Accessories included - Mounting rails Power cables
Battery backup - No
Chipset type -
Color - Not applicable
Controller - other information - 8 channels, no cache Inspur PCIE 12Gbps
CPU - other information - Intel Xeon Silver 4316
CPU frequency - 2.3 GHz
CPU model - 4316
CPU series - Intel Xeon
Description - Rack Server Inspur NF5266M6 24 x 3.5 2x4316 2x32G 2x1300W SNF5266M605B
Designation - CE+WEEE
dimension depth - 280 mm
dimension height - 116 mm
dimension weight - 40200 g
dimension width - 75 mm
Disk controller - Card
Disk controller - Hardware
Disk controller - SAS
Disk controller - SATA
ean - ABEAN-RS68508
Expansion slots - 1 x PCIe x 16
Expansion slots - 2 x PCIe x 8
Form factor (width) - 3,5'' (LFF)
Graphics -
guarantee - 6
guarantee_type - external
Hard drive cage interfaces - SAS
Hard drive cage interfaces - SATA
Hot-plug fans support - Yes
Hot-plug power supply support - Yes
Hot-swapping support - Yes
Housing - Rack 2U
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 2 x USB 3.0
Internal backup device support - No
Kind of memory - Registered
Max. number of disks in current configuration - 24
Max. number of power supplies - 2
Max memory size - 4 TB
Max supported number of processors - 2
Memory frequency - 3200 MHz
Memory type - DDR4
Model - NF5266M6
Motherboard -
name - Server rack NF5266M6 24 x 3.5 2x4316 2x32G 2x1300W - SNF5266M605B
Network card - other information - Inspur X550
Network interface - 2 x 10Gbit/s 10GBase-T
Number of available memory slots - 14
Number of cores - 20C
Number of CPUs installed - 2
Number of fans - 6
Number of HDDs installed - 0
Number of memory slots used - 2
Number of power supplies installed - 2
Optical disk drive - External DVD
Power supply output current - 1300 W
producer - Inspur
RAID levels - 0
RAID levels - 1
RAID levels - 5
RAID levels - 10 (1+0)
RAM - other information -
RAM memory installed - 64 GB
Total number of memory slots - 16
Tower to rack conversion support - No
vendpn - SNF5266M605B
Warranty - 3 years NBD
