Accessories included - Power cord
ARTIKEL1 - 90W MULTI GIG POE INJECTOR
ARTIKEL2 - 1/25/5/10GB SINGLE PORT
Auto MDI/MDI-X - Yes
Brand - Zyxel
BrandPartCode - POE12-90W-EU0101F
Breite - 0
Broadcast storm control - Yes
Category - Power Adapters & Inverters
Certification - CE, FCC, C-Tick, Class A
Depth - 196.25 mm
Description - 10G PoE++ Injector POE12-90W-EU0101F As the demand for connectivity to network devices such as IP phones, IP cameras, and access points increases, so does the complexity of deployment and costs. To reduce cable usage and investment, Power over Ethernet (PoE) technology provides both data connectivity and power to devices using a single cable without the limitations of a power outlet. Equipped with the advantages of PoE technology, Zyxel's PoE injectors provide super-fast LAN connectivity with a high power budget; they easily connect to PoE devices using Cat 5e or newer cable. The PoE12-90W supports the PoE++ standard, ensuring interoperability with other standard-based PoE-enabled devices. Higher network speeds increase network performance Zyxel PoE injectors are designed to meet the growing demand for high-speed network devices, including WiFi 7 and WiFi 6 access points, PTZ surveillance cameras, and advanced POS terminals. The PoE12-90W model is equipped with Multi-Gig 5GbE and 10GbE ports, supporting speeds of up to 10 Gb/s.
Description - ZYXEL POE12-90W MULTI GIG 1/2,5/5/10GB SINGLE PORT 90W POE INJECTOR
Designation - CE+WEEE
dimension depth - 50 mm
dimension height - 155 mm
Dimensions W x D x H, mm - 196.25 x 80 x 39.8
dimension weight - 645 g
dimension width - 205 mm
ean - 4718937638178
EANCode - 4718937638178
Environment requirements - Operating Temperature -10°C to 40°C Humidity 5% to 90% (non-condensing) Storage Temperature -25°C to 65°C Humidity 5% to 90% (non-condensing)
Ethernet LAN (RJ-45) PoE ports quantity - 4
Features - Ethernet LAN - Yes
Features - Input current - 2 A
Features - Input frequency - 50/60 Hz
Features - Input voltage - 240 V
Features - Maximum input power - 102 W
Features - Maximum input voltage - 240 V
Features - Output power - 90 W
Features - Output voltage - 802.3bt
Features - Power current type - DC-to-AC
Features - Power protection features - Humidity resistant, Surge protection
Features - Power supply type - Indoor
Features - Purpose - Power supply
Features - RJ-45 ports quantity - 2
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Powerline Homeplug
GTIN - 4718937638178
guarantee - 60
guarantee_type - normal
Height - 39.8 mm
Height - 48.000000
HERSTELLER - ZYXEL
Hoehe - 0
HSTNUMMER - POE12-90W-EU0101F
I/O ports - 2 x 10 Gbit/s
IGMP snooping - Yes
Jumbo Frames support - Yes
Laenge - 0
Length - 207.000000
LongDesc - Zyxel PoE injectors are here to meet the increasing demand for connections to high-speed networking devices such as WiFi 7 and WiFi 6 APs, surveillance PTZ cameras, and advanced POS terminals. The PoE12-30W supports network speeds of up to 2.5Gbps, while both the PoE12-60W* and PoE12-90W support network speeds of up to 10Gbps.*Limited support for Cat 6a, with cable lengths of up to 30 meters.The PoE12-30W complies with the IEEE 802.3at PoE+ standard, while the PoE12-60W and PoE12-90W comply with the IEEE 802.3bt PoE++ standard to provide PoE power budgets of up to 30W, 60W, and 90W, respectively. They ensure interoperability and compatibility with other standard-based PoE-capable devices.
LongProductName - 30W/60W/90W PoE Injectors Series
LongSummaryDescription - Zyxel PoE12-90W PoE Injector. Purpose: Power supply, Power supply type: Indoor, Input voltage: 240 V
MAC address filtering - Yes
Manufacturer - Zyxel
ManufacturerPartNumber - POE12-90W-EU0101F
name - Injektor 10G PoE++ POE12-90W-EU0101F
Networking standards - IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.1Q
Number of PoE++ ports - 2
Operating temperature range (T-T), °C - 0 - 40
Other features - MTBF @ 25°C (hours) 988,470 Heat dissipation (BTU/hour) 45.21 ESD (air/contact) 15KV/8KV Surge +/- 4KV Total PoE budget 90W PoE standard 802.3bt PoE++ Ethernet standard -IEEE 802.3u 100BASEX -IEEE 802.3ab 1000BASE-T -IEEE 802.3bz 2.5G/5GBASE-T -IEEE 802.3an 10G BASE-T
PeriodofWarranty - 5 Y
Ports quantity - 2
Power consumption, W - 0.138
Power over Ethernet (PoE), W - 60
Power over Ethernet (PoE), W - 90
Power over Ethernet (PoE) Support - Yes
Power supply - 100 - 240V 2.0A, 50/60Hz
producer - Zyxel
ProductName - PoE12-90W PoE Injector
Quality of Service (QoS) support - Yes
ShortSummaryDescription - Zyxel PoE12-90W PoE Injector, Power supply, Indoor, 240 V, 50/60 Hz, 90 W, 802.3bt
Stck_Kart - 9998
Stck_Pal - 0
Storage temperature range (T-T), °C - -40 - 70
Storno - Y
Switch type - Managed
Title - Zyxel PoE12-90W PoE Injector power adapter/inverter Indoor
URL - https://www.zyxel.com/global/en/products/switch/30w-60w-90w-poe-injectors-poe-injector-series/specifications
vendpn - POE12-90W-EU0101F
WarrantyInfo - Limited lifetime warranty
Web-based management - Yes
Weight - 0.640000
Weight - 456 g
Weight, g - 456
Width - 80 mm
Width - 155.000000
