Dahua PFS3010-8ET-65 8PORT POE

Name: Dahua PFS3010-8ET-65 8PORT POE
Brand: Dahua
SKU: 874765
Price: 41.44 EUR
Availability: OutOfStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 874765 Product code: DH-PFS3010-8ET-65

Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.ee website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 3 years

Compare

Main product parameters All parameters

Base-T speed: 10/100
RJ-45 Ports: 10

Similar Products

Ports and equipment
	This product Dahua PFS3010-8ET-65 8PORT POE	TP-LINK TL-SF1016DS 16-Port 10/100Mbps Desktop/Rackmount Switch	TP-LINK TL-SG105-M2, 5x 100Mbps/1Gbps/2.5Gbp Ports	Dahua PFS3110-8ET-96-V2 8PORT POE	Dahua NET SWITCH 8PORT 4POE 10/100M/SF1008LP
Show similar specs. Hide similar specs.	41.44 €	41.37 €	54.32 €	95.61 €	38.23 €
Base-T speed	10/100	10/100	2,5GbE	10/100/1000
PoE Ports	8	N/A	N/A	8
RJ-45 Ports	10	16	5	9	Eight Core
SFP Ports	N/A	N/A	N/A	1
Specifikācija
Number of fans	Fanless	Fanless	Fanless	Fanless
PoE Per-Port Power Budget	30 W	N/A	N/A	30 W
PoE Support	Ir	Nav	Nav	Ir	Ir
PoE Total Power Budget	65 W	N/A	N/A	96 W
Weight (g)	760 g	500 g	870 g	540 g

Ports and equipment

Base-T speed : 10/100

PoE Ports : 8

RJ-45 Ports : 10

SFP Ports : N/A

Specifikācija

Number of fans : Fanless

PoE Per-Port Power Budget : 30 W

PoE Support : Ir

PoE Total Power Budget : 65 W

Weight (g) : 760 g

More detailed specification

Additional information in manufacturers website Dahua PFS3010-8ET-65 8PORT POE

10/100M WAN ports - 2/8
Brand - Dahua Technology
BrandPartCode - DH-PFS3010-8ET-65
Category - Network Switches
Category Code - SWI
Certificates - Certification - CE: EN60950
FCC
Data transmission - Forwarding rate - 1.49 Mpps
Data transmission - MAC address table - 2000 entries
Data transmission - Switching capacity - 2 Gbit/s
Description - PFS3010-8ET-65 10-Port Fast Ethernet Switch with 8-Port PoE > Support eight 10/100M PoE power supply ports, and two 10/100M uplink ports > Support 802.3af and 802.3at standards > Operating Temperature: -10°C to +55°C > Support 250 m long distance PoE tansmission > Support PoE watchdog
Design - LED indicators - Yes
Design - Product colour - Black
Dimensions - 242.5mm × 122.9mm × 35.0mm
Forwarding rate - 1.49 Mpps
Full Description Line - 2x10/100M|8x10/100M|10xRJ45|PoE ports 8|PoE power budget 65 Watts|Switching capacity 2 Gbps|Forwarding rate 1.49 Mpps|Dimensions 242.5mm × 122.9mm × 35.0mm|Unit Net Weight 0.76 kg
GTIN - 6939554946950
LongDesc -
LongProductName - 10-Port Fast Ethernet Switch with 8-Port PoE
LongSummaryDescription - Dahua Technology PoE DH-PFS3010-8ET-65. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 2000 entries, Switching capacity: 2 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE)
Model name - PFS3010-8ET-65
Network - 10G support - No
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Networking standards - IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage temperature (T-T) - 10 - 90 °C
Packaging data - Package depth - 262 mm
Packaging data - Package height - 72 mm
Packaging data - Package weight - 1.3 kg
Packaging data - Package width - 303 mm
PoE ports - 8
PoE power budget - 65 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 10
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Fast Ethernet (copper) ports quantity - 10
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 65 W
Power - Power source - AC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 65 W
Primary port count - 8
ProductName - DH-PFS3010-8ET-65
Product Net Weight - 0.76 kg
RJ45 Input/Output connectors - 10
Shipping Box Depth Shipping/Package Box Dimensions - 30 cm
Shipping Box Height Shipping/Package Box Dimensions - 7 cm
Shipping Box Weight Shipping/Package Box Dimensions - 1.21 kg
Shipping Box Width Shipping/Package Box Dimensions - 26 cm
ShortSummaryDescription - Dahua Technology PoE DH-PFS3010-8ET-65, Fast Ethernet (10/100), Power over Ethernet (PoE)
Switching capacity - 2 Gbps
Title - Dahua Technology PoE DH-PFS3010-8ET-65 network switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Unit Box Height - 0.07
Unit Box Length - 0.3
Unit Box Width - 0.26
Unit Calculated Volume - 0.00546 cubm
Unit Calculated Weight - 1.21 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Desktop-PoE-Switch/PFS3010-8ET-65
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Desktop-PoE-Switch/PFS3010-8ET-65
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 122.9 mm
Weight & dimensions - Height - 35 mm
Weight & dimensions - Weight - 760 g
Weight & dimensions - Width - 242.5 mm
