Audio - Crossover frequency - 2000 Hz
Audio - Frequency range - 54 - 30000 Hz
Audio - RMS rated power - 70 W
Audio - Sensitivity - -10 dB
Brand - Yamaha
BrandPartCode - HS5W
Category - Loudspeakers
dimensionalWeight - 6811
GTIN - 4957812558259
LongDesc - Ever since the 1970's the iconic white woofer and signature sound of Yamaha's nearfield reference monitors have become a genuine industry standard for a reason - their accuracy. Unlike studio monitors with added bass or treble frequencies which may sound more flattering at first, HS Series speakers were designed to give you the most honest, precise reference possible, providing an ideal sonic platform to build on throughout the mixing process. By combining acquired knowledge and expertise with state-of-the-art sound technologies, Yamaha's speaker engineering team have examined, then optimized, every aspect that has contributed to making these monitors the most trusted in the business. The second generation HS Series also adds a new 6.5" model to the lineup, bringing its exceptional accuracy to an even greater variety of recording environments.Home studiosNow you can easily add extremely accurate professional monitors to your home studio that accommodate a wide range of input sources such as mixers, keyboards, and audio interfaces via XLR or TRS phone jack inputs. The versatile lineup of HS powered speakers can match a variety of room sizes and monitoring environments and even come equipped with a ROOM CONTROL feature can attenuate the unnatural low-end that can occur if they are placed next to a wall.Control roomsThe new HS-I models feature mounting points that allow for fast and easy installation in control rooms for theaters and halls. Because HS speakers come equipped with a built-in amplifier, users can easily configure a compact system for rooms with size limitations.Cafes and restaurantsHS-I models feature flexible mounting options that allow users to easily add the signature HS sound and stylish design to cafes or restaurant environments where superior audio quality is a priority. Models come in both black and white color options to match the design aesthetic of a vast array of commercial spaces.Recording studiosAdhering to the Yamaha philosophy of sonic purity, the HS Series carries on the tradition of being one of the most trusted speakers for nearfield monitoring applications, lauded for the signature sound and superior accuracy achieved by our very own meticulously selected transducers. Sound Philosophy of HS Series Studio MonitorsWhen selecting studio reference monitors for mixing and music production, one consideration takes precedence above all others - accuracy.Beginning with the legendary NS-10M, and continuing with the MSP and previous HS Series, this new lineup shares a design philosophy that emphasizes sonic purity without any coloring or alternation of the original sound. While many manufacturers seek to enhance the sound of their monitors to make them sound impressive, Yamaha studio monitors are designed to achieve the best possible mix by ensuring that the sound from your speakers is true to the original. HS Series nearfield reference monitors are the embodiment of this philosophy, delivering a concise sound image, high resolution, and flat response.Highly efficient TransducersThe HS Series features newly developed transducers that achieve astonishingly smooth response over a wide range of bandwidth. These transducers utilize an advanced magnetic field design that regulates the flow of magnetic response to provide seamless, natural sonic transitions. Each component's materials and design were carefully re-examined, then optimized, to drastically improve the accuracy of signal reproduction throughout the audio spectrum.- TweeterThe HS Series features a newly designed, highly efficient 1" dome tweeter that extends the usable frequency range considerably and delivers superb high-resolution sound. Utilizing a thick wave guide designed to minimize vibration the new tweeter is able to deliver smooth, distortion-free high end up to 30 kHz.- WooferWith newly designed, ultra-responsive woofers that utilize large, carefully selected magnets, HS Series monitors produce low distortion sound with a well-defined bottom end at any output level. All of the components in these high-power woofers, including the woofer ring and the basket further contribute to the HS Series' stunning bass while providing clear, accurate mids.High Performance Amp UnitHS Series speakers employ an amplifier unit perfectly matched to the transducers utilized in each model of the series. Featuring a bi-amp design with a separate dedicated amp for both the woofer and the tweeter, this amplifier unit ensures that each HS Series speaker consistently delivers high-resolution sound with exceptionally flat response across the sound spectrum.Low Resonance Enclosure DesignHS Series cabinets are designed to eliminate unwanted resonance and increase the accuracy of sound reproduction to their extreme limit. The enclosures are constructed from a very dense and resilient MDF with a damped acoustic response that is perfectly suited for reference monitors. Drawing from Yamaha's over 100 years of piano design experience, HS Series engineers also employed a traditional three-way mitered-joint technique. Common to architectural design this construction firmly anchors the corners of the enclosure to dramatically improve durability and eliminate unwanted resonance that can influence overall sound.Cutting Edge Noise Reduction TechnologySpeaker port design can greatly influence the clarity of overall sound. Often a vortex at the either end of the port can generate air vibrations inside of the port, causing unwanted noise. By adopting an advanced noise reduction technology that incorporates a thorough analysis of a visual representation of the sound, Yamaha's engineers are able to control and reduce the vortex. Through this in-depth analysis we have arrived at the ideal port design, resulting in a reduction of audible noise up to 6dB. The utilization of this state-of-the-art technology allows HS Series studio monitors to meet the demands of more strict professional production environments.Controls and ConnectivityHS Series full-range models feature two response controls with detailed settings that allow them to adapt to the surface acoustics of rooms of varying shape and size. ROOM CONTROL allows you to attenuate the unnatural, exaggerated low-end that can often occur when speakers are placed next to walls, while HIGH TRIM allows for more flexible control of high frequency response. For inputs, HS full-range speakers can accommodate a wide range of balanced and unbalanced sources such as mixers, keyboards and audio interfaces with XLR and TRS phone jacks. With the HS8S subwoofer, HIGH CUT control sets the cutoff frequency of subwoofer output high-frequency attenuation from 80Hz to 120Hz, while PHASE switch adjusts the phase of the subwoofer output. The LOW CUT switch and LOW CUT controls enables attenuation of low frequencies for output between 80Hz and 120Hz. The HS8S subwoofer is equipped with XLR and TRS phone jack for inputs and XLR for outputs.
LongProductName - HS5, 2-way, 54Hz - 30kHz, 5" cone, " dome, 70 W, XLR3-31, Phone, 170x285x222 mm, white
LongSummaryDescription - Yamaha HS5. Recommended usage: Studio. Speaker type: 2-way, Number of drivers: 2. Connectivity technology: Wired. RMS rated power: 70 W, Frequency range: 54 - 30000 Hz, Sensitivity: -10 dB. Product colour: White
Loudspeakers - Audio output channels - 1.0 channels
Loudspeakers - Number of drivers - 2
Loudspeakers - Speaker placement - Floor
Loudspeakers - Speaker placement - Tabletop/bookshelf, Wall-mountable
Loudspeakers - Speaker type - 2-way
Loudspeakers - Tweeter - Yes
Loudspeakers - Tweeter diameter (imperial) - 2.54 cm (1")
Loudspeakers - Woofer - Yes
Loudspeakers - Woofer diameter (imperial) - 12.7 cm (5")
Other features - Bi-amping - Yes
Other features - Equalizer - Yes
Packaging content - Cables included - AC
Packaging content - Manual - Yes
Performance - Bass reflex - Yes
Performance - Housing material - MDF
Performance - LED indicators - Power
Performance - Plug and Play - Yes
Performance - Product colour - White
Performance - Recommended usage - Studio
Performance - Recommended usage - Universal
Performance - Suitable for outdoor use - No
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - XLR in - Yes
Power - Power consumption (typical) - 45 W
Power - Power source type - AC
producerCode - HS5 W
ProductName - HS5
productName - Yamaha HS5 loudspeaker 2-way white 70 W
productSize - Normal
ShortSummaryDescription - Yamaha HS5, 2-way, Wired, 70 W, 54 - 30000 Hz, White
sizeX - 306
sizeY - 420
sizeZ - 265
Title - Yamaha HS5 2-way White Wired 70 W
URL - https://www.yamahaproaudio.com/global/en/products/speakers/hsseries/index.jsp
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 7400
Weight & dimensions - Depth - 222 mm
Weight & dimensions - Height - 285 mm
Weight & dimensions - Weight - 5.3 kg
Weight & dimensions - Width - 170 mm
