10/100/1000M WAN ports - 4
Brand - Dahua Technology
BrandPartCode - PFS3106-4ET-60-V2
Category - Network Switches
Category Code - SWI
Data transmission - Forwarding rate - 3.57 Mpps
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 1 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 6.8 Gbit/s
Description - Unmanaged PoE switch > Eight-Pin assignment PoE power supply > Intelligent PoE > Hi-PoE 60W (Orange Port) > PoE watchdog > 250 m long distance PoE transmission > Wide operating temperature: –30°C to +65°C 1 Ethernet Port 1 Optical Port Port 1–4: 4 × RJ-45 10/100 Mbps (PoE) Port 5: 1 × RJ-45 10/100/1000 Mbps (Uplink) Port 6: 1 × SFP 100/1000 Mbps (Uplink) Capacity 6.80 Gbps Packet Forwarding Rate 3.57 Mpps Packet Buffer Memory 1 Mbit MAC Table Size 8K Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3X; IEEE 802.3ab; IEEE 802.3z PoE Standard: IEEE802.3af; IEEE802.3at; Hi-PoE PoE Power 60W 250 m long distance PoE transmission
Design - DIN rail mounting - Yes
Design - Housing material - Metal
Design - LED indicators - Power, Status
Design - Product colour - Black
Dimensions - 150 mm × 100 mm × 30 mm
Forwarding rate - 3.57 Mpps
Full Description Line - 4x10/100/1000M|IEEE 802.3|IEEE 802.3ab|IEEE 802.3u|IEEE 802.3x|IEEE 802.3z|PoE power budget 60 Watts|Switching capacity 6.8 Gbps|Forwarding rate 3.57 Mpps|Dimensions 150 mm × 100 mm × 30 mm|Product Net Weight 0.45 kg
GTIN - 6923172506603
IEEE 802.3 Network standard - Yes
IEEE 802.3ab Network standard - Yes
IEEE 802.3u Network standard - Yes
IEEE 802.3x Network standard - Yes
IEEE 802.3z Network standard - Yes
LongDesc -
LongProductName - 4-Port PoE Switch (Unmanaged)
LongSummaryDescription - Dahua Technology PoE PFS3106-4ET-60-V2. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 4, Installed SFP modules quantity: 1. MAC address table: 8000 entries, Switching capacity: 6.8 Gbit/s
Management features - Switch layer - L2
Management features - Switch type - Unmanaged
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -40 - 70 °C
Optical fiber - Fiber ethernet cabling technology - 100BASE-X, 1000Base-X
Packaging content - Manual - Yes
Packaging data - Package depth - 240 mm
Packaging data - Package height - 75 mm
Packaging data - Package weight - 1.1 kg
Packaging data - Package width - 270 mm
PoE power budget - 60 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Fiber optic connector - SFP
Ports & interfaces - Fiber ports quantity - 1
Ports & interfaces - Installed SFP modules quantity - 1
Power - Power consumption (typical) - 3 W
Power - Power source - DC
Primary port count - 4
ProductName - PFS3106-4ET-60-V2
Product Net Weight - 0.45 kg
Shipping Box Depth Shipping/Package Box Dimensions - 27 cm
Shipping Box Height Shipping/Package Box Dimensions - 7.8 cm
Shipping Box Weight Shipping/Package Box Dimensions - 1.089 kg
Shipping Box Width Shipping/Package Box Dimensions - 24 cm
ShortSummaryDescription - Dahua Technology PoE PFS3106-4ET-60-V2, Unmanaged, L2, Fast Ethernet (10/100)
Switching capacity - 6.8 Gbps
Title - Dahua Technology PoE PFS3106-4ET-60-V2 network switch Unmanaged L2 Fast Ethernet (10/100) Black
Unit Box Height - 0.078
Unit Box Length - 0.27
Unit Box Width - 0.24
Unit Calculated Volume - 0.005054 cubm
Unit Calculated Weight - 1.09 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Hardened-PoE-Switch/PFS3106-4ET-60
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Hardened-PoE-Switch/PFS3106-4ET-60
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 100 mm
Weight & dimensions - Height - 30 mm
Weight & dimensions - Weight - 450 g
Weight & dimensions - Width - 150 mm
