: RJ-45. MAC address table: 32000 entries, Switching capacity: 820 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE.... Rack mounting
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Network - 10G support - Yes
Network - Auto-negotiation - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3by, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Port mirroring - Yes
Network - VLAN support - Yes
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - Warranty period - 2 year(s)
Packaging content - Cables included - AC
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Package depth - 282 mm
Packaging data - Package height - 78 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.85 kg
Packaging data - Package width - 384 mm
Performance - Firmware upgradeable - Yes
Ports & interfaces - Console port - RJ-45
Ports & interfaces - Fiber optic connector - SFP28
Ports & interfaces - Fiber ports quantity - 16
Ports & interfaces - SFP28 ports quantity - 16
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 80 W
Power - Power source - AC
Power - Power supply included - Yes
ProductName - QSW-M5216-1T
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP server
Security - IGMP snooping - Yes
Security - Loop protection - Yes
ShortSummaryDescription - QNAP QSW-M5216-1T, Managed, L2, Rack mounting
Stck_Kart - 0
Stck_Pal - 0
Storno - Y
Title - QNAP QSW-M5216-1T network switch Managed L2 Black
URL - https://www.qnap.com/en/product/qsw-m5216-1t
WarrantyInfo - 2 years
Weight & dimensions - Depth - 237.7 mm
Weight & dimensions - Height - 43.5 mm
Weight & dimensions - Weight - 2.15 kg
Weight & dimensions - Width - 285 mm
