AC adapter output voltage Power - 12 V
Stand included Packaging content - Yes
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2291298/fiches?language=EN
Audio output Ports & interfaces - Yes
Brand - Dahua Technology
BrandPartCode - DHI-LM22-J200
Design - Detachable stand - Yes
Design - Front bezel colour - Black
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Product colour - Black
Detachable stand Design - Yes
Display - Native aspect ratio - 16:9
Display - Display diagonal - 54.6 cm (21.5")
Display - Display diagonal (metric) - 56 cm
Display - Display brightness (typical) - 250 cd/m²
Display - Screen shape - Flat
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - Haze rate - 25%
Display - LED backlight - Yes
Display - Maximum refresh rate - 100 Hz
Display - Panel type - IPS
Display - Pixel pitch - 0.24795 x 0.24795 mm
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Response time - 5 ms
Display - Backlight type - Edge LED
Display - Colour depth - 8 bit
Display diagonal (metric) Display - 56 cm
Display diagonal Display - 21.5 "
Display brightness (typical) Display - 250 cd/m²
Screen shape Display - Flat
Display resolution Display - 1920 x 1080 pixels
Display technology Display - LED
Display - Contrast ratio (typical) - 1000:1
Display - NTSC coverage (typical) - 50%
Display - Viewable size, horizontal - 47.6 cm
Display - Viewable size, vertical - 26.8 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display - Colour gamut standard - NTSC
Power consumption (standby) Power - 0.5 W
Energy consumption (SDR) per 1000 hours Power - 10 kWh
Power consumption (typical) Power - 10.4 W
Energy efficiency class (SDR) Power - C
Energy efficiency class Energy Efficiency - C
Energy efficiency scale Power - A to G
EPREL Registration Number Energy Efficiency - 2291298
EPREL Version Number Energy Efficiency - 1
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -6 - 27°
Ergonomics - Height adjustment - No
Ergonomics - LED indicators - Yes
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Wall mountable - Yes
Ergonomics - VESA mounting - Yes
Front bezel colour Design - Black
Warranty - 36 months
WarrantyInfo -
Haze rate Display - 25 %
HD type Display - Full HD
HDMI Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 1
HDMI version Ports & interfaces - 1.4
CnCode - 85285210
Feet colour Design - Black
Performance - Flicker-free technology - Yes
Cables included Packaging content - HDMI
Weight (without stand) Weight & dimensions - 2500 g
Weight & dimensions - Weight (without stand) - 2.5 kg
Weight & dimensions - Height (without stand) - 294.1 mm
Weight & dimensions - Width (without stand) - 489.9 mm
Weight & dimensions - Bezel width (side) - 2.4 mm
Weight & dimensions - Depth (without stand) - 37.5 mm
Weight & dimensions - Bezel width (bottom) - 1.79 cm
Weight & dimensions - Bezel width (top) - 2.4 mm
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -6 - 27 °
Category - Computer Monitors
Category Code - LC3
Mean time between failures (MTBF) Other features - 50000 h
Quick start guide Packaging content - Yes
Description - The Dahua J200 series CCTV monitor operates 24/7, delivering low power consumption and an extended lifespan. With its impressive 5 ms response time and a 100 Hz refresh rate, this monitor ensures that your images and videos are displayed without ghosting or blurring. Additionally, it is highly compatible with Dahua backend security devices, making it an excellent choice for various desktop displays and security video monitoring walls.FHD panel, suitable for continuous 24/7 operation50,000 hours long lifetime, ultra-low power consumption3 sides narrow bezel design, elegant appearance5 ms fast response time with no image blurring or ghosting178°/178° extra-wide viewing angle for overall viewing performanceSupports multiple signal inputs including HDMI and VGA
Summary - Dahua Technology LM22-J200. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black
Contrast ratio (typical) Display - 1000:1
Manual Packaging content - Yes
Number of speakers Multimedia - 2
Height (without stand) Weight & dimensions - 294.1 mm
Height adjustment Ergonomics - No
Storage relative humidity (H-H) Operational conditions - 5 - 90 %
Width (without stand) Weight & dimensions - 489.9 mm
LED indicators Ergonomics - Yes
LED backlight Display - Yes
ShortSummaryDescription - Dahua Technology LM22-J200, 54.6 cm (21.5"), 1920 x 1080 pixels, Full HD, LED, 5 ms, Black
Maximum refresh rate Display - 100 Hz
Model - DHI-LM22-J200
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Other features - Mean time between failures (MTBF) - 50000 h
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Vendor Homepage - https://www.dahuasecurity.com/search/products?keyword=DHI-LM22-J200-V1
Native aspect ratio Display - 16:9
NTSC coverage (typical) Display - 50 %
Packaging data - Package weight - 3.4 kg
Packaging data - Package height - 375 mm
Packaging data - Package width - 556 mm
Packaging data - Package depth - 107 mm
Packaging data - Package type - Box
Package weight Packaging data - 3400 g
Package height Packaging data - 375 mm
Package width Packaging data - 556 mm
Packaging content - Stand included - Yes
Packaging content - Cables included - HDMI
Packaging content - Manual - Yes
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Package depth Packaging data - 107 mm
Package type Packaging data - Box
Panel mounting interface Ergonomics - 75 x 75 mm
Panel type Display - IPS
Title - Dahua Technology LM22-J200 computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LED Black
LongDesc - The Dahua J200 series CCTV monitor operates 24/7, delivering low power consumption and an extended lifespan. With its impressive 5 ms response time and a 100 Hz refresh rate, this monitor ensures that your images and videos are displayed without ghosting or blurring. Additionally, it is highly compatible with Dahua backend security devices, making it an excellent choice for various desktop displays and security video monitoring walls.
LongSummaryDescription - Dahua Technology LM22-J200. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: Black
LongProductName - 21.45" FHD ELED, IPS, 16:9, 100 Hz, 5 ms, 250 cd/m², 1000:1, 2× 2 W, VGA, HDMI, 3.5 mm, 12 VDC, 2 A, 2.5 kg
Pixel pitch Display - 0.24795 x 0.24795 mm
Surface hardness Display - 3H
Plug and Play Ergonomics - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Touchscreen Display - No
Bezel width (bottom) Weight & dimensions - 17.9 mm
Bezel width (side) Weight & dimensions - 2.4 mm
Bezel width (top) Weight & dimensions - 2.4 mm
Frameless design Design - Yes
Response time Display - 5 ms
RMS rated power Multimedia - 4 W
Wall mountable Ergonomics - Yes
Built-in camera Multimedia - No
Built-in speaker(s) Multimedia - Yes
Built-in USB hub Ports & interfaces - No
Storage temperature (T-T) Operational conditions - -20 - 60 °C
Depth (without stand) Weight & dimensions - 37.5 mm
Backlight type Display - Edge LED
Power adapter included Packaging content - Yes
Power supply type Power - External
Product Net Weight - 2.5 kg
ProductName - LM22-J200
Product colour Design - Black
Operating hours (hours/days) Performance - 24/7
Performance - Operating hours (hours/days) - 24/7
Operating relative humidity (H-H) Operational conditions - 10 - 85 %
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Viewable size, horizontal Display - 476.064 mm
Viewable size, vertical Display - 267.786 mm
Viewing angle, horizontal Display - 178 °
Viewing angle, vertical Display - 178 °
Compliance certificates Other features - CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)
URL - https://www.dahuasecurity.com/search/products?keyword=DHI-LM22-J200-V1
VESA mounting Ergonomics - Yes
VGA (D-Sub) ports quantity Ports & interfaces - 1
Current rating Power - 2 A
Flicker-free technology Performance - Yes
Colour gamut standard Display - NTSC
Colour depth Display - 8 bit
Power - Energy efficiency class (SDR) - C
Power - Power supply type - External
Power - Current rating - 2 A
Power - Power consumption (max) - 13.6 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 10.4 W
Power consumption (max) Power - 13.6 W
Power - Energy consumption (SDR) per 1000 hours - 10 kWh
Power - Energy efficiency scale - A to G
Power - AC adapter output voltage - 12 V
Unit Calculated Volume - 0.02279 cubm
Unit Calculated Weight - 3.4 kg
Units per Pallet - 0
Unit Box Height - 0.37
Unit Box Width - 0.11
Unit Box Length - 0.56
