Solidigm D3-S4520 - 1.92TB - SSD - SATA 3.0

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 951853 Product code: SSDSC2KB019TZ01
Can be ordered 15 units Availability: 14 days after order approval
Warranty: 3 years
271.92 €
Ready for dispatch
12.06.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPost parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Type: SATA
  • Read speed (sequential): 550 MB/s
  • Interface: SATA III (6Gb/s)
Basic information
Type : SATA
Read speed (sequential) 550 MB/s

Sequential read speed or the mean data reading speed is the most important criterion of the high-speed operation of the SSD. The data from the SSD will be read much more often than written to it because the operating system stores the processed data in the RAM in most cases.

If you want the reading speed of the purchased SSD to exceed the speed of the classic HDD considerably you should choose the SSD with the reading speed of 200 MB/s or above. The additional increase in the performance will be achieved on the account of the data search (SeekTime) which is of much higher level with SSDs than any HDD.

Ports and equipment
Interface : SATA III (6Gb/s)
Interface SATA

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

More detailed specification
Category_1 - Hard Drives and Pendrives
Category_2 - Internal SSD
dimensionalWeight - 46
EAN_code - 0735858482684
Features - Commodity Classification Automated Tracking System (CCATS) - G162706
Features - Component for - Server/workstation
Features - Data transfer rate - 6 Gbit/s
Features - DWPD - 3
Features - End-to-End Data Protection - Yes
Features - Enhanced Power Loss Data Protection technology - Yes
Features - Export Control Classification Number (ECCN) - 5A992C
Features - Hardware encryption - Yes
Features - Harmonized System (HS) code - 84717070
Features - HP segment - Enterprise
Features - Interface - Serial ATA
Features - Mean time between failures (MTBF) - 2000000 h
Features - Memory type - TLC 3D NAND
Features - NVMe - No
Features - Product series - S4520
Features - Random read (4KB) - 91000 IOPS
Features - Random read (100% span) - 91000 IOPS
Features - Random write (4KB) - 38000 IOPS
Features - Random write (100% span) - 38000 IOPS
Features - Read speed - 550 MB/s
Features - Security algorithms - 256-bit AES
Features - SSD capacity - 1.92 TB
Features - SSD form factor - 2.5"
Features - SSD temperature monitoring - Yes
Features - Uncorrectable Bit Error Rate (UBER) - < 1 per 10^17 bits read
Features - Write speed - 510 MB/s
Manufacturer - Solidigm
Manufacturer_code - SSDSC2KB019TZ01
Name - Solidigm D3-S4520 - 1.92TB - SSD - SATA 3.0
Operational conditions - Maximum operating temperature - 70 °C
Operational conditions - Non-operating shock - 1000 G
Operational conditions - Non-operating vibration - 3.13 G
Operational conditions - Operating shock - 1000 G
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Operational conditions - Operating vibration - 2.17 G
Other features - Internal memory type - SATA 3.0 6Gb/S
Other features - Launch date - Q3'21
Other features - Power consumption (active) - 3.1 W
Other features - Processor family - Intel SSD D3
Other features - Sequential reading - 550 MB/s
Other features - Sequential writing speed - 510 MB/s
Other features - SSD endurance rating - 8.8 PBW
Other features - SSD shock - 1000G,0.5ms
Other features - Status - Launched
Power - Power consumption (idle) - 1.1 W
Power - Power consumption (read) - 3.1 W
Power - Power consumption (write) - 3.1 W
producerCode - SSDSC2KB019TZ01
productName - SSD Solidigm (Intel) S4520 1.92TB SATA 2.5" SSDSC2KB019TZ01 (DWPD up to 3)
productSize - Normal
Safety warning - Warnings - Do not open the appliance casing, risk of damage.
Safety warning - Warnings - In the event of damage, do not dispose of in the normal rubbish bin, contact the relevant electronics disposal unit.
Safety warning - Warnings - Protect from moisture and extreme temperatures.
sizeX - 140
sizeY - 110
sizeZ - 15
warrantyLength - 60
warrantyType - G
Weight - 0,09
weight - 85
