ARTIKEL1 - SFP 1000SX MM DUAL F. LC
ARTIKEL2 - FED VERSION 990-004928-90 IN
Brand - Allied Telesis
BrandPartCode - AT-SPSX-90
Category - Network Transceiver Modules
EANCode - 0767035173276
Features - Hot-swap - Yes
Features - Housing material - Metal
Features - Plug and Play - Yes
Features - Product colour - Silver
GRUPPE1 - Network
GRUPPE2 - Media Converters
GTIN - 0767035173276
GTIN - 767035173276
HERSTELLER - ALLIED TELESIS
Hoehe - 0.02
HSTNUMMER - AT-SPSX-90
Laenge - 0.1
LongDesc - Gigabit Small Form-Factor Pluggable ModulesThe Allied Telesis SP Series delivers flexible, full-duplex Ethernet connectivity. These hot-swappable fiber and copper interfaces simply plug into the SFP slot on all SFP-compatible devices. Configuration can be optimized to meet a wide variety of distance and service requirements.CompatibilityAllied Telesis SP Series Gigabit Small Form-Factor Pluggables (SFPs) are supported on all Allied Telesis devices with SFP uplink connections.SP Series SFPs are Multi-Sourcing Agreement (MSA)-compliant, and fully adhere to industry standard networking regulations. This allows the SP Series to be used with other MSA-compliant platforms that support SFP uplink connections.For Cisco compatibility please refer to the “SFP Compatibility Flyer”.OptionsSP Series SFPs offer short-haul,long-haul and Bi-Directional (BiDi) solutions. This flexibility allows network managers to easily extend network distance and bandwidth.Using an SFP BiDi transceiver can upgrade transmission capacity on a typical network—without installing new fibers—by utilizing a single fiber for both the send and receive signals.Multiple temperature rangesDifferent network environments call for a variety of temperature ranges. The SP Series is available in standard (0-70°C), industrial (-40 to 85°C), and extended (-40 to 105°C) temperature variants.
LongProductName - 1000SX SFP, LC, MMF, 850 nm, TAA
LongSummaryDescription - Allied Telesis AT-SPSX-90. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Product colour: Silver, Housing material: Metal. Quantity per pack: 1 pc(s). RX sensitivity: -19 dB
Operational conditions - Operating temperature (T-T) - -40 - 105 °C
Other features - RX sensitivity - -19 dB
Packaging content - Quantity per pack - 1 pc(s)
Performance - Fiber optic connector - LC
Performance - Interface type - SFP
Performance - Link budget - 11 dB
Performance - Maximum data transfer rate - 1000 Mbit/s
Performance - Maximum transfer distance - 550 m
Performance - Multi-mode fiber (MMF) supported - Yes
Performance - SFP transceiver type - Fiber optic
Performance - Tx power (max) - -3 dBmW
Performance - Tx power (min) - -8 dBmW
Performance - Wavelength - 850 nm
ProductName - AT-SPSX-90
ShortSummaryDescription - Allied Telesis AT-SPSX-90, Fiber optic, 1000 Mbit/s, SFP, LC, 550 m, 850 nm
Stck_Kart - 0
Stck_Pal - 0
Storno - Y
Title - Allied Telesis AT-SPSX-90 network transceiver module Fiber optic 1000 Mbit/s SFP 850 nm
URL - https://www.alliedtelesis.com/documents/datasheet-sp-series?at_language_code=ko
WarrantyInfo -
