Samsung WA65F

Accessories included -
Auto Pivot - No
Bezel width, mm - 14.0
Bluetooth - Yes
Brand - Samsung
BrandPartCode - LH65WAFWLGCXEN
Brightness - 400 nits
Category - Interactive Whiteboards
Category 1 - Displays
Category 2 - Monitore
Certificates - EMC
Color - Black
Computer system - Operating system installed - Android
Computer system - User memory - 64 GB
Connections - Audio (3.5mm)
Connections - Ethernet (RJ-45)
Connections - HDMI 2.1
Connections - Serial (RS-232)
Connections - USB
Contrast ratio (typical) - 1200:1
Curved - 0 R
Data Act - Link
Depth - 87.7 mm
Description - SAMSUNG WAF EBOARD WA65F, 65", ANDROID 14 (8GB RAM, 64GB STORAGE), UHD, IR TOUCH, 2XHDMI (CEC) 2.0, USB-C PD 65W, VIDEO OUT HDMI, USB 4(2.0X1, 4X3.0), OPS SLOT, 2X15W SPEAKERS, LANDSCAPE ONLY
Description - Unlimited Learning Possibilities
The interactive WAF series display, powered by the Android operating system, perfectly supports school learning thanks to Google services and a seamless note-taking function. The WAF display is a solution designed for the modern school, enabling instant note-taking and effective student collaboration.
Android OS
The WAF series offers users an intuitive and convenient user experience. The display is compatible with other Android devices and allows the home screen to be customized with frequently used applications. These features provide greater flexibility in building an environment that meets various learning needs.
EDLA Certification
Earning EDLA certification for the WAF series allows the use of various Google services, such as Google Play and YouTube. Access to key educational applications, including Google Classroom, leads to increased productivity and improved communication with students.
Active Note-Taking Function
The WAF series display allows users to take notes at any time using the always-visible "Annotate" button. Students can take notes without interruption, even while other content is being presented on the screen. This makes collaboration more harmonious, engaging, and less likely to be interrupted due to technical issues.
Split Notes Mode
The improved Notes app allows multiple students to use the whiteboard simultaneously. Up to four students can work in their own zones without impacting others, supporting both collaboration and individual learning.
Supports Multitasking
Content can be easily displayed in a variety of ways, including split-screen and multiple, customizable windows, to support multitasking. This functionality helps teachers conveniently organize all the information needed to create an engaging learning environment.
Efficient Content Sharing
The WAF series allows screen mirroring for up to nine devices simultaneously, increasing student engagement. This feature ensures every student is engaged and actively working, as content can be shared both on the large display and across individual devices. This mode can be supported by iOS, Mac, Windows, Android, or Chrome OS devices.
Multi-Touch
Multiple users can write on the screen simultaneously thanks to advanced multi-touch capabilities. The display recognizes up to 40 simultaneous touches, allowing large groups of students and teachers to collaborate and learn together in a fun and natural way.
Dual Pen
The dual pen feature allows you to use two different writing tools simultaneously. Both ends of the pen are active, with each end corresponding to a different color. Users simply flip the pen over without having to interrupt the lesson or adjust its settings.
Quick Access Features
The WAF display features physical controls located on the front panel, providing quick access to frequently used functions. This intuitive control allows for more efficient use of the interactive display, improving the overall user experience.
Designation - CE+WEEE
dimension depth - 1650 mm
dimension height - 1010 mm
Dimensions W x D x H, mm - 1482.1 x 87.7 x 897.5
dimension weight - 44000 g
dimension width - 185 mm
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 400 cd/m²
Display - Display diagonal - 165.1 cm (65")
Display - Display resolution - 3840 x 2160 pixels
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - Panel type - IPS
Display - Pixel pitch - 0.372 x 0.372 mm
Display - Response time - 8 ms
Display - Touchscreen - Yes
Display - Touchscreen type - Infrared
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness, cd/m² - 400
Display diagonal, " - 65
Display resolution, pixels - 3840 x 2160
Display surface - Matt
ean - 8806095981819
EAN - 8806095981819
Energy class - not applicable
Ergonomics - Panel mounting interface - 600 x 400 mm
Ergonomics - Product colour - Black
Ergonomics - VESA mounting - Yes
Flash memory - 64 GB
Frequency, horizontal max. - 135 kHz
Frequency, vertical max. - 60 Hz
GTIN - 8592978644505
GTIN - 8806095981819
guarantee - 24
guarantee_type - external
Height - 897.5 mm
Height - 1005.000000
Height adjustment - No
I/O connectors - 1 x 3,5 mm minijack
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 2 x HDMI
I/O connectors - 2 x USB 2.0
Internal player - Yes
Length - 1635.000000
LongDesc - Unlimited Learning PossibilitiesThe interactive display WAF series, powered by Android OS, enhances education with Google services and a seamless annotation function. Instantly take notes at any moment and empower students to collaborate independently in separate zones, ushering in a new era of interactive education.An intuitive UX that fits your needsPowered by Android™The WAF series offers familiarity to its users. It's compatible with other Android devices and provides a variety of widgets and an easily customizable home screen. These features create more flexibility in building an environment that suits various learning needs.Effortless access to Google servicesEDLA CertificationWith an EDLA certification, the WAF series supports a variety of Google services like Google Play and YouTube. This access to major educational apps like Google Classroom leads to increased efficiency and enhanced communication with students.Take notes instantly, anywhere on the screenAnnotation OnThe WAF series lets users take notes anytime with a simple press of the always-visible Annotation button. Whether watching a video or viewing any content, users can seamlessly annotate without interruptions, avoiding the need to capture images first and enhancing productivity.Write independently, learn togetherSplit Note ModeThe upgraded Note app allows up to four independent note zones on a single page, enabling multiple students to use the whiteboard simultaneously. Students can work in their own zones without affecting others, fostering both collaboration and individual learning.Display multiple screens simultaneouslyEasy MultitaskingThe split screen and multi-window, enable teachers to easily display information and multitask at the same time on the WAF series. This flexibility provides convenient access to all the screens required to create engaging learning environments.Smart, wireless sharing on multiple devicesPowerful Screen SharingThe WAF series supports screen mirroring for up to nine devices, increasing student engagement. This feature ensures every student is included and engaged as content can be shared on both the large display and individual devices. It can be used on iOS, Mac, Windows, Android.Better interaction with best-in-class multi-touchMulti-point touch drawingMultiple users can write and draw on the whiteboard at the same time with the displays advanced multi-touch capabilities. Up to 40 simultaneous touchpoints are possible, allowing large groups of students and teachers to collaborate and learn together in a fun and natural way.Switch pens without changing settingsDual PenThe dual pen function enables the use of two different writing tools with no downtime. With the double-sided nib applied, users can effortlessly switch between two different colors on the front and back side of the pen – without needing to change the settings or interrupt the flow of the lesson.Front panel controls for intuitive navigationQuick Access ControlsThe WAF includes front-facing physical controls for quick access to frequently used functions. These intuitive controls allow users to operate the interactive display more efficiently, enhancing the overall user experience.Convenient connectivity with USB-C3-in-1 USB-C portConnectivity is enhanced with the 3-in-1 USB-C port, enabling screen mirroring, touch control and external device charging (max. 65W). Teachers can simply connect to the USB Type-C port, allowing them to deliver interactive and engaging lessons without any hassle.Accessible content for any class sizeHDMI outWith the HDMI Out function, whiteboard screen content can be shared on a different and larger screen in the classroom. This feature ensures teachers can provide a real-time, interactive experience for students who can easily view the screen content regardless of where they sit in the classroom.Use your favorite OS for the learningOPS (Open Pluggable Specification)The OPS slot in the WAF series can transform the interactive display into a Windows device, eliminating the need for an extra PC or devices. Users will have access to all the features and functionalities they are familiar with from a standard computer, directly on the display.Seamless management, efficient operationsDevice Management SolutionThe WAF series provides a device management solution[1] essential for advanced educational environments. This solution optimizes the remote management of whiteboard settings and applications, guaranteeing operational efficiency and stability.Notify across multiple devices, immediatelyAdvanced MessagingSend important messages across campuses, classrooms and public spaces immediately. Urgent communications are displayed on interactive whiteboards so students and other personnel are alerted in real time.
LongProductName - 65", 4K (3840 x 2160), IPS, IR Touch, 60Hz, HDMI, USB, LAN, WiFi, Bluetooth, 64 GB, Android OS
LongSummaryDescription - Samsung WA65F. Display diagonal: 165.1 cm (65"), Display brightness: 400 cd/m², Display resolution: 3840 x 2160 pixels. Operating system installed: Android, User memory: 64 GB. Wi-Fi standards: Wi-Fi 5 (802.11ac). Headphone connectivity: 3.5 mm. Product colour: Black, Panel mounting interface: 600 x 400 mm
Manufacturer - Samsung
Manufacturer - SAMSUNG
ManufacturerPartNumber - LH65WAFWLGCXEN
Matrix type - TFT IPS
Model - WA65F
MPN - LH65WAFWLGCXEN
name - Monitor 65 inches WA65F LH65WAFWLGCXEN
Name - Samsung Smart Signage WA65F 165.1cm(65") (Speditionsversand)
Network - Bluetooth - Yes
Network - Ethernet LAN - Yes
Network - Wi-Fi - Yes
Network - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Operating system provided - Android 14
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operation time - 12/7
Optional accessory -
Other features -
Packaging content - Remote control included - Yes
Packaging content - Stylus included - Yes
Packaging data - Package depth - 185 mm
Packaging data - Package height - 1010 mm
Packaging data - Package weight - 44.5 kg
Packaging data - Package width - 1640 mm
Panel type - IPS
Performance - Operating hours (hours/days) - 12/7
PeriodofWarranty - 36 M
Pivot - No
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDCP - Yes
Ports & interfaces - HDCP version - 2.1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Headphone connectivity - 3.5 mm
Ports & interfaces - Line-in - Yes
Ports & interfaces - Line-out - Yes
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB Type-C ports quantity - 1
Ports & interfaces - Video out - Yes
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100-240 V
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 409 W
Power consumption - 409 W
Power consumption, W - 409
producer - Samsung
ProductName - WA65F
Refresh rate - 60 Hz
Refresh rate, Hz - 60
Resolution - 3840 x 2160
Response time - 8 ms
Response time, ms - 8
Screen size (diag.) - 65"
ShortSummaryDescription - Samsung WA65F, 165.1 cm (65"), 400 cd/m², 3840 x 2160 pixels, 4K Ultra HD, IPS, 1200:1
Speakers built-in - No
Static contrast - 1 200:1
Title - Samsung WA65F interactive whiteboard 165.1 cm (65") 3840 x 2160 pixels Touchscreen Black
Touch screen - Yes
Touch sensitive screen - Yes
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.samsung.com/uk/smart-signage/interactive-display/interactive-display-waf-65-inch-lh65wafwlgcxen/
vendpn - LH65WAFWLGCXEN
VESA - 600 x 400
VESA-standard, mm - 600 x 400
Viewing angle, horizontal - 178 °
Viewing angle, horizontal, ° - 178
Viewing angle, vertical - 178 °
Viewing angle, vertical, ° - 178
Warranty -
WarrantyInfo -
Web camera - None
Weight - 36.2 kg
Weight - 37.000000
Weight - 45
Weight & dimensions - Depth - 87.7 mm
Weight & dimensions - Height - 897.5 mm
Weight & dimensions - Weight - 36.2 kg
Weight & dimensions - Width - 1482.1 mm
Weight, kg - 36.2
Width - 185.000000
Width - 1482.1 mm
WiFi - Yes
WLAN type - Wi-Fi 5: 802.11ac
