TP-LINK Omada SG2428LP

10/100/1000/2500 Mbps ports - None
10G support Network - No
Access Control List (ACL) Security - Yes
Accessories included -
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
ARP inspection Management features - Yes
ARTIKEL1 - OMADA 28-PORT 1G SMART SWITCH
ARTIKEL2 - WITH 16-PORT POE+
Auto-negotiation Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 24
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - TP-Link
BrandPartCode - SG2428LP
Breite - 0
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates - CE, FCC
Chassis type - Rack
Cloud-managed Management features - Yes
CnCode - 85176200
Console port - No
Data transmission - Forwarding rate - 41.66 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 4.1 MB
Data transmission - Switching capacity - 56 Gbit/s
Depth Weight & dimensions - 220 mm
Description - - 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
- 150 W Total PoE Budget
- Fanless Design for Silent Operation
- Zero-Touch Provisioning
- Centralized Management
- Omada App
- Static Routing
- Traffic Separation Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface. Multiple Application Scenarios Surveillance
Works with IP Cameras Conference Call
Works with IP Phones Wi-Fi Coverage
Works with Access Points Wired Connections
Works with Non-PoE Devices such as PCs and Printers16× Gigabit 802.3af/at PoE+ ports8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots150 W total PoE budget with up to 30 W PoE output per port*Centralized cloud management via the web or the Omada app†Standalone management via web, CLI, SNMP, and RMONStatic Routing helps route internal traffic for higher efficiencyVLAN, ACL, QoS, and IGMP SnoopingFanless design for quiet operationDurable metal casing and rackmountable design
Description - 16× Gigabit 802.3af/at PoE+ ports 8× Gigabit RJ45 non-PoE ports and 4× Gigabit SFP slots 150W total PoE budget, with the ability to deliver up to 30W PoE per port Centralized cloud management via web page or Omada app Standalone device management via web page, command line interface (CLI), SNMP, and RMON Static routing helps direct internal traffic for greater efficiency VLAN, ACL, QoS, and IGMP snooping Fanless design for quiet operation Rugged metal housing and rack-mount design
Design - LED indicators - Yes
Design - Product colour - Grey
Design - Rack mounting - Yes
Designation - CE+WEEE
DHCP features Security - DHCP relay, DHCP server
dimensionalWeight - 3838
dimension depth - 100 mm
dimension height - 530 mm
Dimensions - 440 × 220 × 44 mm
dimension weight - 4010 g
dimension width - 335 mm
ean - 8885020620832
EAN - 8885020620832
EANCode - 8885020620832
Environment requirements - Operating Temperature: 040 degrees Celsius Storage Temperature: -4070 degrees Celsius Operating Humidity: 1090% RH, non-condensing Storage Humidity: 590% RH, non-condensing
Fan - No
Fanless Performance - Yes
Flow control support Network - Yes
Forwarding rate - 41.66 Mpps
Forwarding rate Data transmission - 41.66 Mpps
Gewicht - 4.57
Gross Weight Kg - 4
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0810142820394
GTIN - 810142820394
GTIN - 8885020620832
GTIN - 8885020620849
guarantee - 60
guarantee_type - normal
Heat dissipation Operational conditions - 628 BTU/h
Height Weight & dimensions - 44 mm
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SG2428LP
IGMP snooping Security - Yes
Jumbo frames Data transmission - 9000
Jumbo frame size - 9 KB
Jumbo frames support Data transmission - Yes
L2 features - 511 IPv4, IPv6 shared multicast groups IGMP Snooping Multicast VLAN Registration (MVR) Multicast Filtering Limited IP Multicast (256 profiles and 16 entries per profile)
L3 features -
Laenge - 0
LED indicators Design - Yes
Link aggregation Network - Yes
LongDesc - - 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots- 150 W Total PoE Budget- Fanless Design for Silent Operation- Zero-Touch Provisioning- Centralized Management- Omada App- Static Routing- Traffic SeparationSoftware Defined Networking (SDN) with Cloud AccessRemotely manage your access points, switches, and gateways across multiple sites all from a single interface.Multiple Application ScenariosSurveillanceWorks with IP Cameras Conference CallWorks with IP Phones Wi-Fi CoverageWorks with Access Points Wired ConnectionsWorks with Non-PoE Devices such as PCs and Printers
LongProductName - 16× 10/100/1000 Mbps PoE+ RJ45, 8× 10/100/1000 Mbps RJ45, 4× Gigabit SFP Slots, 56 Gbps, 41.66 Mpps, 440 x 220 x 44 mm
LongSummaryDescription - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting
MAC address filtering Security - Yes
MAC address table Data transmission - 8000 entries
MAC address table size - 8000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L2+
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - SG2428LP
Manufacturer Name - TP-LINK
Model name - SG2428LP
MPN - SG2428LP
Multicast features - Multicast support - Yes
Multicast support Multicast features - Yes
Name - 24+4P TP-Link Omada SG2428LP M RM POE+
name - Switch SG2428LP 16xGE PoE+ 8xGE 4xSFP
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network - Networking standards - IEEE 802.3at
Network - Number of VLANs - 4000
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - MAC address-based VLAN
Network - Virtual LAN features - MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Network - Virtual LAN features - Protocol-based VLAN
Network - Virtual LAN features - Tagged VLAN
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.3af, IEEE 802.3at
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - 16
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - 4
Number of VLANs Network - 4000
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Heat dissipation - 628 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packet buffer memory Data transmission - 4.1 MB
Password protection Security - Yes
Performance - Fanless - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 184.7 W
Power - Power source - AC/PoE
Power consumption - 184.7 W
Power consumption (max) Power - 184.7 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 16
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 150 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) power per port Power over Ethernet (PoE) - 30 W
Power over Ethernet plus (PoE+) ports quantity Power over Ethernet (PoE) - 16
Power source Power - AC/PoE
Power supply - 100-240V AC, 50/60Hz
Power supply - External
producer - TP-LINK
producerCode - SG2428LP
Product colour Design - Grey
ProductName - Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
productName - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
productSize - Normal
QoS - 802.1p CoS/DSCP priority 8 priority queues Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin) Queue Weight Config Bandwidth Control: Port/Flow-based Rating Limit Smoother Performance Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control
Quality of Service (QoS) support Management features - Yes
Rack mounting Design - Yes
Security - Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv1/SSHv2 IP/Port/MAC-based access control
Security - Access Control List (ACL) - Yes
Security - DHCP features - DHCP relay
Security - DHCP features - DHCP relay, DHCP server
Security - DHCP features - DHCP server
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - Password protection - Yes
Series - Omada
SFP module slots quantity Ports & interfaces - 4
Short description - TP-LINK Switch SG2428LP Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
ShortSummaryDescription - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+, Managed, L2/L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
sizeX - 105
sizeY - 536
sizeZ - 341
Spanning tree protocol Network - Yes
Stackability - Yes
Stck_Kart - 9998
Stck_Pal - 7
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Storno - Y
Summary - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - SMART
Switching capacity Data transmission - 56 Gbit/s
Switch layer - L2
Switch layer - L2+
Switch layer Management features - L2/L2+
Switch type Management features - Managed
Throughput - 56 Gb/s
Title - TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 150 W
Unit Box Height - 0.1
Unit Box Length - 0.535
Unit Box Width - 0.34
Unit Calculated Volume - 0.02178 cubm
Unit Calculated Weight - 4.35 kg
Units per Shipping Box - 4
URL - https://www.tp-link.com/au/business-networking/omada-switch-smart/sg2428lp/#highlights
Vendor Homepage - https://www.tp-link.com/au/business-networking/omada-switch-smart/sg2428lp/#highlights
vendpn - SG2428LP
Virtual LAN features Network - MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
VLAN - VLAN Group: Max. 4K VLAN Groups 802.1Q tag VLAN MAC VLAN: 12 Entries Protocol VLAN GVRP Voice VLAN
VLAN support Network - Yes
Warranty - 24 months
WarrantyInfo - 5 Years
warrantyLength - 24
warrantyType - G
Web-based management Management features - Yes
Weight - 4.06
weight - 4000
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
Width Weight & dimensions - 440 mm
