Be Quiet System Power 10, 750W, 80PLUS Bronze

Brand - be quiet!
BrandPartCode - BN329
Category - Power Supply Units
Category 1 - Netzteile
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Certification - CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)
Certificates - Compliance certificates - CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan speed - 0 - 2100 RPM
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 1080
EAN - 4260052189092
EAN_code - 4260052189092
GTIN - 4260052189092
Logistics data - Country of origin - Germany
Logistics data - Warranty period - 5 year(s)
LongDesc - PROVEN RELIABILITY, QUIET OPERATIONSystem Power 10 750W has been built with price-conscious users in mind that do not want to dispense on reliability and quietness. Elaborated features such as a temperature-controlled fan and a remarkably low stand-by-drain underline the value System Power 10 750W offers even at entry-level. VERY QUIET OPERATIONHigh-quality fan for low noiseSystem Power 10 750W is equipped with a temperature-controlled 120mm quality fan. It provides the low noise operation that be quiet! is famous for, offering remarkable quietness at this price-level.HIGH PERFORMANCE FOR YOUR SYSTEMProven reliability for CPU and GPUSystem Power 10 750W provides stable and dependable power for CPU and GPU. This ensures a steady and reliable operation even when your PC meets an unexpectedly heavy load.80 PLUS® BRONZE CERTIFICATIONEfficient operationThe 80 PLUS Bronze certification of System Power 10 750W Bronze with an efficiency rating of up to 89.1% is convincing evidence of this PSU’s power saving operation.STRONG 12V RAILFor a stable PCIe graphics supportSystem Power 10 750W provides enough power for demanding graphics cards. Safety protections defend against overcurrents, over- and undervoltages, overtemperature, short circuits and overloads, thus keeping your valuable components safe.
LongProductName - 750W, DC/DC, 80 PLUS Bronze, 120 mm, 2100 RPM, 34.7 dB, 20+4-pin, PCI-e 6+2-pin, 6x SATA, 150 x 140 x 86 mm
LongSummaryDescription - be quiet! System Power 10. Total power: 750 W, AC input voltage: 200 - 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 450,550,570,670,690,790 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE, Certification: CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)
Manufacturer - Be quiet
Manufacturer - Be Quiet!
Manufacturer_code - BN329
MPN - BN329
Name - 750W be quiet! System Power 10
Name - be quiet! System Power 10 750W, PC power supply (black, 4x PCIe, 750 watts)
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Noise level (full-load mode, 100%) - 34.7 dB
Other features - Noise level (quiet mode, 50%) - 13.3 dB
Other features - Noise level (silent mode, Other features - Screws included - Yes
Packaging data - Manual - Yes
Packaging data - Manual languages - English
Packaging data - Manual languages - French
Packaging data - Manual languages - German
Packaging data - Manual languages - German, English, Spanish, French, Polish, Russian
Packaging data - Manual languages - Polish
Packaging data - Manual languages - Russian
Packaging data - Manual languages - Spanish
Packaging data - Package depth - 268 mm
Packaging data - Package height - 97 mm
Packaging data - Package weight - 2.3 kg
Packaging data - Package width - 195 mm
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 2.52
Performance - Bearing technology - Sleeve
Performance - Certification - CB, TÜV, cRUus, cTUVus, RCM (Australia), BSMI, CU (Russia)
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 34.7 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 60 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 1
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power cable length - 65 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power cable length - 790 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 1
Ports & interfaces - SATA power cable length - 450
Ports & interfaces - SATA power cable length - 450,550,570,670,690,790 mm
Ports & interfaces - SATA power cable length - 550
Ports & interfaces - SATA power cable length - 570
Ports & interfaces - SATA power cable length - 670
Ports & interfaces - SATA power cable length - 690
Ports & interfaces - SATA power cable length - 790 mm
Power - AC input frequency - 50 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 750 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 89.1%
Power - Hold time - 17 ms
Power - Input current - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 62.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.95
Power - Power Factor Correction (PFC) type - Active
Power - Power Good signal delay range - 100 - 150 ms
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 750 W
producerCode - BN329
productName - be quiet! System Power 10 power supply unit 750 W 20+4 pin ATX ATX Black
ProductName - System Power 10
productSize - Normal
ShortSummaryDescription - be quiet! System Power 10, 750 W, 200 - 240 V, 50 Hz, 5 A, Active, 130 W
sizeX - 270
sizeY - 100
sizeZ - 200
Technical details - Sustainability certificates - CCC
Technical details - Sustainability certificates - CE
Technical details - Sustainability certificates - ENERGY STAR
Technical details - Sustainability certificates - ENERGY STAR, ErP
Technical details - Sustainability certificates - ErP
Technical details - Sustainability certificates - Federal Communications Commission (FCC)
Technical details - Sustainability certificates - RoHS
Technical details - Sustainability certificates - WEEE
Technical details - Warranty period - 5 year(s)
Title - be quiet! System Power 10 power supply unit 750 W 20+4 pin ATX ATX Black
URL - https://www.bequiet.com/en/powersupply/3927
WarrantyInfo - 5-year
warrantyLength - 60
warrantyType - G
Weight - 2,40
Weight - 2.393
weight - 2395
Weight & dimensions - Depth - 86 mm
Weight & dimensions - Height - 150 mm
Weight & dimensions - Weight - 1.95 kg
Weight & dimensions - Width - 140 mm
