Accessories included - Deco S7 unit RJ45 Ethernet cable Charger Quick installation guide
Antenna - Built-in
Brand - TP-Link
BrandPartCode - DECO S7(1-PACK)
Category - Mesh Wi-Fi Systems
Certificates - CE FCC RoHS NCC BSMI JRF JPA VCC
Certificates - Certification - CE, FCC, RoHS, NCC, BSMI, JRF, JPA, VCCI
Certificates - Compliance certificates - CE, RoHS
Color - White
Description - Home Wi-Fi Mesh System, AC1900 Fast Wi-Fi - Watch your favorite series in 4K resolution with total wireless speeds of up to 1900 Mbps (600 Mbps on the 2.4 GHz band and 1300 Mbps on the 5 GHz band) and MU-MIMO 3 technology ×3. Connect over 100 devices - The Deco system can handle traffic even in the busiest networks, providing lag-free connections for over 100 devices. Enhanced Wi-Fi Signal - Thanks to advanced Deco Mesh technology, system units work together to create a unified network. Your devices will automatically connect to Deco offering the best signal as you move around your home. Gigabit ports - 3 Gigabit Ethernet WAN/LAN ports provide fast and stable Internet access. Extensive Parental Controls - Limit time spent online and block inappropriate websites based on the profiles you create for each family member. Two operating modes - The Deco system can operate as a Router or access points. Easy configuration - The Deco application will guide you step by step through the entire configuration process. Wi-Fi dead zone killer Deco S7 is the easiest way to have a strong wireless signal throughout your home. One Deco device covers an area of up to 190 m2 with a wireless network. Wireless connections and optional Ethernet backhaul connect Deco units for even faster speeds and unprecedented switching smoothness. Need more Wi-Fi coverage? Just add another Deco unit. Smooth and fast switching TP-Link Mesh technology makes Deco units work together to create a unified Wi-Fi network. When moving around the house, your phone or tablet will always connect to the Deco unit that offers it the best connection, without interrupting the transfer. Two operating modes: Router and Access Point The multifunctional and flexible Deco S7 device can operate in both router and access point mode. Choose the mode appropriate to your current network requirements and enjoy all the possibilities of a wireless network. Simplified Wi-Fi access Configuration via app - Installing Deco S7 is quick and simple. Unpack your devices, install the app, and then follow the on-screen instructions. Simple management - With the Deco application you can manage your network from home or remotely. The application allows, among other things, verification of connected devices, assigning them priorities, and configuring the network for guests in a few simple steps. Voice Control - Pair Deco S7 with Alexa and control the device with simple voice commands. Reliable parental controls The simple and intuitive parental control function will make it easy for you to provide your child with comprehensive online protection. Works with all Deco models Deco S7 can create a mesh network with any other Deco model. To increase the range of the network, simply add another Deco unit to it.
Design - Antennas quantity - 3
Design - Antenna type - Internal
Design - LED indicators - Yes
Design - Maximum coverage - 520 m²
Design - Number of devices supported - 100
Design - Product colour - White
Design - Product type - Mesh router
Design - Reset button - Yes
Designation - CE+WEEE
dimension depth - 160 mm
dimension height - 310 mm
Dimensions - 162.3 × 90.7 × 90.7 mm
dimension weight - 1867 g
dimension width - 350 mm
ean - 6935364073046
Environment requirements - Permissible operating temperature: 0~40C (32 ~104F) Permissible storage temperature: -40~70C (-40 ~158F) Permissible air humidity: 10%~90%, no condensation Permissible storage humidity: 5%~90%, non-condensing
Features - Built-in processor - Yes
Features - Firewall security - SPI Firewall
Features - Mobile operating systems supported - Android 4.4, iOS 9.0
Features - MU-MIMO technology - Yes
Features - Parental control - Yes
Features - Parental control features - Content filter, Time controls
Features - Port forwarding - Yes
Features - Processor frequency - 1.2 GHz
Features - Quality of Service (QoS) support - Yes
Features - Supported WAN type - Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Features - Transmitting power (CE) - 20 - 23 dBm
Features - Transmitting power (FCC) - 30 dBm
Features - Universal Plug and Play (UPnP) - Yes
GTIN - 4897098681503
guarantee - 36
guarantee_type - normal
I/O ports - 3 x 10/100/1000 Mbit/s
LongDesc - Fast. Stable. Everywhere.Whole Home Mesh Wi-Fi SystemAC1900 Dual-Band Wi-FiWiFi Dead Zone KillerDeco S7 offers a simple way to guarantee a strong WiFi signal in every corner of your home up to 3,900 square feet (2-pack). Wireless connections and an optional Ethernet backhaul work together to link Deco units, providing even faster network speeds and truly seamless coverage.Want more coverage? Simply add another Deco.Stay Fast with Seamless RoamingTP-Link Mesh means Deco units work together to form one unified network. Your phone or tablet automatically connects to the fastest Deco as you move through your home, creating a truly seamless WiFi experience.2-in-1 Router and Access Point ModesFlexible and multifunctional, Deco S7 includes a variety of features allowing it to serve as a router or access point. Just choose the mode that best suits your actual network demands and enjoy maximum wireless flexibility.App-Based SetupInstalling Deco S7 is fast and easy. Just unpack the system, download the Deco app, and follow its on-screen directions.Easy ManagementManage your WiFi at home or away with the Deco app. See all your connected devices, prioritize them, and set up a guest network with just a few taps.Voice ControlPair with Alexa to control Deco S7 with simple voice commands. Enjoy the convenient life.Robust Parental ControlsSimple, intuitive parental controls make it easy tokeep your children safe while they’re online.All Decos CanWork TogetherDeco S7 is compatible with every other Deco model toform a Mesh network. Expand Mesh Wi-Fi coverageanytime by simply adding more Decos
LongProductName - AC1900, 5 / 2.4 GHz, Wi-Fi 5, 1.2 GHz CPU, 3 x Gigabit Ports, 162.3 × 90.7 × 90.7 mm
LongSummaryDescription - TP-Link AC1900 Whole Home Mesh Wi-Fi System. Product colour: White, Antenna type: Internal, Product type: Mesh router. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac). Processor frequency: 1.2 GHz, Firewall security: SPI Firewall, Transmitting power (CE): 20 - 23 dBm. Compliance certificates: CE, RoHS, Certification: CE, FCC, RoHS, NCC, BSMI, JRF, JPA, VCCI. Width: 162.3 mm, Depth: 90.7 mm, Height: 90.7 mm
Management, monitoring, configuration - Modes of operation: Router mode Access point mode Parental Control: Website address filtering Access limits WAN: Dynamic IP address allocation Static IP address allocation PPPoE PPTP L2TP Quality of Service: QoS priorities for devices Cloud service: OTA software updates TP-Link ID DDNS NAT redirection: Port forwarding UPnP IPTV: IGMP Proxy IGMP Snooping Bridge VLAN tagged DHCP: Address reservation DHCP client list Server DDNS: TP-Link
Model - DECO S7
name - System WiFi Deco S7(1-pack) AC1900
Network architecture - GigabitEthernet
Number of antennas - 3
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Other features - Reset button AC1900 WiFi speeds: 5GHz: 1300Mbps (802.11ac) 2.4GHz: 600Mbps (802.11n) WiFi CE transmission power: < 20 dBm (2.4 GHz) < 23 dBm (5 GHz)
Packaging content - AC adapter included - Yes
Packaging content - Ethernet cable - Yes
Packaging content - Number of products included - 1 pc(s)
Packaging content - Number of units included - 1 pc(s)
Ports & interfaces - Ethernet LAN (RJ-45) ports - 3
Ports & interfaces - Ethernet WAN - Yes
Power supply -
producer - TP-LINK
ProductName - AC1900 Whole Home Mesh Wi-Fi System
Security - Network protection: SPI Firewall Access control Guest Network Feature: 5 GHz guest network 2.4 GHz guest network WiFi network encryption: WPA-Personal WPA2-Personal
ShortSummaryDescription - TP-Link AC1900 Whole Home Mesh Wi-Fi System, White, Internal, Mesh router, 520 m², Dual-band (2.4 GHz / 5 GHz), Wi-Fi 5 (802.11ac)
Software - Deco application
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
Supported operating systems - Android
Supported operating systems - iOS
Sustainability - Sustainability compliance - Yes
System Requirements -
Title - TP-Link AC1900 Whole Home Mesh Wi-Fi System
Type - xDSL
URL - https://www.tp-link.com/en/home-networking/deco/deco-s7/v1%20(2-pack)/#overview
vendpn - Deco S7(1-pack)
WarrantyInfo -
Weight & dimensions - Depth - 90.7 mm
Weight & dimensions - Height - 90.7 mm
Weight & dimensions - Width - 162.3 mm
Wireless LAN features - Dynamic DNS (DDNS) - Yes
Wireless LAN features - Dynamic IP - Yes
Wireless LAN features - IGMP snooping - Yes
Wireless LAN features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ad, IEEE 802.11ax, IEEE 802.11az, IEEE 802.11n
Wireless LAN features - Number of guest networks (2.4 GHz) - 1
Wireless LAN features - Number of guest networks (5 GHz) - 1
Wireless LAN features - Point-to-point protocol over Ethernet (PPPoE) - Yes
Wireless LAN features - Security algorithms - WPA, WPA2
Wireless LAN features - Static IP - Yes
Wireless LAN features - Tagged VLAN - Yes
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (first band) - 600 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 1300 Mbit/s
