ID: 524356
Tootekood: PRIME-PX-500
Ametis 1 üksused
Garantii: 2 aastat
Seasonic Prime Fanless PX, 500W, 80PLUS Platinum
Pilt võib erineda tegelikust tootest, võib esineda tarvikuid ja osi, mis ei ole tegeliku tootega kaasas.
-
Omniva pakiautomaat1-2 tööpäeva jooksul1,99 € -
SmartPosti pakiautomaat1-2 tööpäeva jooksul1,99 € -
Kulleri kohaletoimetamine aadressile1-2 tööpäeva jooksul5,99 €
Peamised tooteparameetrid Kõik parameetrid
- Tootja: Seasonic
- Võimsus: 500W
- 80 PLUS certification: 80 PLUS Platinum
- Ventilaatori Läbimõõt: Fanless
- Modulaarkaablid: Fully-Modular
- Protsessori pistikprogramm: 2 x 8-pin(4+4) EPS
- PCI-E: 2 X 6+2pin
Kirjeldus
Ostuvõimalusena on saadaval Seasonic poolt toodetud toiteplokk võimsusega 500W. Toode on saanud 80 PLUS Platinum energiatõhususe sertifikaadi.
Võimsuseallikale on antud 80 PLUS Platinum energiaefektiivsuse sertifikaat, mis tagab vähemalt 92% efektiivsuse 50% koormuse juures. See näitab, et vähemalt 92 W 100 W-st, mida võimsuseallikas võrgust saab, edastatakse arvutikomponentidele, samas kui ülejäänud 8 W kaob kuumusena.
Toiteploki värv on Melna. See on varustatud lamedate kaablitega, mille värv on Melna.
Selle toiteploki on määratud ATX 2.0 standardile. See tähendab, et seade on varustatud ainult 6-pinni ning 8-pinni ühendustega, mis vastavalt annavad 75W ja 150W võimsuse. On oluline märkida, et see plokk on kokkusobiv RTX 4070 ja võimsamate kaartidega, kuid peate kasutama 2x8-pin 16-pinnise 12VHPWR adapterit, mis on kaasas graafikakaardil. ATX 2.0 toiteühendusi ei ole mõeldud käsitlema kaasaegsete graafikakaartide suuri võimsuse kõikumisi; seetõttu, kui te ehitate süsteemi võimsa GPU-ga, nagu RTX 4070, soovitame valida toiteploki ATX 3.* standardi ja 12VHPWR (PCIe 5.0) ühendusega.
Sellel toiteplokil on täielikult modulaarsed kaablid (Fully-modular) - saate ühendada ja lahti ühendada kõik kaasas olevad kaablid vastavalt vajadusele, vähendades segadust ja parandades ventilatsiooni. See on kasulik neile, kellel on osaliselt läbipaistev arvutikorpus ja kelle jaoks esteetiline tegur on eriti oluline.
Põhiteave
Cybenetics Mürataseme sertifitseerimine
: Nav
Cybenetics tõhususe sertifitseerimine
: Nav
Toiteallika tüüp
: ATX
Võimsus
500W
Toiteploki võimsus vatides. Suurem võimsus tähendab suuremat arvuti töötamise stabiilsust. Tänapäevase keskmise arvuti soovitatav toiteploki võimsus on 500W, või enam. Juhul, kui kasutate mitut kõvaketasst, võimsat videokaarti ja protsessorit, on soovitav soetada toiteplokk 600W, või suurema võimsusega.
80 PLUS certification
: 80 PLUS Platinum
Kogu voolutugevus (+12V)
: 41A
Ventilaatori Läbimõõt
: Fanless
Funktsionaalsus
Kaabli värvus
: Must
Valgustus
: Ei ole
Värv
: Must
Modulaarkaablid
: Fully-Modular
Sadamad ja seadmed
PCI-E 5.0/5.1
: Nav
Protsessori pistikprogramm
: 2 x 8-pin(4+4) EPS
Emaplaadi pistik
: 20+4pin
PCI-E
: 2 X 6+2pin
SATA pistikud
: 8
Molex PATA lisamoodulid
: 3
Arvutikorpus
Täpsem spetsifikatsioon
80 PLUS certification Performance - 80 PLUS Platinum
AC input frequency Power - 50 - 60 Hz
AC input voltage Power - 100 - 240 V
Cabling type Ports & interfaces - Fully-Modular
Category 1 - Netzteile
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
Certification Certificates - cTUVus, TUV, CB, CCC, BSMI, EAC, CE, WEEE, ErP Lot 6, REACH
Combined power (+3.3V) Power - 100 W
Combined power (+5V) Power - 100 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 444 W
Combined power (-12V) Power - 3.6 W
Compliance certificates Certificates - RoHS
Cooling type Design - Passive
CPU power cable length Ports & interfaces - 650 mm
CPU power connectors (8-pin) Ports & interfaces - 2
Depth Weight & dimensions - 140 mm
Description - The PRIME Fanless PX series utilizes the fanless technology, which eliminates the fan noise completely, ensuring truly quiet operation. The unit not only is rated to be 80PLUS Platinum efficient, but it also has the highest power output on the fanless power supply market at the moment. The power supply is ideal any situations that demand silence from the equipment. The high quality components inside and the innovative circuit design result in clean and stable power output. The fully modular cables allow for better cable management in the computer case. 80 PLUS® Platinum
The PRIME Platinum Series achieves 80 PLUS® Platinum certification with its 92 % efficiency at 50 % system load. Micro Tolerance Load Regulation
Seasonic’s latest design keeps the output voltage within a very tight range, achieving under 0.5 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems. Seasonic Fanless Design
Cooling fans inside the power supply are replaced by passive cooling based on heat dissipation. Silent operation does not only provide a more pleasant working environment but it also results in less power consumption and lower utility bills.ATX 12 VFull Modular80 PLUS Platinum CertifiedDimensions: 140 mm (L) x 150 mm (W) x 86 mm (H)Micro Tolerance Load Regulation (0.5 %)True Fanless DesignMulti-GPU setupGold plated connectors
EAN - 4711173875598
EAN_code - 4711173875598
Fan diameter Design - 135 mm
Height Weight & dimensions - 86 mm
Manufacturer - Seasonic
Manufacturer - Sea Sonic
Manufacturer_code - PRIME-PX-500
Max output current (+3.3V) Power - 20 A
Max output current (+5V) Power - 20 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 37 A
Max output current (-12V) Power - 0.3 A
Mean time between failures (MTBF) Performance - 150000 h
Model name - PRIME Fanless PX
Motherboard power cable length Ports & interfaces - 610 mm
Motherboard power connector Ports & interfaces - 20+4 pin ATX
MPN - PRIME-PX-500
Name - 500W Seasonic PRIME Fanless PX-500 500W Kabelmanagement
Name - Seasonic Fanless PRIME PX-500 500W PC power supply (black, 2x PCIe, cable management)
Number of fans Design - 1 fan(s)
Number of SATA power connectors Ports & interfaces - 2
On/off switch Design - Yes
Operating temperature (T-T) Operational conditions - 0 - 50 °C
Package type Packaging data - Box
PCI Express power cable length Ports & interfaces - 750 mm
PCI Express power connectors (6+2 pin) Ports & interfaces - 2
Peripheral (Molex) power cable length Ports & interfaces - 470/690 mm
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 2
Power protection features Power - Over current/Over power/Over voltage/Short circuit/Under voltage
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
Purpose Performance - PC
SATA power cable length Ports & interfaces - 810/860 mm
Summary - Seasonic PRIME Fanless PX. Total power: 450 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 810,860 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Passive, Fan diameter: 13.5 cm. Compliance certificates: RoHS, Certification: cTUVus, TUV, CB, CCC, BSMI, EAC, CE, WEEE, ErP Lot 6, REACH
Supported motherboard form factors Performance - ATX
Sustainability certificates Technical details - ENERGY STAR
Total power Power - 450 W
Unit Box Height - 0.116
Unit Box Length - 0.271
Unit Box Width - 0.185
Unit Calculated Volume - 0.007527 cubm
Unit Calculated Weight - 2.87 kg
Units per Shipping Box - 5
Vendor Homepage - https://seasonic.com/prime-fanless-px
Warranty - 24 months
Weight - 2,74
Weight - 2.72
Width Weight & dimensions - 150 mm
