Patriot P320, 512GB, M.2 Gen3 x4

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1110127 Product code: P320P512GM28
In stock 17 units
Warranty: 3 years
109.32 €
Ready for dispatch
on Thuesday, 10.02.2026
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Unisend parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Capacity: 512 GB
  • Type: NVMe
  • Read speed (sequential): 3000 MB/s
  • Write speed (sequential): 2200 MB/s
  • Form factor: M.2 80mm (2280)
  • Interface: PCIe 3.0 x4
Description

We offer to purchase a Patriot M.2 80mm (2280) format SSD drive with a 512 GB capacity.

The disk is equipped with the currently most advanced and compact M.2 connection port.

This is an NVME type SSD drive. It uses the PCI-e protocol, which allows data to be transmitted over multiple lines at the same time. This type of drive is ideal for processing large files, gaming, video editing, and other resource-intensive tasks.

The read speed for this SSD drive reaches 3000 MB/s. However, it's crucial to note - if the "fast" drives are not provided with adequate cooling, they may not be able to operate at the speed indicated by the manufacturer.

The write speed (Sequential write speed) of this SSD is 2200 MB/s. However, if adequate cooling is not provided, "fast" drives may not achieve the speeds guaranteed by the manufacturer.

This SSD drive has an M.2 80mm (2280) format.

This SSD drive interface is PCIe 3.0 x4. If you insert this drive into an older interface slot, the speed of the drive will decrease, as the drive will not have sufficient data transfer speed (Bandwidth).

Basic information
Capacity 512 GB
The HDD capacity in Gigabytes indicates how much information can be stored by the HDD. The capacity of the HDD is fixed and cannot be increased after buying the HDD. Therefore, upon buying the HDD you should verify its compliance with your current volume requirements and provides a reserve for future needs.
Type : NVMe
Read speed (sequential) 3000 MB/s

Sequential read speed or the mean data reading speed is the most important criterion of the high-speed operation of the SSD. The data from the SSD will be read much more often than written to it because the operating system stores the processed data in the RAM in most cases.

If you want the reading speed of the purchased SSD to exceed the speed of the classic HDD considerably you should choose the SSD with the reading speed of 200 MB/s or above. The additional increase in the performance will be achieved on the account of the data search (SeekTime) which is of much higher level with SSDs than any HDD.

Write speed (sequential) 2200 MB/s

The writing speed is almost as important as the reading speed. Also this parameter determines the performance of the SSD, however, as the writing to the disc happens not as often as the data reading and average user will find it subjectively difficult to distinguish between any speed above 100 MB/s and higher indices, except the cases when the SSD is used in a server, for audio/video recording, etc.

Functionality
Radiators : Nav
Lighting : Nav
Ports and equipment
Form factor M.2 80mm (2280)

Thanks to the small size provided by the SSD technology the standard size of the discs is 2.5", and it is suitable for an average portable computer. It is possible to install the 2.5" disc in the desktop computer if the transition 2.5" -> 3.5" is used, and this transition can be bought at a low cost at TopPC.ee section"Adapteri". The discs with the format 2.5" + 3.5" have this transition included.

1.8" discs are intended for the ultra-compact class portable computers.

PCI-Express SSDs are intended for desktop computers with a free PCI-Express plug available. This technology in most cases is used for ensuring the performance that exceeds the possibilities of other types of connections.

Interface : PCIe 3.0 x4
Interface M.2

SSDs with SATAII and SATAIII connection are compatible with the connections of both types in the motherboard. Still, it has to be taken into account that the motherboard SATAII connection can provide maximum about 300 MB/s transmission capacity which can reduce the actual transmission capacity of the SSDs whose reading and/or writing speed exceeds this level to the capacity limits of the SATAII.

The situation is similar with the PCI-Express and SATAIII connection slots. Although the SATAIII standard can provide up to 600 MB/s data transmission capacity there are SSDs with the speed exceeding this limit, in this case the manufacturer chooses the PCI-Express connection slot with a higher transmission capacity. The PCI-Express discs cannot be connected to the portable computer.

Specifikācija
Memory type : Not specified
Random Read IOPS : Not specified
Random Write IOPS : Not specified
Endurance (TBW) : 240 TB
More detailed specification
Category_1 - Hard Drives and Pendrives
Category_2 - Internal SSD - M.2
Color - Not applicable
Depth - 80 mm
Description - SSD 512GB P320 PCIe M.2 Gen3 x4 NVMe 3000/2200MB/s The P320 is Patriots next generation of high-tier PCIe gen 3x4 NVMe SSD to hit the market, offering much higher transfer speeds and IOPs than standard PCIe 3x2 solutions. The compact m.2 form factor is designed for easy installation and will fit into any PC or laptop, while its low power consumption helps extend laptop battery life. The P320 is guaranteed to improve start-up, loading, and transfer times over traditional hard disk drives. The P320s advanced firmware offers thermal throttling technology and end-to-end data path protection to ensure data integrity throughout the life to the drive. Advanced wear-leveling and thermal management features extend the life of the drive for maximum use. Boost your computers performance with quicker application loading times for a better overall experience and productivity while transferring heavy workloads without the lag. Backed by our 5-year warranty, Patriots P320 delivers one of the most reliable price-to-performance SSDs on the market
Designation - CE+WEEE
dimensionalWeight - 40
dimension depth - 1 mm
dimension height - 135 mm
dimension weight - 20 g
dimension width - 20 mm
Disk type - SSD
Drive type - Internal
ean - 4711378427615
EAN_code - 4711378427615
Features - Certificates - CE
Features - Certificates - FCC
Features - Certificates - RoHS
Features - Certificates - UKCA
Features - Component for - PC
Features - M.2 SSD size - 2280 (22 x 80 mm)
Features - NVMe - Yes
Features - Sequential read speed (ATTO) - 3000 MB/s
Features - Sequential read speed (CDM) - 3000 MB/s
Features - Sequential write speed (ATTO) - 2200 MB/s
Features - Sequential write speed (CDM) - 2200 MB/s
Features - SSD capacity - 512 GB
Features - SSD form factor - M.2
Features - SSD interface - PCIe Gen 3 x4
Features - TBW rating - 240
Form factor (width) - M.2 2280
guarantee - 60
guarantee_type - normal
HDD capacity - 512 GB
HDD interface - PCIe 3.0
Height - 3.8 mm
Manufacturer - Patriot
Manufacturer_code - P320P512GM28
Model - P320
Name - Patriot P320 512GB (PCIe 3.0 x4, NVMe 1.3, M.2 2280)
name - SSD 512GB P320 PCIe M.2 Gen3 x4 NVMe 3000/2200MB/s
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
producer - Patriot
producerCode - P320P512GM28
productName - SSD PATRIOT VIPER P320 M.2 PCI-Ex4 NVMe 512GB 3GB/S (P320P512GM28)
productSize - Normal
Reading speed - 3000 MB/s
sizeX - 135
sizeY - 100
sizeZ - 15
TBW - 240 TB
vendpn - P320P512GM28
warrantyLength - 36
warrantyType - G
Weight - 0,02
Weight - 11 g
weight - 20
Weight & dimensions - Height - 3.8 mm
Weight & dimensions - Length - 80 mm
Weight & dimensions - Weight - 11 g
Weight & dimensions - Width - 22 mm
Width - 22 mm
Writing speed - 2200 MB/s
