Accessories included - OLS6KERT5UM UPS Detachable Maintenance Bypass PDU Rack Rails Rack Brackets Rail Kit Screw Kit Power Cord USB Cable User Manual
Active power - 6000 W
Apparent power - 6 kVA
Backup time (100% load) - 7.6 min
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Charging current - 4 A
Battery - Number of batteries supported - 10
Battery - Typical backup time at full load - 7.6 min
Battery - Typical backup time at half load - 23 min
Battery capacity - 9 Ah
Brand - CyberPower
BrandPartCode - OLS6KERT5UM
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE, RoHS
Charging time - 4 h
Chassis type - Rack
Chassis type - Tower
Color - Black
Data Act - Link and Link
Description - CyberPower OLS6KERT5UM is a high-efficiency UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS, servers, DVRs/surveillance systems, transportation, infrastructure, and emergency systems. Its typically integrated into the back office, server room, and data center environment. With high output power factor, the UPS in a smaller footprint can provide more usable power and save rack space. The product allows multiple UPS units to be connected in parallel, achieving higher capacity and power redundancy. The pre-installed Maintenance Bypass PDU (MBP) offers quick and safe maintenance without power interruption. Moreover, the tiltable color LCD comes with an intuitive and graphical interface, allowing users to monitor and configure settings with ease. Besides, the battery charging current is adjustable via LCD setting to shorten charging time. It is also designed with relay-type dry contact port to support specific UPS event notifications for easy management. UPS topology: online double conversion High output power factor Overload protection UPS parallel expansion (optional) Extended battery module (EBM) Color LCD panel Emergency Power Off (EPO) port PowerPanel management software Rack/tower convertible design ECO mode Pure sine wave output Zero transfer time Maintenance bypass switch Auto-detection of additional battery modules Tiltable LCD panel Relay-type dry contact SNMP/HTTP remote management capability
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - Housing material - Metal
Design - LED indicators - Operation
Design - Product colour - Black
Design - Rack capacity - 5U
Designation - CE+WEEE
dimension depth - 530 mm
dimension height - 370 mm
Dimensions - 433 x 213.5 x 661 mm
dimension weight - 87200 g
dimension width - 825 mm
ean - 4711027791289
Environment requirements - Operating temperature: 0 ~ 40°C Storage temperature: -15 ~ 45°C Operating relative humidity (non-condensing): 0 ~ 95% Storage relative humidity (non-condensing): 0 ~ 95%
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features - Crest factor - 3:1
Features - ECO mode - Yes
Features - Emergency Power Off (EPO) - Yes
Features - EMI/RFI noise filtering - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 110 V
Features - Input power factor - 0.99
Features - Maximum current - 27.3 A
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 208 V
Features - Output power - 6000 W
Features - Output power capacity - 6 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 2%
Features - Power factor - 1
Features - Power protection features - Overload
Features - Response time - 0 ms
Features - Surge energy rating - 1335 J
Features - Surge protection - Yes
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Pure sine
Filters / protection - Overload
Filters / protection - Surge
GTIN - 4711027791289
guarantee - 24
guarantee_type - external
I/O connectors - 1 x EPO
I/O connectors - 1 x inpot dry contact
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input power ports - Input terminal
Logistics data - Country of origin - China
Logistics data - Harmonized System (HS) code - 8504408690
LongDesc - CyberPower OLS6KERT5UM is a high-efficiency UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS, servers, DVRs/surveillance systems, transportation, infrastructure, and emergency systems. It’s typically integrated into the back office, server room, and data center environment.With high output power factor, the UPS in a smaller footprint can provide more usable power and save rack space. The product allows multiple UPS units to be connected in parallel, achieving higher capacity and power redundancy. The pre-installed Maintenance Bypass PDU (MBP) offers quick and safe maintenance without power interruption. Moreover, the tiltable color LCD comes with an intuitive and graphical interface, allowing users to monitor and configure settings with ease. Besides, the battery charging current is adjustable via LCD setting to shorten charging time. It is also designed with relay-type dry contact port to support specific UPS event notifications for easy management.
LongProductName - Smart App UPS for Network and Server
LongSummaryDescription - CyberPower OLS6KERT5UM. UPS topology: Double-conversion (Online), Output power capacity: 6 kVA, Output power: 6000 W. AC outlet types: C13 coupler, C19 coupler, AC outlets quantity: 8 AC outlet(s), Serial interface type: RS-232. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 7.6 min, Typical backup time at half load: 23 min. Form factor: Rackmount/Tower, Product colour: Black, Housing material: Metal. Certification: CE, RoHS
name - UPS OLS6KERT5UM 6000VA/ 6000W OnLine R/T 5U 20x9AH/12V, 4xC13, 4xC19 MBP, RMCARD205
No. of batteries - 20
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 1000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Output power ports - 4 x IEC-C13
Output power ports - 4 x IEC-C19
Output power ports - Output terminals
Packaging content - Cables included - USB cable
Packaging data - Package depth - 800 mm
Packaging data - Package height - 650 mm
Packaging data - Package weight - 79 kg
Packaging data - Package width - 600 mm
Ports & interfaces - AC outlets quantity - 8 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
producer - CyberPower
ProductName - OLS6KERT5UM
ShortSummaryDescription - CyberPower OLS6KERT5UM, Double-conversion (Online), 6 kVA, 6000 W, Pure sine, 110 V, 300 V
Software - PowerPanel Business (Recommended)
Special functions - Energy-saving technology Active PFC compatibility Smart Battery Management (SBM) EMI/RFI filtering LCD information display: Operating mode, Power status, Battery status, Load status, Fault and warning, Additional information, Events and log LCD settings and control: Mode settings, Alarm settings, Input and output, Battery settings, Fault and warning, Communication, Events and log, Security settings Audible alarms: Battery mode, Low battery, Overload, Overcharge, Overtemperature, UPS fault, Replace battery Remote SNMP / HTTP monitoring: includes RMCARD205 PowerPanel Cloud service 90-day free trial
The shape of the output voltage - Full sine wave
Title - CyberPower OLS6KERT5UM uninterruptible power supply (UPS) Double-conversion (Online) 6 kVA 6000 W 8 AC outlet(s)
UPS Architecture - on-line double conversion
URL - https://www.cyberpower.com/de/en/product/sku/ols6kert5um
vendpn - OLS6KERT5UM
Voltage - 12 V
WarrantyInfo -
Weight - 78.9 kg
Weight & dimensions - Depth - 661 mm
Weight & dimensions - Height - 213.5 mm
Weight & dimensions - Weight - 68 kg
Weight & dimensions - Width - 433 mm
