TP-LINK TL-SL1311MP, 8PORT

10G support Network - No
Accessories included - TL-SL1311MP Zasilacz Instrukcja instalacji
Application - Home and small office
Auto-negotiation Network - Yes
Auto MDI/MDI-X Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 10
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Fast Ethernet (10/100)
Brand - TP-Link
BrandPartCode - TL-SL1311MP
Cable types supported Network - Cat3, Cat4, Cat5, Cat5e
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category Code - SWI
Chassis type - Desktop
Code - TL-SL1311MP
Copper ethernet cabling technology Network - 10BASE-T, 100BASE-TX
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Grupa produktowa - Przełączniki TP-Link
Dane techniczne: Gwarancja - 5 lat w serwisie sprzedawcy
Dane techniczne: Głębokość - 126 mm
Dane techniczne: Liczba portów LAN 10/100 - 8 szt.
Dane techniczne: Liczba portów LAN 10/100/1000 - 2 szt.
Dane techniczne: Porty PoE - 8 szt.
Dane techniczne: Producent - TP-Link
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Prędkość magistrali wew. - 7.6 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 2000
Dane techniczne: Sloty SFP 1000 Mb/s - 1 szt.
Dane techniczne: Szerokość - 209 mm
Dane techniczne: Szybkość przekierowań pakietów - 5.7 mpps
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Wysokość - 26 mm
Data transmission - Forwarding rate - 5.6544 Mpps
Data transmission - Jumbo frames - 16000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 2000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 7.6 Gbit/s
DC input voltage Power - 53.5 V
Depth Weight & dimensions - 126 mm
Description - TL-SL1311MP Przełącznik typu desktop, 8 portów 10/100 Mb/s PoE+, 3 porty gigabitowe. Profesjonalny przełącznik niezarządzalny, 8 portów 10/100 Mb/s PoE+, 3 porty gigabitowe. Plug and Play. Do 250 m zasięgu transmisji danych i zasilania z myślą o systemach monitoringu. Zgodność ze standardami 802.3af/at PoE zapewnia możliwość oferowania do 30 W mocy na każdym porcie PoE. 124 W łącznej mocy zasilania PoE* przełącznika wyposażonego w 8 portów PoE+ to rozwiązanie idealne m.in. dla systemów monitoringu, biur, akademików i małych firm. Urządzenie jest w pełni zgodne z kamerami IP, punktami dostępowymi, telefonami IP, komputerami, drukarkami, itd.
Description - What This Product Does
TP-Link desktop switch TL-SL1311MP is an unmanaged switch with 8× 10/100Mbps ports and 3× Gigabit ports that requires no configuration. With 8× PoE (Power over Ethernet) ports, it can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc. Professional 11-Port Switch with 8-Port PoE+ (124 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 124 W PoE power budget* for the 8× PoE+ ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more. Ideal for IP Surveillance—Long-Range PoE Transmission and One-Click Traffic Separation
With Extend Mode, the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas. With one click, Isolation Mode easily divides traffic for ports 1–8 to avoid snooping and tampering. This enables the switch to isolate broadcast storm for higher security and performance. Intelligent Power Management
When total power consumption exceeds 124 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged. Durable Metal Casing
The interior components of TL-SL1311MP are protected by high-quality metal casing to ensure a long product life. Its fanless design delivers zero added noise in their locations. Having passed an array of stringent reliability tests, TL-SL1311MP delivers switching performance you can depend on.8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port8× PoE+ ports transfer data and power on individual cablesWorks with IEEE 802.3af/at compliant PDsSupports PoE Power up to 30 W for each PoE portSupports PoE Power up to 124 W for 8 PoE ports*Up to 250 m data and power transmitting range under Extend Mode**Isolation Mode allows one-click client traffic separation for higher security and performancePoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devicesFanless Design reduces power consumption and works silently in its locationPlug and play with no configuration required
Design - Number of fans - 0 fan(s)
Design - Product colour - Black
Design - Rack mounting - No
Design > Case design - Steel case
Design > Form factor - Desktop
Designation - CE+WEEE
dimension depth - 72 mm
dimension height - 240 mm
Dimensions - 209 × 126 × 26 mm
dimension weight - 1561 g
dimension width - 315 mm
EAN - 6935364006259
ean - 6935364006259
Eans - 6935364006259
Fan - No
Forwarding mode - Store-and-forward
Forwarding rate - 5.6544 Mpps
Forwarding rate Data transmission - 5.6544 Mpps
GTIN - 0840030702358
GTIN - 840030702358
GTIN - 1210002617215
GTIN - 6935364006259
GTIN - 6935364006266
guarantee - 60
guarantee_type - normal
Harmonized System (HS) code Logistics data - 85176990
Height Weight & dimensions - 26 mm
Input current Power - 2.43 A
Jumbo frames Data transmission - 16000
Jumbo frame size - 16 KB
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
Link - https://www.tp-link.com/uk/business-networking/poe-switch/tl-sl1311mp/#overview
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - What This Product DoesTP-Link desktop switch TL-SL1311MP is an unmanaged switch with 8× 10/100Mbps ports and 3× Gigabit ports that requires no configuration. With 8× PoE (Power over Ethernet) ports, it can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.Professional 11-Port Switch with 8-Port PoE+ (124 W Budget) for Numerous ApplicationsCompliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 124 W PoE power budget* for the 8× PoE+ ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.Ideal for IP Surveillance—Long-Range PoE Transmission and One-Click Traffic SeparationWith Extend Mode, the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas.With one click, Isolation Mode easily divides traffic for ports 1–8 to avoid snooping and tampering. This enables the switch to isolate broadcast storm for higher security and performance.Intelligent Power ManagementWhen total power consumption exceeds 124 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.Durable Metal CasingThe interior components of TL-SL1311MP are protected by high-quality metal casing to ensure a long product life. Its fanless design delivers zero added noise in their locations. Having passed an array of stringent reliability tests, TL-SL1311MP delivers switching performance you can depend on.
LongProductName - 8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port, 209 × 126 × 26 mm
LongSummaryDescription - TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 2000 entries, Switching capacity: 7.6 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 53.5 V. Power connector: DC-in jack. Power over Ethernet (PoE)
MAC address table Data transmission - 2000 entries
MAC address table size - 2000
Management, monitoring, configuration -
Management features - Switch type - Unmanaged
Management features > Switch type - Unmanaged
Manual Packaging content - Yes
Model - TL-SL1311MP
Model name - 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+
name - SL1311MP switch 8xFE PoE+ 2xGE 1xSFP
Name - TP-Link SL1311MP
Name - TP-LINK | 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+ | LS1008 | Unmanaged | Desktop | Power supply type External
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-TX
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.3af, IEEE 802.3at
Number of 10/100 Mbps ports - 8
Number of 10/100/1000 Mbps ports - 2
Number of fans Design - 0 fan(s)
Number of PoE ports (PoE & PoE+) - 8
Number of power supply units Power - 1
Number of SFP ports - 1
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Certyfikaty: FCC, CE, RoHS
Other features > Power supply type - External
Other functions - Zgodność z urządzeniami zasilanymi PoE (PD) działającymi w standardzie IEEE 802.3af Przycisk trybu Extend (porty 1 4 oraz porty 1 8, zasilanie PoE i transmisja danych do 250m) Przycisk trybu Priority (porty 1 8) Przycisk trybu Isolation (porty 1 8) Automatyczne zapamiętywanie i wygaszanie adresów MAC Obsługa kontroli przepustowości IEEE802.3x dla transmisji w pełnym dupleksie oraz funkcji backpressure dla transmisji w półdupleksie
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 313 mm
Package features > Gross height (mm) - 232 mm
Package features > Gross width (mm) - 70 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Paper/Pasteboard - 400.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.50 kg
Package features > Volume (m3) - 0.00508312 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Package type Packaging data - Box
Packaging content - Manual - Yes
Packaging data - Package type - Box
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 10
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces - SFP module slots quantity - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 10
Ports & interfaces > POE - PoE 802.3 af and PoE 802.3 at
Ports & interfaces > Predominant port type - 10/100 Mbps (RJ-45)
Power - DC input voltage - 53.5 V
Power - Input current - 2.43 A
Power - Number of power supply units - 1
Power - Power supply included - Yes
Power connector Ports & interfaces - DC-in jack
Power consumption - 5.95 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 8
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 124 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet plus (PoE+) ports quantity Power over Ethernet (PoE) - 8
Power supply - Zasilacz zewnętrzny (na wyjściu: 53,5 V DC / 2,43 A)
Power supply - Internal
Power supply included Power - Yes
Producent: Nazwa producenta / importera - TP-Link
TP-Link Polska sp. z o.o.
Ożarowska 40/42
05-850 Duchnice

producer - TP-LINK
Producer - TP-Link
ProducerCode - SL1311MP
Producer product family - 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+
Producer product name - LS1008
Product colour Design - Black
ProductName - 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+
QoS -
Rack mounting Design - No
Security -
SFP module slots quantity Ports & interfaces - 1
ShortDescription -
ShortSummaryDescription - TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+, Unmanaged, Fast Ethernet (10/100), Power over Ethernet (PoE)
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Store-and-forward Data transmission - Yes
Summary - TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 2000 entries, Switching capacity: 7.6 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 53.5 V. Power connector: DC-in jack. Power over Ethernet (PoE)
Supported protocols and standards - IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3z
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switching capacity Data transmission - 7.6 Gbit/s
Switch layer - L2
Switch type Management features - Unmanaged
Technical details > Gross weight - 1.536 kg
Technical details > Net weight - 1.036 kg
Technical details > Producer - TP-LINK
Throughput - 7.6 GB/s
Title - TP-Link 8-Port 10/100Mbps + 3-Port Gigabit Desktop Switch with 8-Port PoE+
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 124 W
Unit Box Height - 0.07
Unit Box Length - 0.317
Unit Box Width - 0.241
Unit Calculated Volume - 0.005348 cubm
Unit Calculated Weight - 1.55 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/uk/business-networking/unmanaged-switch/tl-sl1311mp/
Vendor Homepage - https://www.tp-link.com/uk/business-networking/unmanaged-switch/tl-sl1311mp/
vendpn - TL-SL1311MP
VLAN -
Warranty - 24 months
Warranty - 60
Warranty - 60 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 126 mm
Weight & dimensions - Height - 26 mm
Weight & dimensions - Width - 209 mm
Width Weight & dimensions - 209 mm
