Ubiquiti USW-Pro-8-POE, 8x1Gb POE, 2SFP

10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Home and small office
brand - Ubiquiti
category - Ubiquiti > UniFi komutatori > Professional
Category 1 - Netzwerk
Category 2 - Switching Hubs
Certificates - CE, FCC, IC
Chassis type - Rack
Console port - No
Data transmission - Jumbo frames support - Yes
Data transmission - Static route - Yes
Data transmission - Switching capacity - 56 Gbit/s
Data transmission - Throughput - 28 Gbit/s
Description - USW-PRO-8-POE to przełącznik sieciowy, obsługujący warstwę 3, wyposażony w budżet PoE o mocy 120 W. Posiada dwa gniazda SFP+ o prędkości 10 Gb/s oraz wygodny mały ekran dotykowy. Urządzenie zapewnia przepustowość 1 Gb/s na ośmiu portach RJ45, z czego 6 portów obsługuje PoE+ (Power over Ethernet) o mocy 1 GbE, a 2 porty obsługują PoE++ o mocy również 1 GbE.
Design - Certification - CE, FCC, IC
Design - Form factor - 1U
Design - Housing material - Metal
Design - Housing material - Plastic
Design - LED indicators - Activity
Design - LED indicators - Link
Design - LED indicators - PoE
Design - LED indicators - Speed
Design - LED indicators - System
Design - Product colour - White
Designation - CE+WEEE
dimensionalWeight - 1613
dimension depth - 80 mm
dimension height - 370 mm
Dimensions - 200 x 248 x 44 mm
dimension weight - 2500 g
dimension width - 260 mm
ean - 810084692691
EAN - 0810084692691
Environment requirements - Temperatura otoczenia podczas pracy: -5 do 45° C Wilgotność otoczenia podczas pracy: 10 do 90% bez kondensacji
Fan - No
Gross Weight Kg - 3
guarantee - 24
guarantee_type - normal
height - 0.1 m
L2 features -
L3 features -
length - 0.37 m
Management, monitoring, configuration -
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Manufacturer - Ubiquiti
Manufacturer Code - USW-PRO-8-POE
Manufacturer Name - Ubiquiti Networks
mpn - USW-Pro-8-POE
MPN - USW-PRO-8-POE
Name - 8+2P Ubiquiti UniFi USW-Pro-8-POE 120W
name - Switch UniFi 8 PoE USW-PRO-8-POE, 6 ports 1 GbE PoE+, 2 ports 1 GbE PoE++, 2 ports 10G SFP+, 120W
Network - 10G support - Yes
Network - Auto-sensing - Yes
Network - Auto MDI/MDI-X - Yes
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 10BASE-TX
Network - Copper ethernet cabling technology - 100BASE-FX
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 8
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE++ ports - 2
Number of PoE+ ports - 6
Number of PoE ports (PoE & PoE+) - None
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of SFP+ ports - 2
Number of SFP56 ports - None
Number of SFP ports - None
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 45 °C
Other features -
Other functions -
Packaging data - Manual - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP+ module slots quantity - 2
Power - AC input voltage - 100 - 240 V
Power - Input current - 2 A
Power - Number of power supply units - 1
Power - Power source - AC/DC
Power - Power supply included - Yes
Power consumption - 30 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 60 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 2
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 6
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 120 W
Power supply - Metoda potęgowa: Uniwersalne wejście, 100240 V AC, maks. 2 A. Zasilacz: AC/DC, wewnętrzny Obsługiwany zakres napięcia: 100240 V prądu przemiennego
Power supply - Internal
producer - UBIQUITI
producerCode - USW-Pro-8-PoE
productName - Ubiquiti UniFi USW-PRO-8-POE network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White
productSize - Normal
QoS -
Security -
Security - Authentication - Port-based authentication
Security - Authentication type - IEEE 802.1x, RADIUS
Security - DHCP features - DHCP server
Short description - Ubiquiti Switch UniFi 8xRJ45 GBit/2xSFP+ Managed PoE+ 120W Wall-Mountable, 1,3" Touchscreen
sizeX - 365
sizeY - 85
sizeZ - 260
Stackability - No
Supported protocols and standards -
Support for Jumbo frames - Yes
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - Federal Communications Commission (FCC)
Sustainability - Sustainability compliance - Yes
Switch class - Managed
Switch layer - L3
Technical details - Compliance certificates - CE
Technical details - Compliance certificates - Federal Communications Commission (FCC)
Throughput - 28 Gb/s
title - Ubiquiti UniFi Switch Pro 8 PoE
vendpn - USW-PRO-8-POE
VLAN -
warrantyLength - 24
warrantyType - G
Weight - 2.1 kg
Weight - 2.7
weight - 3 kg
weight - 2725
Weight & dimensions - Depth - 248 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.1 kg
Weight & dimensions - Width - 200 mm
width - 0.26 m
