Aktsia sihtmärk - 0
ARTIKEL1 - 2-portiline seeria PCIE kaart
ARTIKEL2 - .
Bränd - StarTech.com
Brändi osade kood - 2S232422485-PC-CARD
Disain - Sisemine - Jah
Disain - Toote värv - Must
EAN-kood - 0065030900270
Features - Baud rate - 921.6 Kbit/s
Funktsioonid - Voolu kontrolli tugi - Jah
Funktsioonid – FIFO (esimene sisse, esimene välja) - 256 B
Garantiiinfo - 2 aastat
Globaalne kaubakood - 0065030900270
Globaalne kaubakood - 065030900270
GRUPPE1 - Kõvaketas/optiline
GRUPPE2 - Sõidukontrollerid
HST NUMBER - 2S232422485-PC-CARD
Kaal ja mõõtmed - Kaal - 57 g
Kaal ja mõõtmed - Laius - 102 mm
Kaal ja mõõtmed - Sügavus - 105 mm
Kaal ja mõõtmed – Kõrgus - 16 mm
Kategooria - Liidesekaardid/adapterid
Kuidas sul läheb? - 0
Laenge - 0
laius - 0
Logistikaandmed – peamine (välimine) kasti kõrgus - 306 mm
Logistikaandmed – peamine (välimine) kasti laius - 685 mm
Logistikaandmed – peamine (välimine) kasti pikkus - 345 mm
Logistikandmed – tooted ühe peamise (välimise) kasti kohta - 75 tükki
Lühikokkuvõte - StarTech.com 2-portiline jadaportide PCIe-kaart, kahe portiga PCI Express – RS232/RS422/RS485 (DB9) jadaportide kaart, madala profiiliga kinnitused kaasas, 16C1050 UART, Windows/Linux, TAA-vastavus – 4. taseme ESD-kaitse, PCIe, jadaport, PCIe 2.0, RS-232/422/485, must, ASIX – AX99100
Muud omadused - Elektrostaatilise lahenduse (ESD) kaitse - 15 kilovolt
Omadused - Andmebitid - 5, 6, 7, 8, 9
Omadused - Kiibistik - ASIX – AX99100
Omadused - Pariteedibit - Paaris, Mark, Ei, Paaritu, Tühik
Omadused - Stoppbitid - 1, 1.5, 2
Pakendi andmed - Kaablid kaasas - Lintkaabel
Pakendi andmed - Kiirpaigaldusjuhend - Jah
Pakendi andmed - Kinnitusklambrid kaasas - Jah
Pakendi andmed - Pakendi kaal - 147.6 g
Pakendi andmed - Pakendi kõrgus - 30 mm
Pakendi andmed - Pakendi laius - 142 mm
Pakendi andmed - Pakendi sügavus - 170 mm
Pealkiri - StarTech.com 2-portiline jadaportide PCIe-kaart, kahe portiga PCI Express – RS232/RS422/RS485 (DB9) jadaportide kaart, madala profiiliga kinnitused kaasas, 16C1050 UART, Windows/Linux, TAA-vastavus – 4. taseme ESD-kaitse
Pikk kirjeldus - Lisage kaks RS-232, RS-422 või RS-485-ühilduvat DB9-sariporti lauaarvutisse PCIe x1 laienduskardi abilLisage lauaarvutisse või väikese vormifaktoriga (SFF) süsteemi sarikommunikatsiooni tugi, kasutades seda 2-portilist sariporti PCI Express-kaarti. Kaks DB9 porti saab iseseisvalt konfigureerida toetama RS-232, RS-422 ja 2/4-juhtmelisi RS-485 standardeid, et suhelda vastavate jadaportidega.Portide seeriaühenduse konfiguratsioonSee PCIe seeriaühenduse kaart on varustatud sisseehitatud DIP-lülititega, mis võimaldavad igal DB9 seeriaportil töötada RS-232, RS-422 ja/või RS-485 režiimis. Kaardil on iga pordi jaoks LED-indikaatorid, mis võimaldavad pordi tegevust reaalajas jälgida. Konfigureeritav välise SATA toidePCI Expressi jadaporti adapterkaardil on kolm toiterežiimi, mida saab konfigureerida sisseehitatud hüppajate abil, sealhulgas 12 V (1,5 A pordi kohta), 5 V (1,5 A pordi kohta) või toite puudumine (RI) pin 9 kaudu.Vanemate seadmete ühenduvusSee jadakaart võimaldab vanemate jadaseadmete jätkuvat kasutamist, vältides seisakuid ja kulukaid uuendusi. 2-portiline PCIe-jadakaart on ideaalne süsteemi uuendus paljudele rakendustele (nt müügipunkti terminalid, PLC-d, tehase juhtimine ja automatiseerimine, teaduslikud andurid, meditsiiniseadmed, skannerid ja ostsilloskoobid).StarTech.com eelis
Pikk kokkuvõte - StarTech.com 2-portiline jadaporti PCIe-kaart, kahe portiga PCI Express RS232/RS422/RS485 (DB9) jadaporti kaart, madala profiiliga kinnitused kaasas, 16C1050 UART, Windows/Linux, TAA-vastavus – 4. taseme ESD-kaitse. Host-liides: PCIe, väljundliides: jadaliides, laienduskardi standard: PCIe 2.0. Toote värv: must. Kiibistik: ASIX - AX99100, Baudikiirus: 921,6 Kbit/s, FIFO (First In, First Out): 256 B. Toetatud Windows-operatsioonisüsteemid: Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11..., Toetatud serveri operatsioonisüsteemid: Windows Server 2016, Windows Server 2019, Windows Server 2022. Laius: 102 mm, sügavus: 105 mm, kõrgus: 16 mm
Pikk tootenimi - StarTech.com 2-portiline jadaporti PCIe-kaart, kahe portiga PCI Express – RS232/RS422/RS485 DB9 jadaporti kaart, standard-/madalprofiiliga kinnitused, 16C1050 UART, ESD-kaitse, Windows/Linux (2S232422485-PC-CARD)
Pordid ja liidesed - Host-liides - PCIe
Pordid ja liidesed - jadaportide arv - 2
Pordid ja liidesed - Laienduskardi standard - PCIe 2.0
Pordid ja liidesed - Sarjaliidese tüüp - RS-232/422/485
Pordid ja liidesed - Väljundliides - Seeria
Stck_kaart - 9998
Süsteeminõuded - Toetatud Windows-operatsioonisüsteemid - Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11 Home, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 11 Pro, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 11 x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows 11, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 11 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64
Süsteeminõuded – toetatavad serveri operatsioonisüsteemid - Windows Server 2016, Windows Server 2019, Windows Server 2022
Süsteeminõuded – toetatud Linuxi operatsioonisüsteemid - Jah
Tehnilised andmed - Vastavussertifikaadid - RoHS, kaubanduslepingute seadus (TAA)
Tehnilised üksikasjad – jätkusuutlikkuse nõuete täitmine - Jah
Toote nimi - 2-portiline jadaporti PCIe-kaart, kahe portiga PCI Express RS232/RS422/RS485 (DB9) jadaporti kaart, madala profiiliga kinnitused kaasas, 16C1050 UART, Windows/Linux, TAA-vastavus – 4. taseme ESD-kaitse
TOOTJA - STARTECH
Töötingimused - Ladustamistemperatuur (T-T) - -20 - 80 °C
Töötingimused - Töötemperatuur (H-H) - 20 - 80%
Töötingimused - Töötemperatuur (T-T) - 0 - 70 °C
Tühistamine - Ja
Veebiaadress - https://www.startech.com/en-us/2S232422485-PC-CARD
Stck_Pal - 0
ARTIKEL1 - 2-PORT SERIAL PCIE CARD
ARTIKEL2 - .
Brand - StarTech.com
BrandPartCode - 2S232422485-PC-CARD
Design - Internal - Yes
Design - Product colour - Black
EANCode - 0065030900270
Features - Baud rate - 921.6 Kbit/s
Features - Flow control support - Yes
Features - FIFO (First In, First Out) - 256 B
WarrantyInfo - 2 Years
GTIN - 0065030900270
GTIN - 065030900270
GRUPPE1 - Hard Drive/Optical
GRUPPE2 - Drive Controllers
HSTNUMMER - 2S232422485-PC-CARD
Weight & dimensions - Weight - 57 g
Weight & dimensions - Width - 102 mm
Weight & dimensions - Depth - 105 mm
Weight & dimensions - Height - 16 mm
Category - Interface Cards/Adapters
Hoehe - 0
Laenge - 0
Breite - 0
Logistics data - Master (outer) case height - 306 mm
Logistics data - Master (outer) case width - 685 mm
Logistics data - Master (outer) case length - 345 mm
Logistics data - Products per master (outer) case - 75 pc(s)
ShortSummaryDescription - StarTech.com 2-Port Serial PCIe Card, Dual-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Brackets Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection, PCIe, Serial, PCIe 2.0, RS-232/422/485, Black, ASIX - AX99100
Other features - Electrostatic Discharge (ESD) protection - 15 kV
Features - Data bits - 5, 6, 7, 8, 9
Features - Chipset - ASIX - AX99100
Features - Parity bit - Even, Mark, No, Odd, Space
Features - Stop bits - 1, 1.5, 2
Packaging data - Cables included - Ribbon cable
Packaging data - Quick installation guide - Yes
Packaging data - Mounting brackets included - Yes
Packaging data - Package weight - 147.6 g
Packaging data - Package height - 30 mm
Packaging data - Package width - 142 mm
Packaging data - Package depth - 170 mm
Title - StarTech.com 2-Port Serial PCIe Card, Dual-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Brackets Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection
LongDesc - Add two RS-232, RS-422, or RS-485-capable DB9 Serial Ports to a desktop computer via PCIe x1 Expansion CardAdd serial communication support to a desktop computer or Small Form Factor (SFF) system, using this 2-Port Serial PCI Express Card. The two DB9 ports can be independently configured to support RS-232, RS-422, and 2/4-wire RS-485 standards, for communication with compliant serial peripheral devices.Per-Port Serial ConfigurationThis PCIe Serial Card is equipped with on-board DIP switches, enabling each DB9 serial port to operate in RS-232, RS-422, and/or RS-485 mode(s). The card features LED indicators per port, providing real-time monitoring of port activity.Configurable External SATA PowerThe PCI Express Serial Adapter Card features three power modes that are configurable via on-board jumpers, including 12V (1.5A per port), 5V (1.5A per port), or no power (RI), over pin 9.Legacy ConnectivityThis serial card enables the continued use of legacy serial devices, preventing down time and avoiding costly upgrades. The 2-Port PCIe Serial Card is an ideal system upgrade for a wide range of applications (e.g., point-of-sale terminals, PLCs, factory control and automation, scientific sensors, medical equipment, scanners, and oscilloscopes).The StarTech.com Advantage
LongSummaryDescription - StarTech.com 2-Port Serial PCIe Card, Dual-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Brackets Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection. Host interface: PCIe, Output interface: Serial, Expansion card standard: PCIe 2.0. Product colour: Black. Chipset: ASIX - AX99100, Baud rate: 921.6 Kbit/s, FIFO (First In, First Out): 256 B. Windows operating systems supported: Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11..., Server operating systems supported: Windows Server 2016, Windows Server 2019, Windows Server 2022. Width: 102 mm, Depth: 105 mm, Height: 16 mm
LongProductName - StarTech.com 2-Port Serial PCIe Card, Dual-Port PCI Express to RS232/RS422/RS485 DB9 Serial Card, Standard/Low-Profile Brackets, 16C1050 UART, ESD Protection, Windows/Linux (2S232422485-PC-CARD)
Ports & interfaces - Host interface - PCIe
Ports & interfaces - Serial ports quantity - 2
Ports & interfaces - Expansion card standard - PCIe 2.0
Ports & interfaces - Serial interface type - RS-232/422/485
Ports & interfaces - Output interface - Serial
Stck_Kart - 9998
System requirements - Windows operating systems supported - Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11 Home, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 11 Pro, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 11 x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows 11, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 11 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64
System requirements - Server operating systems supported - Windows Server 2016, Windows Server 2019, Windows Server 2022
System requirements - Linux operating systems supported - Yes
Technical details - Compliance certificates - RoHS, Trade Agreements Act (TAA)
Technical details - Sustainability compliance - Yes
ProductName - 2-Port Serial PCIe Card, Dual-Port PCI Express to RS232/RS422/RS485 (DB9) Serial Card, Low-Profile Brackets Incl., 16C1050 UART, Windows/Linux, TAA Compliant - Level-4 ESD Protection
HERSTELLER - STARTECH
Operational conditions - Storage temperature (T-T) - -20 - 80 °C
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Storno - Y
URL - https://www.startech.com/en-us/2S232422485-PC-CARD
