Accessories included -
ARTIKEL1 - TS-H1277AXU-RP-R5-16G 2U 12BAY
ARTIKEL2 - 2.5IN 16GB UDIMMDDR5 NONECC RPS
Brand - QNAP
BrandPartCode - TS-H1277AXU-RP-R5-16G
Breite - 0
Built-in flash memory - 5 GB
Built-in RAM memory - 16 GB
Category - NAS & Storage Servers
Description - Powered by AMD Ryzen 7000 series processors based on AMD's cutting-edge socket AM5 platform, the TS-h1277AXU-RP's ZFS-based storage and backup solution delivers excellent performance and enterprise-level capabilities. With a revolutionary multi-core CPU, DDR5 RAM, M.2 PCIe Gen 5, and redundant power supplies, the TS-h1277AXU-RP delivers excellent performance, ultra-high bandwidth, and reliability for performance-demanding Tier 2 storage, virtualization, 4K video editing, and PB-level storage applications.
Design - Chassis type - Rack (2U)
Design - Cooling type - Active
Design - Fan diameter - 6 cm
Design - LED indicators - HDD
Design - LED indicators - HDD, LAN, Power, SSD, Status
Design - LED indicators - LAN
Design - LED indicators - Power
Design - LED indicators - SSD
Design - LED indicators - Status
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 26406
dimension depth - 350 mm
dimension height - 750 mm
Dimensions - 88.6 × 432 × 511.2 mm
dimension weight - 18360 g
dimension width - 590 mm
Disk type - HDD
Disk type - SSD
ean - 4711103084663
EANCode - 4711103084663
Expansion slots - 1 x PCIe 4.0 x 8
Expansion slots - 2 x PCIe 4.0 x 4
Fan - 6 cm
Form factor (width) - 2,5'' (SFF)
Form factor (width) - 3,5'' (LFF)
Gewicht - 18.56
GRUPPE1 - Storage
GRUPPE2 - Raid System
GTIN - 4711103084663
guarantee - 60
guarantee_type - normal
HDD interface - SATA II - 3 Gb/s
HDD interface - SATA III - 6 Gb/s
HERSTELLER - QNAP
Hoehe - 0
Hot-swapping support - Yes
Housing - Rack 2U
HSTNUMMER - TSH1277AXURPR516G
I/O connectors - 2 x USB 3.1
I/O connectors - 4 x RJ-45 LAN
Laenge - 0
Logistics data - Harmonized System (HS) code - 84714100
LongDesc - Powered by AMD Ryzen™ 7000 Series processors based on the cutting-edge AMD socket AM5 platform, the ZFS-based TS-h1277AXU-RP storage and backup solution unleashes superb performance and enterprise-level potential. With a revolutionary multi-core processor, DDR5 RAM, M.2 PCIe Gen 5, and redundant power supplies, the TS-h1277AXU-RP delivers excellent performance, ultra-large bandwidth, and trusted reliability for performance-demanding Tier 2 storage, virtualization, 4K video editing, and PB-level storage applications.Unmatched hardware design and high performanceThe TS-h1277AXU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet diverse application requirements.M.2 PCIe Gen 5 ultra-fast transfer speedThe TS-h1277AXU-RP comes with two M.2 2280 PCIe Gen 5 slots that allow for installing NVMe SSDs (including WD®, Micron®, Seagate®, Kingston®) to boost NAS performance. PCIe Gen 5 is backwards compatible with PCIe Gen 4 / PCIe Gen 3 for flexible SSD deployment.Abundant I/O capabilities with PCIe Gen 4 expansionThe TS-h1277AXU-RP has three PCIe Gen 4 slots (twice the bandwidth of PCIe Gen 3) that allow for installing various expansion cards for expanding application potential.Build an affordable Fibre Channel SAN environmentCommon Fibre Channel Storage Area Networks (SAN) devices are often costly. By installing QNAP dual-port 16Gb/32Gb Fibre Channel expansion cards in the TS-h1277AXU-RP, you have more budget-friendly options to add a NAS to a SAN environment. You can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.Comprehensive backup and disaster recovery solutionThe TS-h1277AXU-RP supports various apps that cover all your backup needs. Practice safe IT habits by regularly backing up files and device content, allowing them to be easily restored when needed.Multi-version snapshots mitigate ransomware threatsThe TS-h1277AXU-RP supports block-based snapshots that record the state of the system at any time. It helps protect data, which can be restored back to a specific point of time, greatly helping in mitigating the threat of ransomware.Comprehensive security and privilege settingsThe TS-h1277AXU-RP is loaded with flexible privilege settings and security measures. Besides IP blocking, QNAP Authenticator, HTTPS connection, there are more apps that help ensure optimal NAS protection against threats like malware and hackers.Simplified privilege settingsThe TS-h1277AXU-RP supports comprehensive access right settings for shared folders, Azure Active Directory Domain Services (Azure AD DS), LDAP, and Windows ACL to help IT staff efficiently manage user accounts and access rights for multiple NAS systems.Superior security with QVPNA virtual private network (VPN) allows secure access to network resources and services across public networks. QVPN supports creating a VPN client, using the TS-h1277AXU-RP as a VPN server, and WireGuard® VPN service with an easy-to-use interface for setting up a secure connection.QuWAN SD-WANTo facilitate digital transformation, multi-site expansion and remote working, QuWAN SD-WAN helps automatically mesh multi-site VPN. It features IPsec encryption and cloud-centric management, allowing secure multi-site network including QNAP NAS and VMware ESXi platforms.Security CounselorA security portal for the TS-h1277AXU-RP to check for weaknesses and offer recommendations for enhancing NAS security. It also integrates anti-virus and anti-malware scanning software.Malware RemoverRegularly scan your TS-h1277AXU-RP using the latest malware definitions. If infected files are detected, they will be immediately removed to ensure NAS data security.TeamViewer remote accessTeamViewer app enables remote management and connectivity to multiple NAS devices from Windows® PCs with an unparalleled level of safety, while increasing IT efficiency and end user productivity.All-in-one virtual machine and container hosting solutionYou can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with the Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources to simplify network deployment.Virtualization StationRun multiple Windows®, Linux®, UNIX®, Android™, and QuTScloud virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.Container StationExperience LXC and Docker® lightweight virtualization technologies, download apps from the built-in Docker Hub Registry®, import and export containers, and create abundant microservices.ZFS-based QuTS hero operating system enhances NAS performance and data integrityQuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.Flexibly switch to QTS operating systemThe TS-h1277AXU-RP also supports QTS - QNAP’s standard NAS operating system – that provides great everyday performance, efficient memory utilization, and the advantage of Qtier auto-tiering. You can also migrate drives from your current QTS-based NAS to the TS-h1277AXU-RP.
LongProductName - 2U 12-bay 3.5" SATA HDD NAS, AMD Ryzen 5 7000 series 6C12T (boost up to 5.1 GHz), 16GB DDR5 non-ECC RAM (max. 192GB total), 2x M.2 2280 PCIe Gen5 x2 slots for SSD cache, 2x 10GBASE-T + 2x 2.5 GbE RJ45, 3 x PCIe Gen 4 expansion slots, 2 x 550W redundant pwoer supply, without rail kit. Support rail kit RAIL-B02.
LongSummaryDescription - QNAP TS-H1277AXU-RP. Type: NAS. Chassis type: Rack (2U). Device class: Large Enterprise Business. Processor family: AMD Ryzen™ 5. Internal memory: 16 GB, Internal memory type: DDR5. Total installed storage capacity: 0 TB. Operating system installed: QuTS hero
Management, monitoring, configuration -
Max. number of disks - 12
Max memory size - 128 GB
Memory - ECC - No
Memory - Flash memory - 5000 MB
Memory - Internal memory - 16 GB
Memory - Internal memory type - DDR5
Memory - Maximum RAM supported - 192 GB
Memory - Memory form factor - UDIMM
Memory - Memory slots - 4
Memory type - DDR5
name - Server NAS TS-h1277AXU-RP-R5-16G 2U 12-bay 3.5 SATA AMD
Network - Copper ethernet cabling technology - 10GBASE-T
Network - DHCP server - Yes
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000,2500,5000,10000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Ethernet LAN data rates - 2500 Mbit/s
Network - Ethernet LAN data rates - 5000
Network - Ethernet LAN data rates - 10000 Mbit/s
Network - Ethernet LAN data rate supported (max) - 10000 Mbit/s
Network - iSCSI support - Yes
Network - Jumbo frames support - Yes
Network - Supported network protocols - IPv4, IPv6
Network - Wake-on-LAN ready - Yes
Network architecture - GigabitEthernet
Network interface - 2 x 10/100/1000/2500 Mbit/s
Network interface - 2 x 10Gbit/s 10GBase-T
Network protocols -
Number of available memory slots - 3
Number of fans - 3
Number of HDDs installed - 0
Number of memory slots used - 1
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other disk parameters -
Other features -
Packaging content - Cables included - AC
Packaging content - Cables included - AC, LAN (RJ-45)
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Number of screws - 84
Packaging content - Power cables quantity - 2
Performance - Access Control List (ACL) - Yes
Performance - Backup features - Cloud
Performance - Backup features - Cloud, iSCSI LUN
Performance - Backup features - iSCSI LUN
Performance - Backup function - Yes
Performance - Browser supported - Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Performance - Built-in FTP server - Yes
Performance - Buzzer - Yes
Performance - Device class - Large Enterprise Business
Performance - Disk scan - Yes
Performance - Hot spare - Yes
Performance - Management protocols - SNMP V2/V3
Performance - Multilingual support - Yes
Performance - On/off switch - Yes
Performance - Reset button - Yes
Performance - S.M.A.R.T. support - Yes
Performance - Security algorithms - 256-bit AES
Performance - Security algorithms - 256-bit AES, FIPS 140-2, HTTPS, TLS
Performance - Security algorithms - FIPS 140-2
Performance - Security algorithms - HTTPS
Performance - Security algorithms - TLS
Performance - Share folder - CIFS/SMB
Performance - Snapshot - Yes
Performance - System log - Yes
Performance - Type - NAS
Performance - Web-based management - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - PCI Express x8 (Gen 4.x) slots - 1
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Ports & interfaces - USB port - Yes
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Fan voltage - 12 V
Power - Number of power supply units - 2
Power - Power consumption (typical) - 367.65 W
Power - Power supply location - Built-in
Power - Power supply unit (PSU) capacity - 500 W
Power - Redundant power supply (RPS) support - Yes
Power supply - 550W(x2), 100-240V
Processor - AMD Ryzen 5 7000 series 6-core/12-thread processor, burst up to 5.1 GHz
Processor - Bus type - DMI3
Processor - CPU configuration (max) - 1
Processor - Processor boost frequency - 5.1 GHz
Processor - Processor cores - 6
Processor - Processor family - AMD Ryzen™ 5
Processor - Processor manufacturer - AMD
Processor - Processor threads - 12
Processor special features - Embedded options available - No
Processor special features - Enhanced Intel SpeedStep Technology - Yes
Processor special features - Execute Disable Bit - Yes
Processor special features - Idle States - Yes
Processor special features - Intel 64 - Yes
Processor special features - Intel Enhanced Halt State - Yes
Processor special features - Intel Secure Key Technology version - 1.00
Processor special features - Intel Trusted Execution Technology - Yes
Processor special features - Intel TSX-NI - Yes
Processor special features - Intel TSX-NI version - 1.00
Processor special features - Intel Virtualization Technology (VT-x) - Yes
Processor special features - Intel Virtualization Technology for Directed I/O (VT-d) - Yes
Processor special features - Intel VT-x with Extended Page Tables (EPT) - Yes
producer - QNAP
producerCode - TS-h1277AXU-RP-R5-16G
productName - QNAP TS-H1277AXU-RP NAS Rack (2U) AMD Ryzen™ 5 16 GB DDR5 0 TB QuTS hero Black
ProductName - TS-H1277AXU-RP
productSize - Normal
RAID - Yes
RAID levels - 0
RAID levels - 1
RAID levels - 5
RAID levels - 6
RAID levels - 10 (1+0)
RAID levels - JBOD
Safety warning - Warnings - Avoid contact with liquids.
Safety warning - Warnings - Do not dismantle the appliance yourself.
Safety warning - Warnings - Do not dispose of the device in the regular rubbish bin. The product requires special disposal.
ShortSummaryDescription - QNAP TS-H1277AXU-RP, NAS, Rack (2U), AMD Ryzen™ 5, 16 GB, DDR5, 0 TB
sizeX - 585
sizeY - 305
sizeZ - 740
Software - Linux operating systems supported - CentOS 7.0
Software - Linux operating systems supported - CentOS 7.0, Ubuntu 14.04
Software - Linux operating systems supported - Ubuntu 14.04
Software - Mac operating systems supported - Mac OS X 10.10 Yosemite
Software - Mac operating systems supported - Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Software - Mac operating systems supported - Mac OS X 10.11 El Capitan
Software - Mac operating systems supported - Mac OS X 10.12 Sierra
Software - Mac operating systems supported - Mac OS X 10.13 High Sierra
Software - Mac operating systems supported - Mac OS X 10.14 Mojave
Software - Mac operating systems supported - Mac OS X 10.15 Catalina
Software - Operating system installed - QuTS hero
Software - Operating system version - h5.0.0
Software - Server operating systems supported - Windows Server 2008 R2
Software - Server operating systems supported - Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Software - Server operating systems supported - Windows Server 2012
Software - Server operating systems supported - Windows Server 2012 R2
Software - Server operating systems supported - Windows Server 2016
Software - Server operating systems supported - Windows Server 2019
Software - Windows operating systems supported - Windows 7
Software - Windows operating systems supported - Windows 8
Software - Windows operating systems supported - Windows 10
Software - Windows operating systems supported - Windows 10, Windows 7, Windows 8
Stck_Kart - 1
Stck_Pal - 2
Storage - Disk roaming - Yes
Storage - Hot-swap drive bays - Yes
Storage - Installed storage drive type - No
Storage - Number of storage drives supported - 12
Storage - Online RAID expansion - Yes
Storage - Online RAID migration - Yes
Storage - RAID levels - 0
Storage - RAID levels - 0, 1, 5, 6, 10, 50, 60, JBOD
Storage - RAID levels - 1
Storage - RAID levels - 5
Storage - RAID levels - 6
Storage - RAID levels - 10
Storage - RAID levels - 50
Storage - RAID levels - 60
Storage - RAID levels - JBOD
Storage - RAID rebuild - Yes
Storage - RAID support - Yes
Storage - Storage drive capacity - 0 GB
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5
Storage - Storage drive sizes supported - 2.5,3.5"
Storage - Storage drive sizes supported - 3.5"
Storage - Supported file systems - exFAT
Storage - Supported file systems - ext3
Storage - Supported file systems - ext4
Storage - Supported file systems - FAT32
Storage - Supported file systems - FAT32, HFS+, NTFS, ZFS, exFAT, ext3, ext4
Storage - Supported file systems - HFS+
Storage - Supported file systems - NTFS
Storage - Supported file systems - ZFS
Storage - Supported storage drive interfaces - Serial ATA II, Serial ATA III
Storage - Supported storage drive types - HDD & SSD
Storage - Total installed storage capacity - 0 TB
Storno - Y
Title - QNAP TS-H1277AXU-RP NAS Rack (2U) AMD Ryzen™ 5 16 GB DDR5 0 TB QuTS hero Black
Total number of memory slots - 4
URL - https://www.qnap.com/en/product/ts-h1277axu-rp
vendpn - TS-h1277AXU-RP-R5-16G
WarrantyInfo - 5-year
warrantyLength - 60
warrantyType - F
Weight - 13 kg
weight - 18360
Weight & dimensions - Depth - 550 mm
Weight & dimensions - Height - 88.6 mm
Weight & dimensions - Package depth - 721 mm
Weight & dimensions - Package height - 273 mm
Weight & dimensions - Package weight - 17.6 kg
Weight & dimensions - Package width - 567 mm
Weight & dimensions - Weight - 13 kg
Weight & dimensions - Width - 482 mm
