Eaton ELP650DIN, 650VA 400W

ACoutletsquantity - 4 AC outlet(s)
ACoutlettypes - Type F
ARTIKEL1 - EATON ELLIPSE PRO 650 DIN
ARTIKEL2 - IN
AutomaticVoltageRegulationAVR -
Battery -
Batterycapacity -
Batterytechnology - Sealed Lead Acid (VRLA)
Batteryvoltage -
Breite - 0.32
Cablesincluded -
Category Code - UPW
Certificates > Certification - IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC
CnCode - 85044095
Code - ELP650DIN
Colour - Black
Depth - 285 mm
Description - Eaton Ellipse PRO 650 DIN
Design -
Design > Form factor - Tower
Desktop/pedestal Mounting Type - Yes
Dimensions - 260 x 82 x 285mm
Displaytype - LCD
EAN - 743172437266
EANCode - 0743172437266
Efficiency -
Features -
Features > Colour of product - Black
Formfactor - Tower
Gewicht - 7.71
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
Heatdissipation -
Height - 260 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0.14
Hotswapbattery - No
HSTNUMMER - ELP650DIN
Inputfrequency - 50/60 Hz
Inputoperationvoltagemax - 285 V
Inputoperationvoltagemin - 150 V
Input ports - Single, IEC320 C14 (10AMP)
Link - https://www.eaton.com/dk/en-gb/skuPage.ELP650DIN.html
LongDesc - The Eaton Ellipse PRO 650–1600VA is a line interactive UPS specifically developed to protect workstations running demanding applications. The Ellipse PRO features an LCD display for real-time status and measurements. It also features EcoControl power outlets, which enable energy savings up to 20 percent and Advanced Surge Reduction (ASR) that complies fully with the requirements of the IEC 616431-1 standard.
ManufDatasheet -
Name - Eaton | UPS | Ellipse PRO 650 DIN | 650 VA | 400 W
Networkcardslot -
Noiselevel -
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Operatingaltitude -
OperatingrelativehumidityHH -
OperatingtemperatureTT -
Operationalconditions -
Other features > Special features - Convenient extra-flat design for easy installation in any office environment; Automatic Voltage Regulation (AVR); High performance surge-protection device compliant with IEC 61643-11 standard; Data line protection to ensure that the internet line (including xDSL) is protected against surges; LCD display for real-time status and measurements; 4 outlets to connect your PC + peripherals; EcoControl function helps you save up to 20 % energy compared to previous generation UPSs; HID-compliant USB port (cable supplied), for automatic integration with major operating systems (Windows/Mac OS/Linux); Easy to replace battery helps to extend UPS service life
Outputfrequency - 50 Hz
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 220 V
Outputpower - 400 W
Outputpowercapacity - 0.65 kVA
Output power capacity, VA - 650 VA
Output power capacity, W - 400 Watts
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 390.00 mm
Package features > Gross height (mm) - 315 mm
Package features > Gross width (mm) - 140 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 100 pc(s)
Package features > Paper/Pasteboard - 800.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.90 kg
Package features > TI weight (kg) - 5.00 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.017199 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Performance > Capacity - 650 VA
Performance > UPS topology - Line-Interactive
Ports & interfaces > AC outlets quantity - 4
Portsinterfaces -
Powerfactor -
Powerplug - C14 coupler
ProdDesc - 650VA/400W UPS, line-interactive, DIN 3+1
Producer product family - UPS
Producer product name - Ellipse PRO 650 DIN
Productcolour - Black
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 0.65 kVA 400 W
• 4 AC outlet(s)
• Sealed Lead Acid (VRLA)
• Tower Black

Product Net Weight - 6.6 kg
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/ELP650DIN_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/ELP650DIN_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/ELP650DIN_3.jpg
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide -
Rack Mounting Type - Yes
Rackmountkit -
RS232ports -
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
Stck_Kart - 9998
Stck_Pal - 13
Storno - Y
Technical details > Capacity - 400 W
Technical details > Gross weight - 7.7 kg
Technical details > Net weight - 6.8 kg
Technical details > Producer - Eaton
Topology - LineInteractive
Typicalbackuptimeathalfload - 9 min
Unit Box Height - 0.32
Unit Box Length - 0.392
Unit Box Width - 0.14
Unit Calculated Volume - 0.01756 cubm
Unit Calculated Weight - 7.6 kg
Units per Shipping Box - 1
UPStopology - Line-Interactive
USB Communication ports - 1
USBport -
USBporttype -
Vendor Homepage - powerquality.eaton.com/ELP650DIN.aspx?cx=86
Warranty - 24 months
Warranty - 36
Warranty - 36 month(s)
Warrantyandmisc -
Waveform -
Weight - 6.6 kg
Weightdimensions -
Width - 82 mm
