Ubiquiti USW-Pro-Max-16-POE, 16x1Gb POE++ 2SFP

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1129835 Product code: USW-PRO-MAX-16-POE
In stock 27 units
Warranty: 2 years (Warranty for business entities 1 year)
415.52 €
Ready for dispatch
on Wednesday, 16.07.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Base-T speed: 10/100/1000
  • RJ-45 Ports: 16
Ports and equipment
Base-T speed : 10/100/1000
PoE Ports : 16
RJ-45 Ports : 16
SFP Ports : 2
Specifikācija
Number of fans : Fanless
PoE Per-Port Power Budget : 30 W
PoE Support : Ir
PoE Total Power Budget : 180 W
Weight (g) : 2100 g
Network cards
More detailed specification
2.5GbE LAN Ports - 4
10/100/1000/2500 Mbps ports - 16
10/100/1000M LAN Ports - 12
Accessories included -
Application - Home and small office
brand - Ubiquiti
Category - Root/Electronics/Networks and communication/Switchers
category - Ubiquiti > UniFi komutatori > Professional Max
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - CE FCC IC
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - Industry Canada (IC)
Chassis type - Rack
CnCode CnCode - 85176200
Code - USW-Pro-Max-16-PoE
Console port - No
Dane techniczne: Dodatkowe informacje - budżet POE: 180W
Dane techniczne: Gwarancja - 1 rok w serwisie sprzedawcy
Dane techniczne: Głębokość - 160 mm
Dane techniczne: Liczba portów LAN 2.5 Gbit - 4 szt.
Dane techniczne: Liczba portów LAN 10/100/1000 - 12 szt.
Dane techniczne: Obsługa VLANów - tak
Dane techniczne: Porty PoE - 12 szt.
Dane techniczne: Producent - Ubiquiti
Dane techniczne: Przeznaczenie - do szaf RACK 19"
Dane techniczne: Prędkość magistrali wew. - 84 Gb/s
Dane techniczne: Sloty SFP+ 10G - 2 szt.
Dane techniczne: Szerokość - 325 mm
Dane techniczne: Szybkość przekierowań pakietów - 62 mpps
Dane techniczne: Typ - zarządzalny
Dane techniczne: Waga - 2.1 kg
Dane techniczne: Warstwa przełączania - 3
Dane techniczne: Wysokość - 43.7 mm
Dane techniczne: Zarządzalność - tak
Data transmission - Forwarding rate - 62.496 Mpps
Data transmission - Jumbo frames support - Yes
Data transmission - Switching capacity - 84 Gbit/s
Data transmission - Throughput - 42 Gbit/s
Description - UBIQUITI Pro Max 16 PoE USW-Pro-Max-16-PoE (180W) A 16-port, Layer 3 Etherlighting™ switch with 2.5 GbE, PoE++ output, and versatile mounting options. Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network* (4) 2.5 GbE PoE++ ports (12) GbE PoE+ ports (2) 10G SFP+ ports 180W total PoE availability Versatile desktop, wall, and rack** mounting Silent, fanless cooling system
Description - UBIQUITI USW-Pro-Max-16-PoE
The USW-Pro-Max-16-PoE is an advanced 16-port Layer 3 switch with Etherlighting technology, supporting 2.5GbE and equipped with PoE++ outputs. Each port is equipped with Etherlighting illumination, making it easy to identify the port location, speed/link, and native VLAN. The switch offers four 2.5GbE PoE++ ports and twelve GbE PoE+ ports, with a total PoE power of 180W. Additionally, it has two 10G SFP ports for higher bandwidth requirements. Desktop, wall, or rack mount (requires additional rack mount accessories), and a quiet, fanless cooling system provide flexibility and reliability in various network environments.
Design - Display type - LCM
Design - Housing material - Steel
Design - LED indicators - System
Design - Product colour - Grey
Design - Rack mounting - Yes
Design - Reset button - Yes
Design > Form factor - Desktop/Wall-mountable
Designation - CE+WEEE
dimensionalWeight - 2649
dimension depth - 250 mm
dimension height - 520 mm
Dimensions - 325.1 x 160 x 43.7 mm
Dimensions - 325.1 x 160 x 43.7 mm
dimension weight - 3500 g
dimension width - 110 mm
EAN - 810084694572
ean - 810084694572
EAN - 0810084694572
Eans - 810084694572
Environment requirements -
Fan - No
Forwarding rate - 62.496 Mpps
Forwarding rate - 62.496 Mpps
Full Description Line - 12x10/100/1000M|4x2.5GbE|2xSPF+|PoE power budget 180 Watts|Switching capacity 84 Gbps|Forwarding rate 62.496 Mpps|Dimensions 325.1 x 160 x 43.7 mm|Product Net Weight 2.1 kg
Gross Weight Kg - 5,4
guarantee - 12
guarantee_type - normal
height - 0.132 m
L2 features - IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
L3 features - DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
length - 0.52 m
Link - https://eu.store.ui.com/eu/en/category/switching-professional-max-xg/products/usw-pro-max-16-poe
Management, monitoring, configuration -
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features > Switch type - Managed L3
Manufacturer - Ubiquiti
Manufacturer Code - USW-PRO-MAX-16-POE
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - USW-Pro-Max-16-PoE
Model - USW-PRO-MAX-16-POE
mpn - USW-Pro-Max-16-PoE
MPN - USW-PRO-MAX-16-POE
Multicast features - Multicast support - Yes
Name - 16+2P Ubiquiti UniFi USW-Pro-Max-16-POE 180W M RM POE++
name - Switch USW-Pro-Max-16-PoE
Name - Ubiquiti 16-port Switch | USW-Pro-Max-16-PoE | Managed L3 | Desktop/Wall-mountable | Power supply type AC/DC, external, 210W
Name - UBIQUITI USW-PRO-MAX-16-POE
Name - Ubiquiti USW-Pro-Max-16-POE, Switch (180W PoE Budget)
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.1x
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Network architecture - FastEthernet
Number of 10Gb ports - 2
Number of PoE++ ports - 4
Number of PoE+ ports - 12
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Other features -
Other features > Power supply type - AC/DC, external, 210W
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 325.10 mm
Package features > Gross height (mm) - 43.70 mm
Package features > Gross width (mm) - 160.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 276 pc(s)
Package features > Paper/Pasteboard - 1216.00 g
Package features > Plastic (No PET) - 304.00 g
Package features > Tare weight (kg) - 1.52 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Cables included - Power
Packaging content - Manual - Yes
Packaging data - Mounting brackets included - Yes
PoE power budget - 180 Watts
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 4
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 16
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 12
Ports & interfaces - Power connector - DC-in jack
Ports & interfaces - SFP+ module slots quantity - 2
Ports & interfaces > POE - PoE++
Ports & interfaces > Predominant port type - 2.5 Gbps (RJ-45)
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - DC input voltage - 44 - 57 V
Power - Power consumption (max) - 30 W
Power - Power source - AC/DC
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power consumption - 25 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 15 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 4
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 12
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 180 W
Power over Ethernet (PoE) > Power over Ethernet (PoE) - Yes
Power supply - 5V, 25W (included)
Power supply - External
Primary port count - 16
Producent: Nazwa producenta / importera - UbiquitiBATNA SPÓŁKA Z OGRANICZONĄ ODPOWIEDZIALNOŚCIĄOlgi Boznańskiej 3e42-202 CzęstochowaPolskaEmail: sklep@batna24.com
producer - UBIQUITI
Producer - Ubiquiti
producerCode - USW-Pro-Max-16-PoE
ProducerCode - USW-PRO-MAX-16-POE
productName - Ubiquiti Pro Max 16 PoE Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
Product Net Weight - 2.1 kg
productSize - Normal
QoS -
Security -
Security - DHCP features - DHCP snooping
Security - DHCP features - DHCPv6 relay
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Shipping Box Depth Shipping/Package Box Dimensions - 53 cm
Shipping Box Height Shipping/Package Box Dimensions - 25.5 cm
Shipping Box Weight Shipping/Package Box Dimensions - 16.3 kg
Shipping Box Width Shipping/Package Box Dimensions - 51 cm
ShortDescription -
Short description - Ubiquiti Switch UniFi 12xRJ45 GBit/4xRJ45 2.5G/2xSFP+ Managed PoE+ 180W Max optional 19" Rack-Mountable, 1,3" Touchscreen
sizeX - 515
sizeY - 245
sizeZ - 105
SPF+ LAN Ports - 2
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switching capacity - 84 Gbps
Switch layer - L3
Technical details > Gross weight - 3.62 kg
Technical details > Net weight - 2.10 kg
Technical details > Producer - Ubiquiti
Technical details > Producer product family - 16-port Switch
Technical details > Producer product name - USW-Pro-Max-16-PoE
Technical details > Software type - UniFi Network: Version 8.1.127 and later
Throughput - 84 Gb/s
title - Ubiquiti UniFi Switch Pro Max 16 PoE
Unit Box Height - 0.11
Unit Box Length - 0.515
Unit Box Width - 0.25
Unit Calculated Volume - 0.01723 cubm
Unit Calculated Weight - 4.08 kg
Units per Shipping Box - 4
Vendor Homepage - eu.store.ui.com/eu/en/products/usw-pro-max-16-poe
vendpn - USW-Pro-Max-16-PoE
VLAN -
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 1.95 kg
Weight - 3,60
Weight - 3.588
weight - 4.2 kg
weight - 3610
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 43.7 mm
Weight & dimensions - Weight - 2.1 kg
Weight & dimensions - Width - 325.1 mm
width - 0.25 m
