Brand - TP-Link
BrandPartCode - SX6632YF
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Data transmission - Forwarding rate - 610.1 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 128000 entries
Data transmission - Packet buffer memory - 8 MB
Data transmission - Switching capacity - 820 Gbit/s
Design - Number of fans - 4 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
EAN - 4895252501315
GTIN - 0840030705816
GTIN - 840030705816
GTIN - 4895252501315
GTIN - 4895252501322
LongDesc - What This Product DoesThe Omada SX6632YF is a true L3 managed switch with full fiber ports that offers L3 routing, swift 25 Gbps wired speed, stacking, and redundant power supplies, catering to convergence layer demands. It comes with 6× 25 Gbps SFP28 slots, 26× 10 Gbps SFP+ slots, and physical stacking. Integrated with robust security and comprehensive management features, this switch ensures reliable performance for SMB, enterprise, and ISP networks.High-speed Connectivity and Powerful Stacking6× 25 Gbps SFP28 slots and 26× 10 Gbps SFP+ slots provide up to 820 Gbps switching capacity per unit. Up to 8 units of physical stacking with up to 6560 Gbps switching capacity empowers the networking structure with built-in redundancy and performance.Abundant Layer 3 CapabilitiesComes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server, and DHCP Relay are supported. PIM-DM multicast routing protocol guarantees efficient routing for multicast groups.Highly AvailableInternal fixed redundant power supplies* and VRRP make it an ideal choice for reliable networking architecture. ERPS supports rapid protection and recovery in a ring topology.Enhanced Security FunctionsDefend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.Omada SDNIntegration into the Omada system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP).† The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers, providing 100% centralized cloud management—all controlled from a single interface.Apart from the ability to be centrally managed via the web or the Omada app, SX6632YF is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.
LongProductName - Omada 26-Port 10G Stackable L3 Managed Aggregation Switch with 6 25G Slots
LongSummaryDescription - TP-Link SX6632YF. Switch type: Managed, Switch layer: L2+/L3. Console port: RJ-45. MAC address table: 128000 entries, Switching capacity: 820 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah. Rack mounting
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+/L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - TP-Link
MPN - SX6632YF(UN)
Multicast features - Multicast support - Yes
Name - TP-Link Omada Switch 26x GE SX6632Y Layer 3
Network - 10G support - Yes
Network - IP routing - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah
Network - Port mirroring - Yes
Network - Virtual LAN features - MAC address-based VLAN, Multicast VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
Network - VLAN support - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - Cables included - Power
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Performance - Minimum system requirements - Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ / Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® /Linux.
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - No
Ports & interfaces - Console port - RJ-45
Ports & interfaces - Number of management ports - 1 pc(s)
Ports & interfaces - SFP+ module slots quantity - 26
Ports & interfaces - SFP module slots quantity - 6
Ports & interfaces - USB Type-A ports quantity - 2
Ports & interfaces - USB Type-C ports quantity - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Number of power supply units - 2
Power - Power source - AC
Power - Redundant power supply (RPS) support - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
ProductName - SX6632YF
Protocols - Management protocols - SNMPv1/v2c/v3
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP Option 82
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - SSH/SSL support - Yes
Security - Static port security - Yes
ShortSummaryDescription - TP-Link SX6632YF, Managed, L2+/L3, Rack mounting
Title - TP-Link SX6632YF network switch Managed L2+/L3 Black
URL - https://www.tp-link.com/eg/business-networking/managed-switch/sx6632yf/
WarrantyInfo -
Weight & dimensions - Depth - 380 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
