Brand - be quiet!
BrandPartCode - BN330
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Certification - CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)
Certificates - Compliance certificates - CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan speed - 0 - 2000 RPM
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN_code - 4260052189108
GTIN - 4260052189108
Logistics data - Country of origin - Germany
Logistics data - Warranty period - 5 year(s)
LongDesc - PROVEN RELIABILITY, QUIET OPERATIONSystem Power 10 850W has been built with price-conscious users in mind that do not want to dispense on reliability and quietness. Features such as LLC + SR + DC-to-DC topology and Dual-Rail operation underline the value System Power 10 850W offers even at entry-level. 80 PLUS® GOLD CERTIFICATIONVery high operating efficiencySystem Power 10 850W is certified 80 PLUS Gold with an efficiency rating of up to 93.4% – a truly outstanding level for this class of PSUs. The most compelling benefit is lower power consumption, lower costs, and cooler, quieter operation. Whether you are building a very quiet system or gaming system: System Power 10 850W is the price-conscious choice!EXCEPTIONALLY SILENT OPERATIONAchieved by a silence-optimized 120mm be quiet! fanThe silence-optimized 120mm be quiet! fan is thermally governed to strike the best balance between effective cooling and quietness. Airflow-optimized fan blades reduce turbulence, enabling best-in-class quiet functionality and the almost inaudible operation that be quiet! is famous for.HIGH-CLASS TECHNOLOGIESCompatibility for all systemsLLC and Synchronous Rectifier (SR) provide very stable operation and enhanced voltage regulation. The PSU is equipped with DC-to-DC conversion for tight voltage regulation even under heavy cross-loading conditions.HIGH PERFORMANCE FOR YOUR SYSTEMProven reliability for CPU and GPUSystem Power 10 850W provides stable and dependable power for CPU and GPU. It is equipped with 2 independent 12V-rails and supports several graphics cards with 4 PCI express connectors for GPU support.
LongProductName - 850W, DC/DC, 80 PLUS Gold, 120 mm, 2000 RPM, 30.7 dB, 20+4-pin, PCI-e 6+2-pin, 6x SATA, 150 x 160 x 86 mm
LongSummaryDescription - be quiet! System Power 10. Total power: 850 W, AC input voltage: 200 - 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 450,550,570,670,690,790 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE, Certification: CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)
Manufacturer - Be quiet
Manufacturer_code - BN330
Name - be quiet! System Power 10 850W, PC power supply (black, 4x PCIe, 850 watts)
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Noise level (full-load mode, 100%) - 30.7 dB
Other features - Noise level (quiet mode, 50%) - 10.4 dB
Other features - Noise level (silent mode, Other features - Screws included - Yes
Packaging data - Manual - Yes
Packaging data - Manual languages - German, English, Spanish, French, Polish, Russian
Packaging data - Package depth - 300 mm
Packaging data - Package height - 100 mm
Packaging data - Package weight - 2.6 kg
Packaging data - Package width - 220 mm
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 2.52
Performance - Bearing technology - Rifle
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 30.7 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 60 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 1
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power cable length - 65 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power cable length - 790 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 1
Ports & interfaces - SATA power cable length - 450,550,570,670,690,790 mm
Power - AC input frequency - 50 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 849.6 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 93.4%
Power - Hold time - 17 ms
Power - Input current - 5 A
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V1) - 40 A
Power - Max output current (+12V2) - 36 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.97
Power - Power Factor Correction (PFC) type - Active
Power - Power Good signal delay range - 100 - 150 ms
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 850 W
ProductName - System Power 10
ShortSummaryDescription - be quiet! System Power 10, 850 W, 200 - 240 V, 50 Hz, 5 A, Active, 120 W
Technical details - Sustainability certificates - ENERGY STAR, ErP
Title - be quiet! System Power 10 power supply unit 850 W 20+4 pin ATX ATX Black
URL - https://www.bequiet.com/en/powersupply/3926
WarrantyInfo - 5-year
Weight - 2,65
Weight & dimensions - Depth - 86 mm
Weight & dimensions - Height - 150 mm
Weight & dimensions - Weight - 2.14 kg
Weight & dimensions - Width - 160 mm
