Incase 2-Port VGA Splitter (350MHz) VS92A

Brand - ATEN
BrandPartCode - VS92A-AT-G
Category - Video Splitters
Code - VS92A-AT-G
Design > Material - Metal
EAN - 4710423770928
Features - Bandwidth - 350 MHz
Features - Housing material - Metal
Features - LED indicators - Power
Features - Maximum operating distance - 30 m
Features - Maximum refresh rate - 60 Hz
Features - Maximum resolution - 1920 x 1440 pixels
Features - Product colour - Silver
GTIN - 0971471449912
GTIN - 971471449912
GTIN - 4710423770928
Link - https://www.aten.com/global/en/products/professional-audiovideo/video-splitters/vs92a/
Logistics data - Harmonized System (HS) code - 85176990
Logistics data - Master (outer) case gross weight - 13.2 kg
Logistics data - Master (outer) case height - 338 mm
Logistics data - Master (outer) case length - 490 mm
Logistics data - Master (outer) case net weight - 9.62 kg
Logistics data - Master (outer) case width - 315 mm
Logistics data - Products per master (outer) case - 20 pc(s)
LongDesc - The VS92A is a video splitter that not only duplicates the video signal from any VGA, XGA, SVGA, UXGA, or multisync monitor to two outputs, but also boosts the video signal over a distance of up to 30 meters. Cascadable to support up to 8 displays, and offering bandwidth up to 350 MHz, the VS92A is ideal for broadcasting and enhancing video information to the public, monitoring your work environments from safe locations, or offering superior video for company or classroom training.
LongProductName - 1920 x 1440@60Hz, 350 MHz, VGA, DC 9V, 130x75.1x44 mm
LongSummaryDescription - ATEN 2-Port VGA Video Splitter (350 MHz). Video port type: VGA, Video out: 2x VGA. Maximum resolution: 1920 x 1440 pixels, Product colour: Silver, Housing material: Metal. AC input voltage: 9 V, Power consumption (typical): 1.15 W. Width: 75.1 mm, Depth: 130 mm, Height: 44 mm. Quantity per pack: 1 pc(s), Package width: 59 mm, Package depth: 239 mm
Name - Aten | 2-Port VGA Splitter (350MHz) | VS92A
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Operational conditions > Operating relative humidity (H-H) - 0 - 80 %
Operational conditions > Operating temperature (T-T) - 0-50 °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 240 mm
Package features > Gross height (mm) - 65 mm
Package features > Gross width (mm) - 160 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 346 pc(s)
Package features > Paper/Pasteboard - 100 g
Package features > Plastic (No PET) - 20 g
Package features > Tare weight (kg) - 0.12 kg
Package features > Volume (m3) - 0.002496 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - AC adapter included - Yes
Packaging content - Manual - Yes
Packaging data - Package depth - 239 mm
Packaging data - Package height - 160 mm
Packaging data - Package weight - 631 g
Packaging data - Package width - 59 mm
Packaging data - Quantity per pack - 1 pc(s)
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Video out - 2x VGA
Ports & interfaces - Video ports quantity - 3
Ports & interfaces - Video port type - VGA
Power - AC input voltage - 9 V
Power - Power consumption (typical) - 1.15 W
Producer product family - 2-Port VGA Splitter (350MHz)
Producer product name - VS92A
ProductName - 2-Port VGA Video Splitter (350 MHz)
ShortSummaryDescription - ATEN 2-Port VGA Video Splitter (350 MHz), VGA, 2x VGA, 1920 x 1440 pixels, Silver, Metal, 30 m
Technical details > Gross weight - 0.62 kg
Technical details > Net weight - 0.5 kg
Technical details > Other features - One video input to 2 video outputs; Cascadable to 3 levels - provides up to 8 video signals; Supports 350 MHz bandwidth; Long-distance transmission - up to 30 m; Superior video quality - 1920 x 1440@60Hz; DDC, DDC2, DDC2B Compatible (Port 1 only); Supports VGA, XGA, SVGA, UXGA,WUXGA and multisync monitors
Technical details > Producer - Aten
Title - ATEN 2-Port VGA Video Splitter (350 MHz)
URL - https://www.atten.eu/
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 130 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 481 g
Weight & dimensions - Width - 75.1 mm
