Asus Pro WS Platinum, 2200W, 80PLUS Platinum, ATX 3.1, PCIe 5.1

Brand - ASUS
BrandPartCode - 90YE00Z1-B0NA00
category - PC Components|Power Supplies|PSUs above 800 Watts
Category - Power Supply Units
Certificates - Compliance certificates - RoHS
code - 90YE00Z1-B0NA00
Design - Cooling type - Active
Design - On/off switch - Yes
Design - Product colour - Black
ean - 4711387972861
GTIN - 4711387972861
Logistics data - Warranty period - 10 year(s)
LongDesc - ASUS Pro WS 2200W Platinum PSU delivers exceptional voltage stability and advanced power delivery for professionals, supporting up to four graphics cards to meet the demanding AI workloads.The ASUS Pro WS 2200W Platinum PSU is engineered to support up to four GeForce RTX™ 5080 graphics cards. It also features 80 PLUS Platinum certification, high-performance copper pins, dual-ball fan bearings, etched cables, rock-solid voltage stability and advanced power delivery, making it an ideal choice for AI solutions, deep learning and IT management.ENGINEERINGHeavy-Duty PowerDesigned to reliably deliver the thousands of watts necessary to power up to four NVIDIA® GeForce RTX™ 5080 graphics cards, the ASUS Pro WS 2200W Platinum enables breakthrough performance that meets the needs of demanding AI workloads.Gold-Plated High-Performance Copper PinsThe copper pins of the PCIe® connectors in this PSU have been upgraded with gold plating to help ensure cooler operation and improved power delivery efficiency. This plating translates to a significant reduction in normal 12V-2x6 connector temperatures (up to 10°C), promoting optimal performance and stability for even the most demanding graphics cards. Furthermore, the improved contact between socket pins and connectors reduces resistance and improves durability for connector insertion and removal, ensuring reliable cooling performance.Protective PCB CoatingAll wrapped upA protective conformal coating envelops the circuit board to help protect against short-circuits caused by moisture, dust or debris. This added layer of protection enhances durability and stability, ensuring reliable performance throughout the PSU’s lifespan.ATX 3.1 CompatibleATX 3.1 ushers in tighter voltage and current regulation for next-gen hardware ― and the ASUS Pro WS series is ahead of the curve with full compliance. The 16-pin PCIe cables bundled with the PSU deliver up to 600 watts to PCIe 5.1 graphics cards, readying your build for the graphics cards of tomorrow.80 Plus Platinum The ASUS Pro WS Platinum uses low-ESR Japanese server-grade capacitors to ensure efficient operation. This upgrade enables an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% efficiency at 50% load. This increased efficiency results in less heat, reduced fan noise and increased reliability.COOLINGExtruded Aluminum Heatsinks The integrated heatsinks have up to twice the volume of standard designs, to dissipate heat more effectively and help extend component lifespan. Dual-Ball Fan BearingsUp to twice the lifespanDual-ball bearings boast a remarkable lifespan of up to 80,000 hours, lasting up to twice as long as sleeve bearings and exceeding even fluid dynamic bearings. This helps ensure long-lasting, reliable cooling with minimal noise.EXPERIENCEEtched CablesMade using pliable premium materials, these etched cables are easily flexible during installation, and they operate at temperatures 50°C lower than the safety limit when routed for cable management. The cables also meet the rigorous standards of the UL1581 flame test and UL758 certification, helping to ensure a smooth PC DIY experience and exceptional safety.DIY-Friendly CPU/PCIe Power ConnectorEngineered for a streamlined build experience, the power cable features a distinct clip between the 4+4 pin connectors and a unique color scheme for easy identification during installation. The integrated clip helps ensure a secure and effortless connection to the motherboard's CPU power connector, while the dual-color PCIe 16-pin connector enhances visibility and simplifies GPU power connections.Compact SizeThe compact 175mm length allows flexible installation in a wide range of PC cases, making it easier to maintain clean cable management and optimized airflow.10-year WarrantyEnjoy the peace of mind that the reliability of the ASUS Pro WS Platinum offers, backed by a 10-year warranty.
LongProductName - Pro WS 2200W Platinum
LongSummaryDescription - ASUS Pro WS 2200W Platinum. Total power: 2200 W, AC input voltage: 200 - 240 V, Power Factor Correction (PFC) type: Active. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Active. Compliance certificates: RoHS
name - ASUS Pro WS Platinum, 80 PLUS Platinum Netzteil, modular, ATX 3.1, PCIe 5.1 - 2200 Watt
Packaging data - Package depth - 208 mm
Packaging data - Package height - 144 mm
Packaging data - Package type - Box
Packaging data - Package weight - 5.06 kg
Packaging data - Package width - 346 mm
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - ATX version - 3.1
Performance - Bearing technology - Ball bearing
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 100 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 61 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power cable length - 75 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - PCI Express power connectors (16-pin) - 4
Ports & interfaces - Peripheral (Molex) power cable length - 150,400 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Ports & interfaces - SATA power cable length - 120,400 mm
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 2200 W
Power - Combined power (-12V) - 9.6 W
Power - Efficiency - 92%
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 183.3 A
Power - Max output current (-12V) - 0.8 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 2200 W
ProductName - Pro WS 2200W Platinum
ShortSummaryDescription - ASUS Pro WS 2200W Platinum, 2200 W, 200 - 240 V, Active, 130 W, 2200 W, 130 W
Title - ASUS Pro WS 2200W Platinum power supply unit 20+4 pin ATX ATX Black
URL - https://www.asus.com/motherboards-components/power-supply-units/workstation/asus-pro-ws-2200p/
WarrantyInfo - 10 years
Weight & dimensions - Depth - 175 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.13 kg
Weight & dimensions - Width - 150 mm
