Brand - Gamer Storm
BrandPartCode - R-PK650D-FA0B-JGEU
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Certification - CB/CE/FCC/CAN ICES-003(B)/NMB-003(B)/ TUV-RH/CCC/UKCA/EAC/RCM/BIS/KC
Certificates - Certification - CE/FCC/CCC/RCM/EAC/CAN ICES-003(B)/NMB-003(B) /TUV-RH
Certificates - Compliance certificates - RoHS
Certificates - Compliance certificates - WEEE
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 1267
EAN_code - 6933412715177
GTIN - 6933412740230
LongDesc - PK650DThe DeepCool PK-D series power supply offers reliable 80 PLUS Bronze efficiency to power computer system builds with stability and low noise performance.PK650D80 PLUS Bronze Power SupplyPK650DThe DeepCool PK-D series power supply offers reliable 80 PLUS Bronze efficiency to power computer system builds with stability and low noise performance.Beautiful in BronzeThe PK-D series is certified 80 PLUS Bronze, delivering up to 85% efficiency under typical load minimizing excess heat waste and lowering energy costs.DC-DC ConversionA highly efficient DC-DC board designed for the +3.3V and +5V rails help achieve tighter voltage regulation and improve system compatibility for next-generation components.Tough and DurableDesigned to operate effortlessly in high temperatures up to 40°C and high altitudes up to 5000m while providing continuous stable power output.ErP Lot 6 CompliantDesigned to be highly power efficient when in power standby mode to meet international ErP Lot 6 standards to lower overall energy consumption.Stealth BlackBlack direct power cables help blend in with other components.
LongProductName - 650W, ATX12V V2.4, 120 mm, HB, APFC, 20+4 Pin, EPS 12V 8 (4+4)Pin x2, PCI-E (6+2)Pin x2, SATA x7, 4Pin Peripheral x4, 150 x 140 x 86 mm
LongSummaryDescription - Gamer Storm PK650D. Total power: 650 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 400,500,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC
Manufacturer - Deepcool
Manufacturer_code - R-PK650D-FA0B-EU
Name - DeepCool PK650D 650W, PC power supply (black, 4x PCIe, 650 watts)
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - Cables included - AC
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 2.4
Performance - Bearing technology - HDB
Performance - Bearing technology - Hypro Bearing
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 50 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 1
Ports & interfaces - PCI Express power cable length - 62 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power cable length - 400,500,600,700 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 1
Ports & interfaces - SATA power cable length - 400,500,600 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 110 W
Power - Combined power (+5V) - 110 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 648 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Hold time - 16 ms
Power - Input current - 10 - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 54 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power Good signal delay range - 100 - 150 ms
Power - Power protection features - No load operation
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Surge & inrush protection (SIP)
Power - Power protection features - Surge protection
Power - Power protection features - Under voltage
Power - Total power - 650 W
producerCode - R-PK650D-FA0B-JGEU
productName - Deepcool PK650D 650W Bronze Power Supply
ProductName - PK650D
productSize - Normal
ShortSummaryDescription - Gamer Storm PK650D, 650 W, 100 - 240 V, 50/60 Hz, 10 - 5 A, Active, 110 W
sizeX - 117
sizeY - 275
sizeZ - 197
Technical_details - Type: PC power supply Color: Black EAN: 6933412715177 Manufacturer No.: R-PK650D-FA0B-EU Series: PK-D Power: 650W : 648W : 110W : Up to 85% : 100-240 volts Default: ATX12V 2.4 Design: ATX Certification: 80 PLUS Bronze Current: 20A : 20A : 2.5A : 0.3A : 54A : 54A Power Factor Correction: Active PFC Connectors: 1x 24-pin ATX12V-2.x, 2x 4+4-pin 12V, 4x 4-pin 5.25", 4x 6+2-pin graphics, 7x 15-pin SATA Cable: 24-pin mainboard main connector: 1x 50 cm, 8-pin additional motherboard connectors: 1x 62 cm, 1x 74 cm, 5.25-inch drive connectors: 1x 40 cm, 1x 50 cm, 1x 60 cm, 1x 80 cm, SATA drive connectors : 1x 40 cm, 2x 50 cm, 2x 60 cm, 2x 70 cm, 6-/8-pin graphics connectors: 2x 50 cm, 2x 62 cm Cooling: 1x 120mm fan Protections: Over Current Protection (OCP), Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Load Protection (OLP/OPP), Short Circuit Protection (SCP), Over Temperature Protection (OTP) Dimensions: Width: 150mm x Height: 86mm x Depth/Length: 140mm
Title - Gamer Storm PK650D power supply unit 650 W 20+4 pin ATX ATX Black
URL - https://www.deepcool.com/products/PowerSupplyUnits/powersupplyunits/PK650D-80-PLUS-Bronze-Power-Supply/2022/15619.shtml
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 2,16
weight - 2664
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
