Audio - ALL-IN-ONE - 8-channel
Audio - ALL-IN-ONE - Integrated
Audio - Audio output channels - 8-channel
Audio - Audio system - Integrated
Audio - Built-in speaker(s) - Yes
Audio - Number of speakers - 2
Audio - RMS rated power - 6 W
Brand - TERRA
BrandPartCode - 1000034
Category - All-in-One PCs/Workstations
Certificates - Certification - SMBios (DMI), EnergyStar 8.0, EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
The product meets the criteria of RAL UZ 78 (Blue Angel)
Design - ALL-IN-ONE - All-in-one
Design - ALL-IN-ONE - ISO 9001, Assembled in Germany ¦ Compatibility: SMBios (DMI), EnergyStar 8.0, EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Certification - ISO 9001, Assembled in Germany Compatibility: SMBios (DMI), EnergyStar 8.0, EN62368-1, EN55032, EN55035, EN61000-3-2/3, EN62623, 89/336/ECC
Design - Factor de forma - All-in-one
Design - Panel mounting interface - 100 x 100 mm
Design - Product colour - Black
Design - VESA mounting - Yes
Display - ALL-IN-ONE - 23.8"
Display - ALL-IN-ONE - 250 cd/m2
Display - ALL-IN-ONE - 1000:1
Display - ALL-IN-ONE - 1920 x 1080 ( Full HD )
Display - ALL-IN-ONE - LCD - 10-point Multitouch - capacitive
Display - ALL-IN-ONE - LED-Backlight
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness - 250 cd/m2
Display - Display brightness - 250 cd/m²
Display - Display diagonal - 23.8"
Display - Display diagonal - 60.5 cm (23.8")
Display - Display resolution - 1920 x 1080 ( Full HD )
Display - Display resolution - 1920 x 1080 pixels
Display - Display type - LCD - 10-point Multitouch - capacitive
Display - HD type - Full HD
Display - LED backlighting type - LED-Backlight
Display - Panel type - LCD
Display - Touchscreen - Yes
EAN - 4039407081714
General - ALL-IN-ONE - Intel Core i5 (14. Gen.) 14500 / max. Intel Turbo Boost Frequenzy 5.0 GHz, 24 MB Intel Smart Cache
General - ALL-IN-ONE - Windows 11 Pro
General - Operating system - Windows 11 Pro
General - Processor model - Intel Core i5 (14. Gen.) 14500 / max. Intel Turbo Boost Frequenzy 5.0 GHz, 24 MB Intel Smart Cache
Graphics - ALL-IN-ONE - Dynamisch
Graphics - ALL-IN-ONE - HDMI 2.0 max. 4096x2160 @ 60 Hz (4K), DP 1.4 4096x2304 @ 60 Hz (4K) ¦ Unterstützt Triple-Monitoring
Graphics - ALL-IN-ONE - Intel UHD Graphics
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - Maximum resolution - HDMI 2.0 max. 4096x2160 @ 60 Hz (4K), DP 1.4 4096x2304 @ 60 Hz (4K) Unterstützt Triple-Monitoring
Graphics - On-board GPU manufacturer - Intel
Graphics - On-board graphics adapter memory - Dynamisch
Graphics - On-board graphics card - Yes
Graphics - On-board graphics card family - Intel® UHD Graphics
Graphics - On-board graphics card model - Intel UHD Graphics
Graphics - On-board graphics card model - Intel UHD Graphics 770
Gross Weight Kg - 11,8
GTIN - 4039407081714
Input device - ALL-IN-ONE - USB
Input device - Device interface - USB
Keyboard - ALL-IN-ONE - USB
Keyboard - Device interface - USB
LongSummaryDescription - TERRA 1000034. Product type: All-in-One PC. Display diagonal: 60.5 cm (23.8"), HD type: Full HD, Display resolution: 1920 x 1080 pixels, Touchscreen, Panel type: LCD. Processor family: Intel® Core™ i5, Processor frequency: 2.6 GHz. Internal memory: 8 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 500 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro. Product colour: Black
Manufacturer Code - 1000034
Manufacturer Name - WORTMANN AG
Memory - ALL-IN-ONE - 1 x 8 GB
Memory - ALL-IN-ONE - 2
Memory - ALL-IN-ONE - 8 GB
Memory - ALL-IN-ONE - 64 GB
Memory - ALL-IN-ONE - 5600 MHz
Memory - ALL-IN-ONE - DDR5
Memory - Internal memory - 8 GB
Memory - Internal memory type - DDR5
Memory - Internal memory type - DDR5-SDRAM
Memory - Maximum internal memory - 64 GB
Memory - Memory clock speed - 5600 MHz
Memory - Memory layout (slots x size) - 1 x 8 GB
Memory - Memory slots - 2
Memory - Memory slots type - DIMM
Mouse - ALL-IN-ONE - Optional
Mouse - Mouse included - Optional
Network - ALL-IN-ONE - Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax ¦ Bluetooth 5.1
Network - ALL-IN-ONE - Realtek Gigabit LAN, WOL/ PXE
Network - Bluetooth - Yes
Network - Bluetooth version - 5.1
Network - Data link protocols - Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax Bluetooth 5.1
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - LAN controller - Realtek Gigabit LAN, WOL/ PXE
Network - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Network - Wi-Fi - Yes
Network - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Network - WLAN controller manufacturer - Intel
Network - WLAN controller model - Intel Wi-Fi 6 AX201
Operational conditions - ALL-IN-ONE - 5° C - 35° C
Operational conditions - ALL-IN-ONE - 10 - 75% (non-condensing)
Operational conditions - ALL-IN-ONE - 35 °C
Operational conditions - Intervalo de temperatura operativa - 5° C - 35° C
Operational conditions - Maximum operating temperature range (T-T) - 35 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 75%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Recommended humidity operating range - 10 - 75% (non-condensing)
Optical drive - ALL-IN-ONE - None
Optical drive - Optical drive type - None
Other features - ALL-IN-ONE - 1x 2.5" (HDD/ SSD) ¦ 1x M.2 type 2230, PCI Express + USB (already in use with M.2 WiFi/ BT modul) ¦ 1x M.2 type 2280 (SSD)
Other features - ALL-IN-ONE - 2x 3W Stereo Speaker¦ Bluetooth ¦ Kensington-Lock ¦ High-adjustable 105 mm ¦ Pivot functionion ¦ Swiveling -5°/ +20° ¦ VESA 100x100 mm ¦ TPM 2.0 ¦ Secure Boot ¦ Windows Autopilot-ready
Other features - ALL-IN-ONE - Active
Other features - ALL-IN-ONE - Cam: 5m Auflösung ¦ 2x 3W Stereo Speaker¦ Bluetooth ¦ Kensington-Lock ¦ High-adjustable 105 mm ¦ Pivot Function ¦ Swiveling -5°/ +20° ¦ ¦ VESA 100x100 mm
Other features - ALL-IN-ONE - Windows 10, Windows 11
Other features - Compatible operating systems - Windows 10, Windows 11
Other features - Expansion slots - 1x 2.5" (HDD/ SSD) 1x M.2 type 2230, PCI Express + USB (already in use with M.2 WiFi/ BT modul) 1x M.2 type 2280 (SSD)
Other features - Maximum cooling capacity - Active
Other features - Special features - 2x 3W Stereo Speaker Bluetooth Kensington-Lock High-adjustable 105 mm Pivot functionion Swiveling -5°/ +20° VESA 100x100 mm TPM 2.0 Secure Boot Windows Autopilot-ready Cam: 5m Auflösung 2x 3W Stereo Speaker Bluetooth Kensington-Lock High-adjustable 105 mm Pivot Function Swiveling -5°/ +20° VESA 100x100 mm
Packaging content - ALL-IN-ONE - Optional
Packaging content - ALL-IN-ONE - Quick Start Guide, PSU, Powercord EU
Packaging content - Included Accessories - Quick Start Guide, PSU, Powercord EU
Packaging content - Keyboard supplied - Optional
Performance - ALL-IN-ONE - 0,5 Sone
Performance - ALL-IN-ONE - Personal-Computer
Performance - Market positioning - Business
Performance - Nivel de ruido - 0,5 Sone
Performance - Product type - All-in-One PC
Performance - Product type - Personal-Computer
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
Ports & interfaces - Audio output - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Microphone in - Yes
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Power - AC adapter frequency - 50 - 60 Hz
Power - AC adapter input voltage - 100 - 240 V
Power - AC adapter input voltage - 100-240 V~ / 50-60 Hz
Power - ALL-IN-ONE - 100-240 V~ / 50-60 Hz
Power - ALL-IN-ONE - 120 Watt
Power - ALL-IN-ONE - Power adapter
Power - ALL-IN-ONE - Ø 2.0 Watt (S3 Mode, Suspend to RAM, WOL activated)
Power - ALL-IN-ONE - Ø 32 Watt Short Idle-Mode ¦ 103 kWh pro Jahr (ETEC = Typical Energy Consumption)
Power - Maximum input power - 120 Watt
Power - Nominal power - Ã 32 Watt Short Idle-Mode 103 kWh pro Jahr (ETEC = Typical Energy Consumption)
Power - Power consumption (standby) - Ã 2.0 Watt (S3 Mode, Suspend to RAM, WOL activated)
Power - Power source - Power adapter
Print Text - TERRA Greenline series | 10-Point-Touch Display 23.8" (60.5 cm) frameless | Height-adjustable stand with pivot function | Core i5-14500 (up to 5.0 GHz) | 8 GB DDR5 SO-DIMM, 500 GB M.2-SSD PCIe | Intel HD Graphics, Kensington-Lock | WebCam 5MP retractable | GbE-LAN, WiFi 802.11ax, Bluetooth 5.2 | Windows 11 Pro, Microsoft Office trial | Microsoft Office trial | (!) w/o keyboard & mouse
Processor - ALL-IN-ONE - 1
Processor - ALL-IN-ONE - 14 Core
Processor - ALL-IN-ONE - Core i5
Processor - ALL-IN-ONE - FCLGA1700 (max. 65 Watt TDP)
Processor - ALL-IN-ONE - Intel H610 Express
Processor - Efficient-core base frequency - 1.9 GHz
Processor - Efficient-core Max Turbo Frequency - 3.7 GHz
Processor - Efficient cores - 8
Processor - Maximum number of SMP processors - 1
Processor - Maximum turbo power - 154 W
Processor - Motherboard chipset - Intel H610 Express
Processor - Number of processors - 1
Processor - Performance-core base frequency - 2.6 GHz
Processor - Performance-core Max Turbo Frequency - 5 GHz
Processor - Performance cores - 6
Processor - Processor base power - 65 W
Processor - Processor boost frequency - 5 GHz
Processor - Processor cache - 24 MB
Processor - Processor cache type - Smart Cache
Processor - Processor cores - 14
Processor - Processor cores - 14 Core
Processor - Processor family - Core i5
Processor - Processor family - Intel® Core™ i5
Processor - Processor frequency - 2.6 GHz
Processor - Processor generation - Intel® Core™ i5 (14th gen)
Processor - Processor manufacturer - Intel
Processor - Processor model - i5-14500
Processor - Processor socket - FCLGA1700 (max. 65 Watt TDP)
Processor - Processor threads - 20
ProductName - 1000034
Short description - TERRA ALL-IN-ONE-PC 2420HA GREENLINE
ShortSummaryDescription - TERRA 1000034, 60.5 cm (23.8"), Full HD, Intel® Core™ i5, 8 GB, 500 GB, Windows 11 Pro
Software - ALL-IN-ONE - 1 month trial version for new Microsoft® 365 user
Software - Operating system architecture - 64-bit
Software - Operating system installed - Windows 11 Pro
Software - Pre-installed software - 1 month trial version for new Microsoft® 365 user
Storage - ALL-IN-ONE - 1 x 500 GB - solid state
Storage - ALL-IN-ONE - 2x S-ATA 6GB/s ¦ 1x M.2 type 2260/2280 (SATA & PCIe 4.0 x4 NVMe)
Storage - ALL-IN-ONE - 500 GB
Storage - ALL-IN-ONE - No RAID supported
Storage - ALL-IN-ONE - PCIe (NVMe)
Storage - ALL-IN-ONE - SSD M.2
Storage - HDD capacity - 1 x 500 GB - solid state
Storage - HDD interface - 2x S-ATA 6GB/s 1x M.2 type 2260/2280 (SATA & PCIe 4.0 x4 NVMe)
Storage - Number of SSDs installed - 1
Storage - NVMe - Yes
Storage - Optical drive type - No
Storage - RAID levels - No RAID supported No RAID supported
Storage - SSD capacity - 500 GB
Storage - SSD form factor - M.2
Storage - SSD interface - PCIe (NVMe)
Storage - SSD interface - PCI Express 4.0
Storage - Storage media - SSD
Storage - Storage media - SSD M.2
Storage - Total SSDs capacity - 500 GB
Storage - Total storage capacity - 500 GB
Technical details - ALL-IN-ONE - International
Technical details - Localization - International
Title - TERRA 1000034 All-in-One PC/workstation Intel® Core™ i5 i5-14500 60.5 cm (23.8") 1920 x 1080 pixels Touchscreen 8 GB DDR5-SDRAM 500 GB SSD Windows 11 Pro Wi-Fi 6 (802.11ax) Black
Weight & dimensions - ALL-IN-ONE - 5.4 ¦ Grundfläche Fuss: 25.4 x 24.3 (B x T) cm
Weight & dimensions - ALL-IN-ONE - 7.5 kg
Weight & dimensions - ALL-IN-ONE - 54.0 cm
Weight & dimensions - ALL-IN-ONE - max.: 52.0 min.: 38.9 cm
Weight & dimensions - Altura - max.: 52.0 min.: 38.9 cm
Weight & dimensions - Ancho - 54.0 cm
Weight & dimensions - Depth (with stand) - 54 mm
Weight & dimensions - Height (with stand) - 520 mm
Weight & dimensions - Peso - 7.5 kg
Weight & dimensions - Profundidad - 5.4 Grundfläche Fuss: 25.4 x 24.3 (B x T) cm
Weight & dimensions - Weight (with stand) - 7.5 kg
Weight & dimensions - Width (with stand) - 540 mm
