ARTIKEL1 - L2 +M 24 X TX GB P + 4 XCOMBO
ARTIKEL2 - 990-005794-50 IN
Brand - Allied Telesis
BrandPartCode - 990-005794-50
Category - Network Switches
Data transmission - Jumbo frames - 10000
Data transmission - Jumbo frames support - Yes
Data transmission - Latency (1 Gbps) - 4.3 µs
Data transmission - Latency (10-100 Mbps) - 8.6 µs
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Switching capacity - 56 Gbit/s
Data transmission - Throughput - 41.7 Mpps
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Product colour - Grey
Design - Rack mounting - Yes
EANCode - 0767035211374
GRUPPE1 - Network
GRUPPE2 - Kvm Switch Entry Hig
GTIN - 0767035211374
GTIN - 767035211374
GTIN - 7670352113746
HERSTELLER - ALLIED TELESIS
HSTNUMMER - AT-GS970M/28PS-50
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The GS970M Series of Layer 3 switches provide high performance with gigabit to the desktop, the ability to connect and power endpoints, and lower management costs—a high value network edge solution from Allied Telesis.- Reduce costs and automate network and device management with the Allied Telesis Autonomous Management Framework™ (AMF)- Flexible deployment with 10, 18 and 28 port models- High-speed gigabit network access for power users- Support converged networks with PoE+ to power devices like wireless access points, digital surveillance cameras and IP phones- Easy management with an industry-standard Command Line Interface (CLI) and intuitive Graphical - User Interface (GUI)- AlliedWare Plus™ Enterprise-class operating system- Eco-friendly for reduced running costs- Network Access Control (NAC) for edge security- Ethernet Protection Switched Ring (EPSRing™) enables resilient high-speed ring-based networks- Static Routing and RIP support Layer 3 environments
LongProductName - GS970M Managed L3 switch, Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE), 24x 10/100/1000T PoE, 4x 100/1000X SFP, 1U Gray
LongSummaryDescription - Allied Telesis GS970M. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. MAC address table: 16000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1x, IEEE.... Rack mounting, Form factor: 1U
Management features - ARP inspection - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Multicast features - Multicast support - Yes
Network - 10G support - No
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Number of VLANs - 4094
Network - Port mirroring - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Private VLAN, Tagged VLAN, Protocol-based VLAN, Port-based VLAN
Network - VLAN support - Yes
Operational conditions - Heat dissipation - 89 BTU/h
Operational conditions - Non-operating altitude - 0 - 4000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Packaging data - Package depth - 360 mm
Packaging data - Package height - 150 mm
Packaging data - Package weight - 4 kg
Packaging data - Package width - 430 mm
Performance - Flash memory - 64 MB
Performance - Internal memory - 512 MB
Performance - Memory type - DDR-SDRAM
Performance - Noise level - 34 dB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Combo SFP ports quantity - 4
Ports & interfaces - Console port - RJ-45
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 26 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
ProductName - GS970M
Security - Access Control List (ACL) - Yes
Security - Authentication - MAC-based authentication, Web-based authentication
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP server, DHCP client
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - 3DES, 128-bit AES, 192-bit AES, 256-bit AES, AES, DES, MD5, SHA-1, SHA-2, SHA-256
Security - SSH/SSL support - Yes
ShortSummaryDescription - Allied Telesis GS970M, Managed, L3, Gigabit Ethernet (10/100/1000), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 4
Storno - Y
Title - Allied Telesis GS970M Managed L3 Gigabit Ethernet (10/100/1000) 1U Grey
URL - https://www.alliedtelesis.com/products/switches/gs970m-series
WarrantyInfo - 5Years
Weight & dimensions - Depth - 231 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.4 kg
Weight & dimensions - Width - 341 mm
