Startech 2-PORT USB SERIAL ADAPTER USB TO DUAL DB9 RS232 ADAPTER

ARTIKEL1 - 2-PORT USB SERIAL ADAPTER
ARTIKEL2 - USB TO DUAL DB9 RS232 ADAPTER
Brand - StarTech.com
BrandPartCode - 2P6FFC-USB-SERIAL
Breite - 0
Category - Cable Gender Changers
Certificates - Compliance certificates - RoHS
EANCode - 0065030898379
Gewicht - 0.38
GRUPPE1 - Cables
GRUPPE2 - Serial Cable
GTIN - 0065030898379
GTIN - 065030898379
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - 2P6FFC-USB-SERIAL
Laenge - 0
Logistics data - Master (outer) case height - 250 mm
Logistics data - Master (outer) case length - 330 mm
Logistics data - Master (outer) case width - 585 mm
Logistics data - Products per master (outer) case - 40 pc(s)
LongDesc - Add two RS232 serial ports to a laptop or desktop, using an available USB-A portAdd RS-232 serial communication support to USB-A enabled Data Terminal Equipment (DTE - e.g., desktop or laptop), using this 13ft (4m) straight through 2-Port USB to Serial Adapter Cable.Serial Port ExpansionThe Dual-Port USB Serial Adapter adds two RS-232 serial DB/DE-9 (male) connectors to a desktop or laptop via a single USB Type-A port. Secure the adapter to a serial device, using pre-installed and removable slotted D-Sub thumbscrews or install the included DB-9 Nuts for compatibility with other serial peripheral devices or cables.LED IndicatorsData transmission and reception LED indicators for each port on the adapter provide real-time monitoring of port activity. The USB LED indicates when the adapter has successfully enumerated on the desktop or laptop. All the LEDs aid with diagnostics and troubleshooting.Seamless ConnectivityThe adapter is compatible with Windows, macOS, ChromeOS, and Linux. Drivers automatically install to Windows 7 and newer versions, macOS 10.15 and above, and Linux. The USB to RS-232 adapter features COM retention, which automatically reassigns the COM port value if the cable is disconnected and reconnected, or if the system is rebooted.Built To LastThe rugged TPE construction and Level-4 ESD protection (15kV air and 8kV contact) enhance the reliability and longevity of the USB to Serial Adapter. Copper shielding minimizes Electromagnetic and Radio Frequency Interference (EMI and RFI). Gold-plated connectors enhance signal conductivity. The included mounting bracket allows the hub of the serial adapter to be mounted to a desired surface.The StarTech.com Advantage
LongProductName - StarTech.com 13ft/4m 2-Port USB to Serial Adapter Cable, COM Retention, FTDI, USB-A to DB9 RS232, Changeable DB9 Screws/Nuts
LongSummaryDescription - StarTech.com 13ft (4m) 2-Port USB to Serial Adapter Cable, Interchangeable DB9 Screws/Nuts, COM Retention, USB-A to DB9 RS232, FTDI, Level-4 ESD Protection, Windows/macOS/ChromeOS/Linux - Rugged TPE Construction. Connector 1: USB-A, Connector 2: 2 x DB-9 RS-232, Cable length: 4 m. Product colour: Black, Grey
Operational conditions - Operating temperature (T-T) - -40 - 80 °C
Operational conditions - Relative humidity - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 80 °C
Packaging content - Manual - Yes
Packaging data - Package depth - 155 mm
Packaging data - Package height - 55 mm
Packaging data - Package weight - 290 g
Packaging data - Package width - 225 mm
Performance - Baud rate - 921.6 Kbit/s
Performance - Cable jacket material - Thermoplastic elastomer (TPE)
Performance - Chipset - FTDI - FT2232H
Performance - Compatible operating systems - Windows 7, 8/8.1, 10, 11
Windows Server 2008 R2, 2012, 2012 R2, 2016, 2019, 2022
macOS 10.9 to 10.15, 11.0, 12.0, 13.0, 14.0
Linux 4.15.x+- LTS Versions
Chrome OS
Performance - Data bits - 7, 8
Performance - Data transfer rate - 0.48 Gbit/s
Performance - FIFO (First In, First Out) - 4048 B
Performance - LED indicators - Yes
Performance - Parity bit - Even, Mark, No, Odd, Space
Performance - Product colour - Black, Grey
Performance - Stop bits - 1, 2
Ports & interfaces - Cable length - 4 m
Ports & interfaces - Connector 1 - USB-A
Ports & interfaces - Connector 1 form factor - Straight
Ports & interfaces - Connector 1 gender - Male
Ports & interfaces - Connector 2 - 2 x DB-9 RS-232
Ports & interfaces - Connector 2 form factor - Straight
Ports & interfaces - Connector 2 gender - Male
Ports & interfaces - USB version - 2.0
ProductName - 13ft (4m) 2-Port USB to Serial Adapter Cable, Interchangeable DB9 Screws/Nuts, COM Retention, USB-A to DB9 RS232, FTDI, Level-4 ESD Protection, Windows/macOS/ChromeOS/Linux - Rugged TPE Construction
ShortSummaryDescription - StarTech.com 13ft (4m) 2-Port USB to Serial Adapter Cable, Interchangeable DB9 Screws/Nuts, COM Retention, USB-A to DB9 RS232, FTDI, Level-4 ESD Protection, Windows/macOS/ChromeOS/Linux - Rugged TPE Construction, USB-A, 2 x DB-9 RS-232, 4 m, Black, Grey
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - StarTech.com 13ft (4m) 2-Port USB to Serial Adapter Cable, Interchangeable DB9 Screws/Nuts, COM Retention, USB-A to DB9 RS232, FTDI, Level-4 ESD Protection, Windows/macOS/ChromeOS/Linux - Rugged TPE Construction
URL - https://www.startech.com/en-us/2P6FFC-USB-SERIAL
WarrantyInfo - 2 Years
Weight & dimensions - Depth - 4000 mm
Weight & dimensions - Height - 20 mm
Weight & dimensions - Weight - 280 g
Weight & dimensions - Width - 45 mm
