Qnap QSW-M408-4C, 8x1GB 4X 10G SFP+

10G support Network - Yes
Access Control List (ACL) Security - Yes
AC input frequency Power - 50 - 60 Hz
AC input voltage Power - 100 - 240 V
ARTIKEL1 - QSW-M408-4C SWITCH 8PORT 1GBPS
ARTIKEL2 - 4X 10G SFP+/ NBASE-T COMBO WMSW
Auto-negotiation Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 8
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - QNAP
BrandPartCode - QSW-M408-4C
Cables included Packaging content - AC
Cable types supported Network - Cat5, Cat5e, Cat6
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Certification - CE, FCC, VCCI, BSMI, CCC
Certification Certificates - CE, FCC, VCCI, BSMI, CCC
Combo SFP ports quantity Ports & interfaces - 4
Console port Ports & interfaces - RJ-45
Copper ethernet cabling technology Network - 10BASE-T, 10GBASE-T, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
Country of origin Logistics data - Taiwan
Dane techniczne: Gwarancja - 2 lata w serwisie sprzedawcy
Dane techniczne: Głębokość - 127 mm
Dane techniczne: Liczba portów LAN 10 Gbit - 4 szt. (combo)
Dane techniczne: Liczba portów LAN 10/100/1000 - 8 szt.
Dane techniczne: Obsługa VLANów - tak
Dane techniczne: Obsługiwane protokoły - IEEE 802.1p
Dane techniczne: Obsługiwane protokoły - IEEE 802.1Q
Dane techniczne: Obsługiwane protokoły - IEEE 802.1w
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3 an
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ab
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ad
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ae
Dane techniczne: Obsługiwane protokoły - IEEE 802.3az
Dane techniczne: Obsługiwane protokoły - IEEE 802.3bz
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Obsługiwane protokoły - IEEE 802.3x flow control
Dane techniczne: Obsługiwane protokoły - IEEE 802.3z
Dane techniczne: Port konsolowy - 1 szt.
Dane techniczne: Producent - Qnap
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Prędkość magistrali wew. - 96 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 16000
Dane techniczne: Sloty SFP+ 10G - 4 szt.
Dane techniczne: Szerokość - 290 mm
Dane techniczne: Typ - zarządzalny
Dane techniczne: Waga - 1.15 kg
Dane techniczne: Wysokość - 42.5 mm
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Switching capacity - 96 Gbit/s
Data transmission - Throughput - 48 Gbit/s
Depth Weight & dimensions - 127 mm
Description - The QSW-M408-4C is a Layer 2 Web Managed Switch equipped with four 10GbE SFP+/RJ45 combo ports and eight Gigabit ports. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M408-4C offers flexible deployment in hybrid high-speed network environments and provides an entry-level network management solution that is usable even by non-IT professionals. The QSW-M408-4C is compatible with 10GbE and NBASE-T technologies that supports up to five speeds (10G / 5G / 2.5G / 1G / 100M) to provide higher transmission speeds with existing Cat 5e and 6a cables. With its high performance, user-friendly management features and desktop size, the QSW-M408-4C allows you to instantly upgrade to a hybrid high-speed network environment at a cost-effective price, while optimizing network bandwidth and ensuring network maintenance security. Flexible deployment with multiple 10G SFP+ fiber and Gigabit ports
The QSW-M408-4C provides four 10GbE SFP+/RJ45 combo ports and eight Gigabit ports for connecting various devices and enabling hybrid high-speed networks. With SFP+ interfaces, direct attach copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T devices through RJ45 Category 6, 5 or 5e cabling. The switching capacity of QSW-M408-4C is 96Gbps, guaranteeing the full potential of each port. QSS: Intuitive Network Management Software with Web GUI
The QSW-M408-4C uses the QNAP Switch System (QSS), which features an easy-to-use Web GUI with value-added functions to simplify network set up and management. Sleek Design
Use the at-a-glance major functions, flat control layers and one-click login to simplify set up and management. GUI
The visual illustration matches physical ports for greater usability. Value-added Functions
With the setting guide, status chart reference, online firmware update, the learning and management costs are greatly reduced. QSS: The human-centered setting guide
QNAP Switch System (QSS) provides an overview dashboard, port management and setting guide to help administrators control Layer 2 networks. Optimize Network Performance with bandwidth and packet control
The QSW-M408-4C provides bandwidth and packet control functions (such as LACP, VLAN, QoS, and IGMP Snooping) for boosting network performance through IP grouping and bandwidth management. Powerful security and system functions
The QSW-M408-4C has powerful security and system functions (including ACL, LLDP, RSTP and Flow Control) to help administrators enhance network reliability using access controls, troubleshooting, loop prevention and avoiding packet loss. Faster speeds using existing cables with 10GBASE-T & NBASE-T
The QSW-M408-4C is compatible with 10GbE and NBASE-T technologies to support up to five speeds (10G / 5G / 2.5G / 1G / 100M). The SFP+/RJ45 (copper) combo ports provide higher transmission speeds with existing cables. Depending on cable types and their lengths, different speeds can be achieved for faster, more efficient data transfer. Improve team productivity with a 5GbE/ 10GbE High-Speed Network
From NAS with built-in 10GbE SFP+ and 10GBASE-T ports, or NAS with PCIe slots that support 10GbE/5GbE/2.5GbE network adapters, QNAP has led the industry in 10GbE adoption. Other high-speed network solutions from QNAP include Thunderbolt 3 to 10GbE Network Adapters and USB 3.2 Gen 1 to 5GbE Network Adapters. These can all be used with the QSW-M408-4C to create a comprehensive high-speed network environment for boosting the performance of photo/video editing, virtualization, large-file data transfers, and other bandwidth-demanding tasks. Desktop size for easy use in offices
With a compact and modern design, the QSW-M408-4C fits perfectly alongside other devices in modern digital offices. Featuring a delicate white or textured surface design, the QSW-M408-4C helps users to easily identify each port. The flexible DC power connector also assists in universally deploying the QSW-M408-4C. Being fully plug-and-play, simply connect the QSW-M408-4C to your devices and it will do the rest.The QSW-M408-4C is equipped with four 10GbE SFP+/ RJ45 combo ports and eight Gigabit ports. Compatible with 10GbE and NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M), the QSW-M408-4C offers higher transmission speeds when used with existing cablesFeaturing a user-friendly web UI, the QNAP Switch System (QSS) provides an overview dashboard, port management and setting guide, making central network management intuitive and easyThe QSW-M408-4C provides Layer 2 management features, such as LACP, VLAN, ACL and LLDP for IT administrators to efficiently control the network bandwidth and enhance securityThe QSW-M408-4C is one the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). You can easily and efficiently deploy small/medium-scale networks that support expansion, redundancy and loop preventionCompliant with IEEE 802.3az Energy Efficient Ethernet and IEEE802.3x Flow Control in full-duplex mode, the QSW-M408-4C avoids packet loss from unparalleled bandwidth, and reduces power consumption for low-speed and inactive connectionsQSS (QNAP Switch System) helps administrators update firmware with just one click, ensuring network security
Design - Electromagnetic compatibility - CLASS A
Design - LED indicators - Activity, Link, Power, Speed, Status
Design - Number of fans - 1 fan(s)
Design - Product colour - White
Design - Rack mounting - No
Design - Reset button - Yes
Design - Stackable - No
DHCP features Security - DHCP client
EAN - 4713213516713
EANCode - 4713213516713
Eans - 4713213516713
EAN_code - 4713213516713
Electromagnetic compatibility Design - CLASS A
Flow control support Network - Yes
Full duplex Network - Yes
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 8
Gross Weight Kg - 1,5
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0885022018734
GTIN - 885022018734
GTIN - 4713213516713
Harmonized System (HS) code Logistics data - 85176990
Height Weight & dimensions - 42.5 mm
HERSTELLER - QNAP
HSTNUMMER - QSW-M408-4C
IGMP snooping Security - Yes
Jumbo frames Data transmission - 9000
Jumbo frames support Data transmission - Yes
LED indicators Design - Activity, Link, Power, Speed, Status
Logistics data - Country of origin - Taiwan
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Products per master (outer) case - 8 pc(s)
LongDesc - The QSW-M408-4C is a Layer 2 Web Managed Switch equipped with four 10GbE SFP+/RJ45 combo ports and eight Gigabit ports. Supporting Layer 2 switching and network management via a user-friendly web user interface, the QSW-M408-4C offers flexible deployment in hybrid high-speed network environments and provides an entry-level network management solution that is usable even by non-IT professionals. The QSW-M408-4C is compatible with 10GbE and NBASE-T technologies that supports up to five speeds (10G / 5G / 2.5G / 1G / 100M) to provide higher transmission speeds with existing Cat 5e and 6a cables. With its high performance, user-friendly management features and desktop size, the QSW-M408-4C allows you to instantly upgrade to a hybrid high-speed network environment at a cost-effective price, while optimizing network bandwidth and ensuring network maintenance security.Flexible deployment with multiple 10G SFP+ fiber and Gigabit portsThe QSW-M408-4C provides four 10GbE SFP+/RJ45 combo ports and eight Gigabit ports for connecting various devices and enabling hybrid high-speed networks. With SFP+ interfaces, direct attach copper (DAC) cables can be used for connecting directly to SFP+ devices. You can also use RJ45 ports to connect 10GBASE-T/NBASE-T devices through RJ45 Category 6, 5 or 5e cabling. The switching capacity of QSW-M408-4C is 96Gbps, guaranteeing the full potential of each port.QSS: Intuitive Network Management Software with Web GUIThe QSW-M408-4C uses the QNAP Switch System (QSS), which features an easy-to-use Web GUI with value-added functions to simplify network set up and management.Sleek DesignUse the at-a-glance major functions, flat control layers and one-click login to simplify set up and management.GUIThe visual illustration matches physical ports for greater usability.Value-added FunctionsWith the setting guide, status chart reference, online firmware update, the learning and management costs are greatly reduced.QSS: The human-centered setting guideQNAP Switch System (QSS) provides an overview dashboard, port management and setting guide to help administrators control Layer 2 networks.Optimize Network Performance with bandwidth and packet controlThe QSW-M408-4C provides bandwidth and packet control functions (such as LACP, VLAN, QoS, and IGMP Snooping) for boosting network performance through IP grouping and bandwidth management.Powerful security and system functionsThe QSW-M408-4C has powerful security and system functions (including ACL, LLDP, RSTP and Flow Control) to help administrators enhance network reliability using access controls, troubleshooting, loop prevention and avoiding packet loss.Faster speeds using existing cables with 10GBASE-T & NBASE-TThe QSW-M408-4C is compatible with 10GbE and NBASE-T technologies to support up to five speeds (10G / 5G / 2.5G / 1G / 100M). The SFP+/RJ45 (copper) combo ports provide higher transmission speeds with existing cables. Depending on cable types and their lengths, different speeds can be achieved for faster, more efficient data transfer.Improve team productivity with a 5GbE/ 10GbE High-Speed NetworkFrom NAS with built-in 10GbE SFP+ and 10GBASE-T ports, or NAS with PCIe slots that support 10GbE/5GbE/2.5GbE network adapters, QNAP has led the industry in 10GbE adoption. Other high-speed network solutions from QNAP include Thunderbolt 3 to 10GbE Network Adapters and USB 3.2 Gen 1 to 5GbE Network Adapters. These can all be used with the QSW-M408-4C to create a comprehensive high-speed network environment for boosting the performance of photo/video editing, virtualization, large-file data transfers, and other bandwidth-demanding tasks.Desktop size for easy use in officesWith a compact and modern design, the QSW-M408-4C fits perfectly alongside other devices in modern digital offices. Featuring a delicate white or textured surface design, the QSW-M408-4C helps users to easily identify each port. The flexible DC power connector also assists in universally deploying the QSW-M408-4C. Being fully plug-and-play, simply connect the QSW-M408-4C to your devices and it will do the rest.
LongProductName - 8x RJ45 1GbE, 4x 10GbE SFP+/RJ45 Combo, Web Managed, 100-240VAC, 50/60 Hz, 42.5 x 290 x 127 mm, 1.15 kg
LongSummaryDescription - QNAP QSW-M408-4C. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. MAC address table: 16000 entries, Switching capacity: 96 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE...
MAC address table Data transmission - 16000 entries
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - Qnap
Manufacturer Code - QSW-M408-4C
Manufacturer Name - QNAP
Manufacturer_code - QSW-M408-4C
Model name - QSW-M408-4C
Name - QNAP QSW-M408-4C
Name - QNAP QSW-M408-4C, Switch
Network - 10G support - Yes
Network - Auto-negotiation - Yes
Network - Cable types supported - Cat5, Cat5e, Cat6
Network - Copper ethernet cabling technology - 10BASE-T, 10GBASE-T, 1000BASE-LX, 1000BASE-SX, 1000BASE-T
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Port-based VLAN, Private VLAN
Network - VLAN support - Yes
Networking standards Network - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Noise level Performance - 21 dB
Number of fans Design - 1 fan(s)
Number of power supply units Power - 1
Operating relative humidity (H-H) Operational conditions - 5 - 95%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - Warranty period - 2 year(s)
Package depth Packaging data - 219 mm
Package height Packaging data - 60 mm
Package type Packaging data - Box
Package weight Packaging data - 1.19 kg
Package width Packaging data - 315 mm
Packaging content - Cables included - AC
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 219 mm
Packaging data - Package height - 60 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.19 kg
Packaging data - Package width - 315 mm
Performance - Noise level - 21 dB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Combo SFP ports quantity - 4
Ports & interfaces - Console port - RJ-45
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 8
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Number of power supply units - 1
Power - Power consumption (max) - 31.46 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption (max) Power - 31.46 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Power source Power - AC
Power supply included Power - Yes
Producent: Nazwa producenta / importera - Qnap
QNAP GmbH
Karl-Arnold-Straße 26
47877 Willich
Producer - Qnap
ProducerCode - QSW-M408-4C
Product colour Design - White
ProductName - QSW-M408-4C
Products per master (outer) case Logistics data - 8 pc(s)
Quality of Service (QoS) support Management features - Yes
Quick start guide Packaging content - Yes
Rack mounting Design - No
Reset button Design - Yes
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP client
Security - IGMP snooping - Yes
ShortDescription -
Short description - QNAP Switch QSW-M408-4C
ShortSummaryDescription - QNAP QSW-M408-4C, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex
Spanning tree protocol Network - Yes
Stackable Design - No
Stck_Kart - 8
Stck_Pal - 0
Storno - Y
Summary - QNAP QSW-M408-4C. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. MAC address table: 16000 entries, Switching capacity: 96 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE...
Switching capacity Data transmission - 96 Gbit/s
Switch layer Management features - L2
Switch type Management features - Managed
Throughput Data transmission - 48 Gbit/s
Title - QNAP QSW-M408-4C network switch Managed L2 Gigabit Ethernet (10/100/1000) White
Unit Box Height - 0.22
Unit Box Length - 0.315
Unit Box Width - 0.06
Unit Calculated Volume - 0.004158 cubm
Unit Calculated Weight - 1.79 kg
Units per Shipping Box - 1
URL - https://www.qnap.com/en/product/qsw-m408-4c
Vendor Homepage - https://www.qnap.com/en/product/qsw-m408-4c
Virtual LAN features Network - Port-based VLAN, Private VLAN
VLAN support Network - Yes
Warranty - 24 months
WarrantyInfo - 2 Years
Warranty period Other features - 2 year(s)
Web-based management Management features - Yes
Weight - 1,82
Weight & dimensions - Depth - 127 mm
Weight & dimensions - Height - 42.5 mm
Weight & dimensions - Weight - 1.15 kg
Weight & dimensions - Width - 290 mm
Weight Weight & dimensions - 1.15 kg
Width Weight & dimensions - 290 mm
