10/100/1000M LAN Ports - 3
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Available bandwidth - 1200 Mbps
Brand - Dahua Technology
BrandPartCode - DH-AC12
Category - Wireless Routers
Category Code - WRO
Colour - Black
Description - "AC1200 Wireless Router > 1.2 Gbps Wireless Speed(300 Mbps@2.4 GHz, 867 Mbps@5 GHz). > Backward compatible (IEEE 802.11 b/g/n/ac standard). > Beamforming for better Coverage. > Bi-directional MU-MIMO. > WiFi protected Access(WPA/WPA2). > Guest Wi-Fi. > Parental Control."
Design - Indication light - Yes
Design - Product colour - Black
Design - Product type - Tabletop router
Design - Wall mountable - Yes
Dimensions - 222 × 147.4 × 188.4 mm
Features - Firmware upgradeable - Yes
Features - Internal memory - 64 MB
Features - Number of simultaneously connected devices (max) - 32
Full Description Line - AC12|Wireless Router|Available bandwidth 1200 Mbps|IEEE 802.1ab|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|3x10/100/1000M|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|Number of antennas 4|Wireless Frequency Range 2.4/5 GHz|Wireless Transmit Power 20 dBm|Included Accessories 1 × Power adapter,1 × Ethernet cable,1 × Quick Start Guide,1 × Legal and Regulatory Information|Power supply requirements 12 VDC,1A|Colour Black|Dimensions 222 × 147.4 × 188.4 mm
GTIN - 6923172557315
IEEE 802.1ab Network standard - Yes
IEEE 802.11ac Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Included Accessories - 1 × Power adapter,
1 × Ethernet cable,
1 × Quick Start Guide,
1 × Legal and Regulatory Information
LAN \ WAN ports - 1
LongDesc - DH-AC12 Gigabit Wireless Router has a wide signal coverage and fast wireless speed. It complies with the IEEE 802.11ac standard, and its wireless speed reaches up to 1,167 Mbps, allowing smooth internet access. It uses beamforming technology to widen its Wi-Fi coverage, and has a built-in 1 GHz high-performance processor, which provides it with strong processing capabilities and high data transmission speeds. The router can be managed through the WiLynk app and provides wireless networks, making it a great choice for common wireless applications.
LongProductName - 1.2 Gbps, IEEE 802.11b/g/n/ac, 2.4-5 Ghz, 4x RJ-45, 64 MB RAM, 12 VDC, 1 A, 0.31 kg
LongSummaryDescription - Dahua Technology AC12 AC1200 Wireless Router. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: 64-bit WEP, 128-bit WEP, WEP, WPA, WPA2. Product type: Tabletop router, Product colour: Black
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Web-based management - Yes
Model name - AC12
Network - Automatic channel selection - Yes
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN interface type - Ethernet
Network - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Network - Receiver sensitivity - 5GHz
11ac VHT80_MCS0: -89dbm
11ac VHT80_MCS9:-62dbm
2.4GHz
11n HT20_MCS0: -95dbm
11n HT20_MCS7: -75dbm
11n HT40_MCS0: -92dbm
11n HT40_MCS7: -72dbm
Network - VPN Passthrough - Yes
Network Device Type - Wireless Router
Number of antennas - 4
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - 20 - 70 °C
Other features - Bandwidth (first) - 2.484 GHz
Other features - Bandwidth (second) - 5.85 GHz
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Manual - Yes
Packaging content - Quick start guide - Yes
Packaging data - Number of products included - 1 pc(s)
Packaging data - Package depth - 300 mm
Packaging data - Package height - 70 mm
Packaging data - Package width - 260 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB port - No
Power - External power adapter - Yes
Power - Output current - 1 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 12 W
Power - Power source type - DC
Power supply requirements - 12 VDC,1A
ProductName - AC12 AC1200 Wireless Router
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Security - Network address translation (NAT) - Yes
Security - Parental control - Yes
Security - Security algorithms - 64-bit WEP, 128-bit WEP, WEP, WPA, WPA2
Security - System event log - Yes
Shipping Box Depth Shipping/Package Box Dimensions - 30 cm
Shipping Box Height Shipping/Package Box Dimensions - 26 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.61 kg
Shipping Box Width Shipping/Package Box Dimensions - 7 cm
ShortSummaryDescription - Dahua Technology AC12 AC1200 Wireless Router, Wi-Fi 5 (802.11ac), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Tabletop router
Title - Dahua Technology AC12 AC1200 Wireless Router
Unit Box Height - 0.26
Unit Box Length - 0.3
Unit Box Width - 0.07
Unit Brutto Volume - 0.00546 cubm
Unit Gross Weight - 0.61 kg
Unit Net Weight - 0.31 kg
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/IT-Channel-Products/Wireless-Router/AC12
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Transmission/IT-Channel-Products/Wireless-Router/AC12
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 222 mm
Weight & dimensions - Height - 188.4 mm
Weight & dimensions - Weight - 310 g
Weight & dimensions - Width - 147.4 mm
Wireless Frequency Range - 2.4/5 GHz
Wireless LAN features - Channel bandwidth - 80 MHz
Wireless LAN features - Channels quantity - 165 channels
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 1200 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 867 Mbit/s
Wireless Transmit Power - 20 dBm
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
